Item
Quality class:
Ssangyong genuine engine oil
(Approved by MB Sheet 229.1 or 229.3)
Engine oil
Viscosity:
MB sheet No. 224.1
Automatic
SHELL Fuchs ATF 3353
transmission
BP Olex GO 4927
Rear axle oil
Engine Coolant
SYC-310
Power steering fluid
ATF DEXRON II or III
Brake fluid
DOT4
WARNING
Use only Ssangyong recommended fluids and lubricants.
Keep the specified levels when adding or replacing the fluids.
Do not mix any different types or brands of oils or fluids. This
may cause damages.
Page 2
Specification
CM500
11.5 ~ 12.0
as required
2006-10-02, ¿ÀÈÄ 5:55
Capacity
CM600
7.0
←
8.0
←
1.3
←
←
1.0
←
←
