RM0351
26.4.20
TIM1/TIM8 DMA address for full transfer (TIMx_DMAR)
Address offset: 0x4C
Reset value: 0x0000
15
14
13
rw
rw
rw
Bits 15:0 DMAB[15:0]: DMA register for burst accesses
A read or write operation to the DMAR register accesses the register located at the address
(TIMx_CR1 address) + (DBA + DMA index) x 4
where TIMx_CR1 address is the address of the control register 1, DBA is the DMA base
address configured in TIMx_DCR register, DMA index is automatically controlled by the DMA
transfer, and ranges from 0 to DBL (DBL configured in TIMx_DCR).
26.4.21
TIM1 option register 1 (TIM1_OR1)
Address offset: 0x50
Reset value: 0x0000 0000
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Res.
Res.
Res.
Res.
Bits 31:5 Reserved, must be kept at reset value
Bit 4 TI1_RMP: Input Capture 1 remap
Bits 3:2 ETR_ADC3_RMP: External trigger remap on ADC3 analog watchdog
Note: ADC3 AWDx sources are 'ORed' with the TIM1_ETR input signals. When ADC3 AWDx
12
11
10
9
rw
rw
rw
rw
27
26
25
Res.
Res.
Res.
11
10
9
Res.
Res.
Res.
0: TIM1 input capture 1 is connected to I/O
1: TIM1 input capture 1 is connected to COMP1 output.
00: TIM1_ETR is not connected to ADC3 AWDx. This configuration must be selected when
the ETR comes from the I/O.
01: TIM1_ETR is connected to ADC3 AWD1.
10: TIM1_ETR is connected to ADC3 AWD2.
11: TIM1_ETR is connected to ADC3 AWD3.
is used, it is necessary to make sure that the corresponding TIM1_ETR input pin is not
enabled in the alternate function controller. Refer to
circuitry.
8
7
6
DMAB[15:0]
rw
rw
rw
24
23
22
21
Res.
Res.
Res.
Res.
8
7
6
5
Res.
Res.
Res.
Res.
DocID024597 Rev 3
Advanced-control timers (TIM1/TIM8)
5
4
3
rw
rw
rw
20
19
18
Res.
Res.
Res.
4
3
2
TI1_R
ETR_ADC3_RMP
MP
rw
rw
rw
Figure 210: TIM1 ETR input
2
1
0
rw
rw
rw
17
16
Res.
Res.
1
0
ETR_ADC1_RMP
rw
rw
841/1693
