Bits 31:16 Reserved, must be kept at reset value.
Bit 15 PU15: Port A pull-up bit 15
When set, this bit activates the pull-up on PA[15] when APC bit is set in PWR_CR3 register.
The pull-up is not activated if the corresponding PD15 bit is also set.
Bit 14 Reserved, must be kept at reset value.
Bits 13:0 PUy: Port A pull-up bit y (y=0..13)
When set, this bit activates the pull-up on PA[y] when APC bit is set in PWR_CR3 register.
The pull-up is not activated if the corresponding PDy bit is also set.
5.4.9

Power Port A pull-down control register (PWR_PDCRA)

Address offset: 0x24.
Reset value: 0x0000 0000. This register is not reset when exiting Standby modes and with
PWRRST bit in the RCC_APB1RSTR1 register.
Access: Additional APB cycles are needed to access this register vs. a standard APB
access (3 for a write and 2 for a read).
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
Res. PD14 Res. PD12
rw rw
Bits 31:15 Reserved, must be kept at reset value.
Bit 14 PD14: Port A pull-down bit 14
When set, this bit activates the pull-down on PA[14] when APC bit is set in PWR_CR3
register.
Bit 13 Reserved, must be kept at reset value.
Bits 12:0 PDy: Port A pull-down bit y (y=0..12)
When set, this bit activates the pull-down on PA[y] when APC bit is set in PWR_CR3 register.
5.4.10

Power Port B pull-up control register (PWR_PUCRB)

Address offset: 0x28.
Reset value: 0x0000 0000. This register is not reset when exiting Standby modes and with
PWRRST bit in the RCC_APB1RSTR1 register.
Access: Additional APB cycles are needed to access this register vs. a standard APB
access (3 for a write and 2 for a read).
31 30 29 28
Res. Res. Res. Res.
27 26 25 24
Res. Res. Res. Res.
11 10 9 8
PD11 PD10 PD9 PD8
rw rw rw rw
27 26 25 24
Res. Res. Res. Res.
DocID024597 Rev 3
23 22 21 20
Res. Res. Res. Res.
7 6 5 4
PD7 PD6 PD5 PD4
rw rw rw rw
23 22 21 20
Res. Res. Res. Res.
Power control (PWR)
19 18 17 16
Res. Res. Res. Res.
3 2 1 0
PD3 PD2 PD1 PD0
rw rw rw rw
19 18 17 16
Res. Res. Res. Res.
