If you place a new room within bounding elements or separation lines that contain a room that you placed
previously, Revit Architecture warns you that the new room is redundant and suggests that you either move
it or delete it.
You can delete a room by deleting it from a room schedule. The corresponding room tag is deleted as well.
If you delete a room tag in a plan view, the room remains in the project and in the schedule. (See
Rooms on page 1000.)

Room Schedules and Room Tags

The room schedule and rooms are associated; therefore, all fields that appear in the room schedule are part
of the properties list for the room. If you modify field values in the schedule, the corresponding property
values update for the room, and vice versa. Also, this association extends to room tags. For example, if you
change the room name in the schedule, the room and related tags update and display the new name.
Room tags are annotation elements that display values from the room properties. The properties of a room
tag are the properties of the annotation family. If a room is selected in a schedule, you can click Show on
the Modify Schedule/Quantities tab to see the position of the room in any related view.
For more information about schedules, see

Room Tag Properties

Use room tag properties to control the appearance and behavior of room tags.
Related topic
Room Properties
Modifying Room Tag Properties
1 In a plan or section view, select a room tag, and click Modify Room Tags tab
2 In the Instance Properties dialog, edit room tag instance parameters.
3 To edit room tag type parameters, click Edit Type.
4 Click OK.
Room Tag Type Properties
Name
Graphics
Show Volume
Show Room Number
Show Area
988 | Chapter 16 Rooms and Areas
on page 1003
panel Element Properties.
See Room Tag Instance Properties
See Room Tag Type Properties
Description
Displays the room's computed volume in the tag. If Not Computed displays, turn
on volume computation. See
Displays the room's assigned number in the tag.
Displays the room's computed area in the tag.
Creating a Schedule or Quantity
on page 989.
on page 988.
Enabling Volume Computations
Removing
on page 173.
Element
on page 993.
