RM0351
Bits 6:4 TS: Trigger selection
This bit-field selects the trigger input to be used to synchronize the counter.
Note: These bits must be changed only when they are not used (e.g. when SMS=000) to
Bit 3 OCCS: OCREF clear selection
This bit is used to select the OCREF clear source
Bits 2:0 SMS: Slave mode selection
When external signals are selected the active edge of the trigger signal (TRGI) is linked to the
polarity selected on the external input (see Input Control register and Control Register
description.
Note: The gated mode must not be used if TI1F_ED is selected as the trigger input (TS=100).
Note: The clock of the slave timer must be enabled prior to receive events from the master
Slave TIM
TIM2
TIM3
000: Internal Trigger 0 (ITR0). reserved
001: Internal Trigger 1 (ITR1).
010: Internal Trigger 2 (ITR2).
011: Internal Trigger 3 (ITR3). reserved
100: TI1 Edge Detector (TI1F_ED)
101: Filtered Timer Input 1 (TI1FP1)
110: Filtered Timer Input 2 (TI2FP2)
111: External Trigger input (ETRF)
See Table 153: TIMx internal trigger connection on page 907
meaning for each Timer.
avoid wrong edge detections at the transition.
0: OCREF_CLR_INT is connected to the OCREF_CLR input
1: OCREF_CLR_INT is connected to ETRF
0000: Slave mode disabled - if CEN = '1 then the prescaler is clocked directly by the internal
clock.
0001: Encoder mode 1 - Counter counts up/down on TI1FP1 edge depending on TI2FP2
level.
0010: Encoder mode 2 - Counter counts up/down on TI2FP2 edge depending on TI1FP1
level.
0011: Encoder mode 3 - Counter counts up/down on both TI1FP1 and TI2FP2 edges
depending on the level of the other input.
0100: Reset Mode - Rising edge of the selected trigger input (TRGI) reinitializes the counter
and generates an update of the registers.
0101: Gated Mode - The counter clock is enabled when the trigger input (TRGI) is high. The
counter stops (but is not reset) as soon as the trigger becomes low. Both start and stop of
the counter are controlled.
0110: Trigger Mode - The counter starts at a rising edge of the trigger TRGI (but it is not
reset). Only the start of the counter is controlled.
0111: External Clock Mode 1 - Rising edges of the selected trigger (TRGI) clock the counter.
1000: Combined reset + trigger mode - Rising edge of the selected trigger input (TRGI)
reinitializes the counter, generates an update of the registers and starts the counter.
Indeed, TI1F_ED outputs 1 pulse for each transition on TI1F, whereas the gated mode
checks the level of the trigger signal.
timer, and must not be changed on-the-fly while triggers are received from the master
timer.

Table 153. TIMx internal trigger connection

ITR0 (TS = 000)
TIM1
TIM1
General-purpose timers (TIM2/TIM3/TIM4/TIM5)
ITR1 (TS = 001)
TIM8/OTG_FS SOF
TIM2
DocID024597 Rev 3
for more details on ITRx
ITR2 (TS = 010)
(1)
TIM3
TIM5
ITR3 (TS = 011)
TIM4
TIM4
907/1693
