Advanced-control timers (TIM1/TIM8)
Bit 2 CC2IE: Capture/Compare 2 interrupt enable
0: CC2 interrupt disabled
1: CC2 interrupt enabled
Bit 1 CC1IE: Capture/Compare 1 interrupt enable
0: CC1 interrupt disabled
1: CC1 interrupt enabled
Bit 0 UIE: Update interrupt enable
0: Update interrupt disabled
1: Update interrupt enabled
26.4.5

TIM1/TIM8 status register (TIMx_SR)

Address offset: 0x10
Reset value: 0x0000 0000
31 30 29
Res. Res. Res. Res.
15 14 13
Res. Res. SBIF CC4OF CC3OF CC2OF CC1OF
rc_w0 rc_w0
Bits 31:18 Reserved, must be kept at reset value.
Bit 17 CC6IF: Compare 6 interrupt flag
Refer to CC1IF description (Note: Channel 6 can only be configured as output)
Bit 16 CC5IF: Compare 5 interrupt flag
Refer to CC1IF description (Note: Channel 5 can only be configured as output)
Bits 15:14 Reserved, must be kept at reset value.
Bit 13 SBIF: System Break interrupt flag
Bit 12 CC4OF: Capture/Compare 4 overcapture flag
Refer to CC1OF description
Bit 11 CC3OF: Capture/Compare 3 overcapture flag
Refer to CC1OF description
Bit 10 CC2OF: Capture/Compare 2 overcapture flag
Refer to CC1OF description
Bit 9 CC1OF: Capture/Compare 1 overcapture flag
This flag is set by hardware only when the corresponding channel is configured in input
capture mode. It is cleared by software by writing it to '0'.
820/1693
28 27 26 25
Res. Res. Res.
12 11 10 9
rc_w0 rc_w0 rc_w0
This flag is set by hardware as soon as the system break input goes active. It can be
cleared by software if the system break input is not active.
This flag must be reset to re-start PWM operation.
0: No break event occurred.
1: An active level has been detected on the system break input. An interrupt is generated if
BIE=1 in the TIMx_DIER register.
0: No overcapture has been detected.
1: The counter value has been captured in TIMx_CCR1 register while CC1IF flag was
already set
24 23 22
Res. Res. Res.
8 7 6
B2IF BIF TIF
rc_w0 rc_w0 rc_w0
DocID024597 Rev 3
21 20 19 18
Res. Res. Res. Res.
5 4 3
COMIF CC4IF CC3IF CC2IF
rc_w0 rc_w0 rc_w0 rc_w0
RM0351
17 16
C6IF C5IF
rc_w0 rc_w0
2 1 0
CC1IF UIF
rc_w0 rc_w0
