SSANGYONG Y200
DIESEL ENGINE CONTROLS 1F3-65
Removal & Installation Procedure
Caution: The fuel system is under pressure. To avoid
fuel spillage and the risk of personal injury or fire,
it is necessary to relieve the fuel system pressure
before disconnecting the fuel lines.
1. Disconnect the negative battery cable.
2. Disconnect the fuel filler hoses.
YAD1FDC0
3. Put aside the floor carpet to remove the fuel pump
access cover.
4. Remove the fuel pump access cover.
5. Disconect the fuel return and supply line.
6. Disconnect the fuel pump wiring connector.
YAD1FDD0
7. Remove the fuel pump moumting bolts and
bracket.
8. Carefully lower the fuel tank.
9. Installation should follow the removal precedure
in the reverse order.
YAD1FDE0
