RM0351
15 14 13 12
PU15 PU14 PU13 PU12
rw rw rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 PUy: Port C pull-up bit y (y=0..15)
When set, this bit activates the pull-up on PC[y] when APC bit is set in PWR_CR3 register.
The pull-up is not activated if the corresponding PDy bit is also set.
5.4.13

Power Port C pull-down control register (PWR_PDCRC)

Address offset: 0x34.
Reset value: 0x0000 0000. This register is not reset when exiting Standby modes and with
PWRRST bit in the RCC_APB1RSTR1 register.
Access: Additional APB cycles are needed to access this register vs. a standard APB
access (3 for a write and 2 for a read).
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
PD15 PD14 PD13 PD12
rw rw rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 PDy: Port C pull-down bit y (y=0..15)
When set, this bit activates the pull-down on PC[y] when APC bit is set in PWR_CR3 register.
5.4.14

Power Port D pull-up control register (PWR_PUCRD)

Address offset: 0x38.
Reset value: 0x0000 0000. This register is not reset when exiting Standby modes and with
PWRRST bit in the RCC_APB1RSTR1 register.
Access: Additional APB cycles are needed to access this register vs. a standard APB
access (3 for a write and 2 for a read).
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
PU15 PU14 PU13 PU12
rw rw rw rw
11 10 9 8
PU11 PU10 PU9 PU8
rw rw rw rw
27 26 25 24
Res. Res. Res. Res.
11 10 9 8
PD11 PD10 PD9 PD8
rw rw rw rw
27 26 25 24
Res. Res. Res. Res.
11 10 9 8
PU11 PU10 PU9 PU8
rw rw rw rw
DocID024597 Rev 3
7 6 5 4
PU7 PU6 PU5 PU4
rw rw rw rw
23 22 21 20
Res. Res. Res. Res.
7 6 5 4
PD7 PD6 PD5 PD4
rw rw rw rw
23 22 21 20
Res. Res. Res. Res.
7 6 5 4
PU7 PU6 PU5 PU4
rw rw rw rw
Power control (PWR)
3 2 1 0
PU3 PU2 PU1 PU0
rw rw rw rw
19 18 17 16
Res. Res. Res. Res.
3 2 1 0
PD3 PD2 PD1 PD0
rw rw rw rw
19 18 17 16
Res. Res. Res. Res.
3 2 1 0
PU3 PU2 PU1 PU0
rw rw rw rw
171/1693
