Operational amplifiers (OPAMP)
Bits 9:8 VM_SEL: Inverting input selection
These bits are used only when OPAMODE = 00, 01 or 10.
Bits 7:6 Reserved, must be kept at reset value.
Bits 5:4 PGA_GAIN: Operational amplifier Programmable amplifier gain value
Bits 3:2 OPAMODE: Operational amplifier PGA mode
Bit 1 OPALPM: Operational amplifier Low Power Mode
The operational amplifier must be disable to change this configuration.
Bit 0 OPAEN: Operational amplifier Enable
20.5.5

OPAMP2 offset trimming register in normal mode (OPAMP2_OTR)

Address offset: 0x14
Reset value: 0x0000 XXXX (factory trimmed values)
31 30 29
Res. Res. Res.
15 14 13
Res. Res. Res.
Bits 31:13 Reserved, must be kept at reset value.
Bits 12:8 TRIMOFFSETP[4:0]: Trim for PMOS differential pairs
Bits 7:5 Reserved, must be kept at reset value.
Bits 4:0 TRIMOFFSETN[4:0]: Trim for NMOS differential pairs
20.5.6 OPAMP2 offset trimming register in low-power mode
(OPAMP2_LPOTR)
Address offset: 0x18
600/1693
