Table 111. Comp2 Input Plus Assignment; Table 112. Comp2 Input Minus Assignment; Comp Reset And Clocks - ST STM32L4x6 Reference Manual

RM0351
¾ V
REFINT
V
REFINT
DAC Channel1
DAC Channel2
PB1
PC4
PB4
PB6
¼ V
REFINT
½ V
REFINT
¾ V
REFINT
V
REFINT
DAC Channel1
DAC Channel2
PB3
PB7
19.3.3

COMP reset and clocks

The COMP clock provided by the clock controller is synchronous with the APB2 clock.
There is no clock enable control bit provided in the RCC controller. Reset and clock enable
bits are common for COMP and SYSCFG.
Note: Important: The polarity selection logic and the output redirection to the port works
independently from the APB2 clock. This allows the comparator to work even in Stop mode.
19.3.4 Comparator LOCK mechanism
The comparators can be used for safety purposes, such as over-current or thermal
protection. For applications having specific functional safety requirements, it is necessary to
insure that the comparator programming cannot be altered in case of spurious register
access or program counter corruption.
Table 110. COMP1 input minus assignment (continued)
COMP1_INM

Table 111. COMP2 input plus assignment

COMP2_INP

Table 112. COMP2 input minus assignment

COMP2_INM
