GENERAL INFORMATION
DIAGRAM...............................................
3. FUNCTION OF POWER SUPPLY LINE
(NUMBER)..............................................
IDENTIFICATION.....................................
CONNECTOR..........................................
NUMBER.................................................
7. ELECTRIC SYMBOLS................................
GENERAL INFORMATION
GENERAL INFORMATION
4
5
5
5
5
6
6
0000-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rexton 2010 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SSANGYONG Rexton 2010

Summary of Contents for SSANGYONG Rexton 2010

  • Page 1: Table Of Contents

    GENERAL INFORMATION 0000-00 GENERAL INFORMATION GENERAL INFORMATION 1. HOW TO READ ELECTRICAL WIRING DIAGRAM..........2. CIRCUIT IDENTIFICATION SYMBOL..3. FUNCTION OF POWER SUPPLY LINE (NUMBER)..........4. WIRING HARNESS COLOR IDENTIFICATION........5. HOW TO CHECK TERMINAL NUMBER OF CONNECTOR.......... 6. PART LOCATION ACCORDING TO PART NUMBER..........
  • Page 2 01-2 0000-00 * Y-286 UPDATE DETALS GENERAL INFORMATION REXTON 2010.01...

  • Page 4: How To Read Electrical Wiring Diagram

    01-4 0000-00 1) CONTENTS OF ELECTRICAL WIRING DIAGRAM (CIRCUIT) GENERAL INFORMATION 1. HOW TO READ ELECTRICAL WIRING DIAGRAM GENERAL INFORMATION REXTON 2010.01...

  • Page 5: Circuit Identification Symbol

    4. WIRING HARNESS COLOR IDENTIFICATION 3. FUNCTION OF POWER SUPPLY LINE (NUMBER) 5. HOW TO CHECK TERMINAL NUMBER OF CONNECTOR Terminal number is given based on Female Terminal Male Connector ex) Terminal Number 4 of C901 connection GENERAL INFORMATION REXTON 2010.01...

  • Page 6: Part Location According To Part Number

    01-6 0000-00 6. PART LOCATION ACCORDING TO PART NUMBER 7. ELECTRIC SYMBOLS GENERAL INFORMATION REXTON 2010.01...
  • Page 8 CONNECTOR/GROUND 8201-00/8210-00/8210-02/8210-03/8210-09/8210-10/8210-06/8210-07/8210-08 CONNECTOR/GROUND WIRING HARNESS 8201-00 WIRING HARNESS, COMPONENTS LOCATION....CONNECTOR/GROUND 8210-00 W/H ENGINE ROOM...... 8210-02 W/H MAIN........8210-03 W/H FLOOR........8210-09 W/H ROOF........8210-06 W/H DRIVER DOOR....... 8210-07 W/H PASSENGER DOOR....8210-08 W/H RR DOOR......8210-10 W/H TAIL GATE......

  • Page 10: Wiring Harness

    02-3 8201-00 WIRING HARNESS WIRING HARNESS, COMPONENTS LOCATION 8201-00 2) COMPONENTS LOCATION 1) WIRING HARNESS CONNECTORS/GROUNDS REXTON 2010.01...
  • Page 11 02-4 8201-00 3) CONNECTOR, GROUND & SPLICE PACK INFORMATION ▶ CONNECTOR CONNECTORS/GROUNDS REXTON 2010.01...
  • Page 12 02-5 8201-00 4) SPLICE PACK CIRCUIT ▶ SPLICE PACK ▶ S201 ▶ GROUND ▶ S202 (CAN) CONNECTORS/GROUNDS REXTON 2010.01...
  • Page 13 02-6 8201-00 ▶ S203 (GND) ▶ S205 ▶ S204 ▶ S301 CONNECTORS/GROUNDS REXTON 2010.01...
  • Page 14 02-7 8201-00 5) WIRING CONNECTOR CONNECTORS/GROUNDS REXTON 2010.01...
  • Page 15 02-8 8201-00 ▶ UNIT CONNECTOR ▶ SWITCH CONNECTOR CONNECTORS/GROUNDS REXTON 2010.01...
  • Page 16 02-9 8201-00 ▶ MODE CONNECTOR ▶ETC. ▶ SENSOR CONNECTOR ▶ LAMP CONNECTOR CONNECTORS/GROUNDS REXTON 2010.01...

  • Page 17: Connector/Ground

    02-10 8210-00 CONNECTOR/GROUND W/H ENGINE ROOM 8210-00 CONNECTORS/GROUNDS REXTON 2010.01...

  • Page 18: 8210-02 W/H Main

    02-11 8210-02 W/H MAIN 8210-02 CONNECTORS/GROUNDS REXTON 2010.01...

  • Page 19: 8210-03 W/H Floor

    02-12 8210-02 W/H FLOOR 8210-02 CONNECTORS/GROUNDS REXTON 2010.01...
  • Page 20 02-13 8210-02 CONNECTORS/GROUNDS REXTON 2010.01...
  • Page 21 02-14 8210-03 W/H ROOF DRIVER DOOR 8210-03 8210-03 CONNECTORS/GROUNDS REXTON 2010.01...
  • Page 22 02-15 8210-03 PASSENGER DOOR W/H RR DOOR 8210-03 8210-03 CONNECTORS/GROUNDS REXTON 2010.01...

  • Page 23: 8210-10 W/H Tail Gate

    W/H TAIL GATE 8210-09...
  • Page 24 POWER DISTRIBUTION 8410-02/8410-04/8401-06 POWER DISTRIBUTION FUSE/RELAY 8410-02 ENGINE ROOM FUSE / RELAY BOX........8410-04 I/P - FUSE BOX....... 8401-06 I/P - RELAY BOX......ELECTRICITY DIVIDE 8210-02 ENGINE ROOM FUSE / RELAY BOX CIRCUIT..... 8410-04 I/P - FUSE BOX CIRCUIT....8410-06 I/P - RELAY BOX CIRCUIT....8410-06 ICM RELAY BOX CIRCUIT....

  • Page 26: Fuse/Relay

    03-3 8410-02 FUSE / RELAY ENGINE ROOM FUSE / RELAY BOX 8410-02 1) UPPER 3) ENGINE ROOM FUSE & RELAY BOX(D27DT, PWM/VISCO) 2) LOWER POWER DISTRIBUTION REXTON 2010.01...
  • Page 27 03-4 8410-02 4) ENGINE ROOM FUSE / RELAY BOX(D27DTP, GSL) 5) USAGE OF FUSE IN ENGINE ROOM FUSE BOX 6) ENGINE ROOM FUSE BOX CONNECTOR NUMBER POWER DISTRIBUTION REXTON 2010.01...

  • Page 28: 8410-04 I/P - Fuse Box

    03-5 8410-04 I/P - FUSE BOX 8410-04 1) FUSE BOX (DSL) 3) POWER SUPPLY 2) FUSE BOX (GSL) POWER DISTRIBUTION REXTON 2010.01...

  • Page 29: 8401-06 I/P - Relay Box

    03-6 8410-06 I/P - RELAY BOX 8410-06 1) RELAY BOX 2) POWER SUPPLY POWER DISTRIBUTION REXTON 2010.01...

  • Page 31: Electricity Divide

    03-7 8210-02 ELECTRICITY DIVIDE ENGINE ROOM FUSE / RELAY BOX CIRCUIT 8210-02 (1) SB1 ~ SB4, CONDENSOR FAN RELAY (HI, LO) (2) SB5 ~ SB8, EF5, EF6, ENG MAIN RELAY, START RELAY POWER DISTRIBUTION REXTON 2010.01...
  • Page 32 03-8 8210-02 (3) SB9 ~ SB11, EF1, EF2, DEICER RELAY, HORN RELAY (4) EF3, EF4, EF19, EF20, HEAD LAMP RELAY(HI, LO), COMP RELAY,ENG MOUNT CONTROL RELAY POWER DISTRIBUTION REXTON 2010.01...
  • Page 33 03-9 8210-02 (5) EF7 ~ EF9, EF21, TAIL LAMP RELAY, FRT FOG LAMP RELAY (6) EF10 ~ EF13, EF17, EF18, EF23, RR DEF RELAY POWER DISTRIBUTION REXTON 2010.01...
  • Page 34 03-10 8210-02 (7) EF14 ~ EF16, EF22, EF24 ~ EF26, POWER WINDOW RELAY (8) FRT WIPER MOTOR RELAY(LO) POWER DISTRIBUTION REXTON 2010.01...

  • Page 35: 8410-04 I/P - Fuse Box Circuit

    03-11 8410-04 I/P - FUSE BOX CIRCUIT 8410-04 (1) F1 ~ F5 (2) F6 ~ F10 POWER DISTRIBUTION REXTON 2010.01...
  • Page 36 03-12 8410-04 (3) F12 (DSL), F13 ~ F16 (4) F11, F12 (GSL), F17 ~ F22 POWER DISTRIBUTION REXTON 2010.01...
  • Page 37 03-13 8410-04 (5) F23 ~ F26 (6) F27 ~ F31 POWER DISTRIBUTION REXTON 2010.01...
  • Page 38 03-14 8410-04 (7) F33 ~ F36 POWER DISTRIBUTION REXTON 2010.01...

  • Page 39: 8410-06 I/P - Relay Box Circuit

    03-15 8410-06 I/P - RELAY BOX CIRCUIT 8410-06 (1) BLOWER RELAY(FRT, RR), FLASHER UNIT (2) WIPER RELAY(HI), RR WASHER RELAY, RR WIPER RELAY POWER DISTRIBUTION REXTON 2010.01...
  • Page 40 03-16 8410-06 (3) RR FOG LAMP RELAY, RR SEAT WARMER RELAY(LH/RH) (4) F/PUMP RELAY, INJ/IGN RELAY, SNR RELAY POWER DISTRIBUTION REXTON 2010.01...

  • Page 41: 8410-06 Icm Relay Box Circuit

    03-17 8410-06 ICM RELAY BOX CIRCUIT 8410-06 (1) HDC RELAY, DR LOCK/UNLOCK RELAY (2) HAZARD RELAY, DRL SIGNAL POWER DISTRIBUTION REXTON 2010.01...
  • Page 43 CIRCUIT 1461-01/2820-01/1491-01/8210-01/3410-01/4480-01/4920-01/4892-01/4620-12/8010-01/7410-13/7410-04/8510-52/8510-48/ 8710-02/7830-03/8510-05/8610-06/7632-167340-03/8310-01/8510-00/8320-01/8410-01/8210-01/8310-10/4810-01/7770-02/ 7770-10/8910-01/8930-01/8790-01/6810-15/6910-01/6810-20 CIRCUIT ENGINE ELECTRIC 1461-01 STARTING / CHARGING....8510-48 RR SEAT WARMER......2820-01 PREHEATING CIRCUIT I....8710-02 STICS........... 2820-01 PREHEATING CIRCUIT II....7830-03 RR DPS WIPER / WASHER.... 1491-01 ECU (D27DT (EU IV), D27DTP)..7830-03 RR STANDARD WIPER / 1491-01 ECU (D27DT)........

  • Page 45: 1461-01 Starting / Charging

    04-3 1461-01 STARTING / CHARGING (1) CONNECTOR INFORMATION 1461-01 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 46 04-4 2820-01 PREHEATING CIRCUIT I (D27DT (EU IV) / (1) CONNECTOR INFORMATION 2820-01 　 D27DTP - W/ AQGS) (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 47 04-5 2820-01 PREHEATING CIRCUIT II (D27DT / D27DTP - (1) CONNECTOR INFORMATION 2820-01 　 W/O AQGS) (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 48 04-6 1491-01 ECU (ENGINE CONTROL UNIT - D27DT (EU IV), (1) CONNECTOR INFORMATION 1491-01 　 D27DTP) 1) ENG MAIN RELAY, PEDAL MODULE, HFM SENSOR, VALVE, ENG MOUNT (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 49 04-7 1491-01 2) FUEL FILTER WARNING LAMP, IMMOBILIZER, SENSOR, PREHEATING (1) CONNECTOR INFORMATION UNIT, A/CRUISE SW, DIAGNOSIS (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 50 04-8 1491-01 3) INJECTOR, STOP LAMP SW, SENSOR(A/CON, E-GAS), CLUTCH SW (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 51 04-9 1491-01 ECU (ENGINE CONTROL UNIT - D27DT) (1) CONNECTOR INFORMATION 1491-01 ENG MAIN RELAY, PEDAL MODULE, HFM SENSOR, VALVE, CRUISE CONTROL SW (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 52 04-10 1491-01 2) FUEL FILTER WARNING LAMP, IMMOBILIZER, SENSOR (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 53 04-11 1491-01 3) INJECTOR, CAN LINE (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 54 04-12 1491-01 ECU (ENGINE CONTROL UNIT - GSL G32D) (1) CONNECTOR INFORMATION 1491-01 1) IGN COIL, INJECTOR, PEDAL MODULE, THROTTLE SENSOR (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 55 04-13 1491-01 2) O2 SENSOR, CPS, KNOCK SENSOR, HFM SENSOR, CANISTER (1) CONNECTOR INFORMATION PURGE VALVE (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 56 04-14 1491-01 S/AIR PUMP, STOP LAMP, CRUISE CONTROL SW, FUEL PUMP, (1) CONNECTOR INFORMATION IMMOBILIZER (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 57: 8210-01 Diagnosis Circuit

    04-15 8210-01 DIAGNOSIS CIRCUIT (1) CONNECTOR INFORMATION 8210-01 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 58 04-24 8810-01 AIR-BAG (SIDE AIR-BAG) (1) CONNECTOR INFORMATION 8810-01 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 59 04-25 8010-01 CLUSTER (1) CONNECTOR INFORMATION 8010-01 1) GAUGE (SPEED, RPM, FUEL, TEMP), WARNING LAMP (FUEL, FUEL FILTER, ABS/ESP, BRAKE, HDC, 4WD) (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 60 04-26 8010-01 2) WARNING LAMP (EPB, AUTO PARK G, GLOBAL), TPMS DISPLAY (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 61 04-27 8010-01 3) WARNING LAMP (BATT CHARGE, OIL, SSPS, DOOR, ENG CHECK, AIR (1) CONNECTOR INFORMATION BAG, SEAT BELT), TURN SIGNAL, FOG LAMP, HAZARD (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 62 04-28 7410-13 POWER SEAT - DRIVER (W/ MEMORY) (1) CONNECTOR INFORMATION 7410-13 1) DRIVER POWER SEAT / SEAT MEMORY (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 63 04-29 7410-13 2) ELECTRIC OUTSIDE MIRROR / FOLDING (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 64: 7410-04 Power Seat - Passenger

    04-30 7410-04 POWER SEAT - PASSENGER (1) CONNECTOR INFORMATION 7410-04 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 65: 8510-52 Electric Outside Mirror

    04-31 8510-52 null ELECTRIC OUTSIDE MIRROR / FOLDING (W/O (1) CONNECTOR INFORMATION 8510-52 MEMORY) (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 66 04-32 8510-48 FRT SEAT WARMER (W/ MEMORY) (1) CONNECTOR INFORMATION 8510-48 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 67 04-33 8510-48 FRT SEAT WARMER (W/O MEMORY) (1) CONNECTOR INFORMATION 8510-48 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 68 04-34 8510-48 RR SEAT WARMER (1) CONNECTOR INFORMATION 8510-48 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 69 04-35 8710-02 STICS (1) CONNECTOR INFORMATION 8710-02 1) POWER/GROUND, CHIME BELL, BUZZER WARNING LAMP (BRAKE, S/BELT, DR OPEN) (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 70 04-36 8710-02 2) CENTRAL DOOR LOCK CIRCUIT (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 71 04-37 8710-02 3) TAIL LAMP, HAZARD, POWER WINDOW (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 72 04-38 8710-02 4) DEFOGGER (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 73 04-39 8710-02 5) PANIC, AUTO LIGHT / RAIN SENSING, ROOM LAMP (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 74 04-40 8710-02 6) FRT WIPER / WASHER (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 75 04-41 7830-03 RR DPS WIPER / WASHER (W/ FLIP UP GLASS) (1) CONNECTOR INFORMATION 7830-03 　 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 76 04-42 7830-03 RR STANDARD WIPER / WASHER (1) CONNECTOR INFORMATION 7830-03 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 77: 8510-05 Power Window Circuit

    04-43 8510-05 POWER WINDOW CIRCUIT (1) CONNECTOR INFORMATION 8510-05 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 78 04-44 8610-06 HORN (1) CONNECTOR INFORMATION 8610-06 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 79 04-45 7632-16 CIGAR LIGHTER / POWER OUTLET CIRCUIT (1) CONNECTOR INFORMATION 7632-16 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 80: 7340-03 Sun Roof Circuit

    04-46 7340-03 SUN ROOF CIRCUIT (1) CONNECTOR INFORMATION 7340-03 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 81 04-47 8310-01 HEAD LAMP / DRL (DAY TIME RUNNING (1) CONNECTOR INFORMATION 8310-01 HEAD LAMP ＆ DRL LIGHT) UNIT CIRCUIT (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 82 04-48 8510-00 HLLD (HEAD LAMP LEVEL G DEVICE) CIRCUIT (1) CONNECTOR INFORMATION 8510-00 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 83: 8320-01 Tail Lamp Circuit

    04-49 8320-01 TAIL LAMP CIRCUIT (1) CONNECTOR INFORMATION 8320-01 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 84: 8410-01 Turn Signal / Hazard Lamp Circuit

    04-50 8410-01 TURN SIGNAL / HAZARD LAMP CIRCUIT (1) CONNECTOR INFORMATION 8410-01 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 85: 8210-01 Trailer Lamp Circuit

    04-51 8210-01 TRAILER LAMP CIRCUIT (1) CONNECTOR INFORMATION 8210-01 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 86: 8310-10 Fog Lamp Circuit

    04-52 8310-10 FOG LAMP CIRCUIT (1) CONNECTOR INFORMATION 8310-10 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 87: 4810-01 Stop / Back-Up Lamp Circuit

    04-53 4810-01 STOP / BACK-UP LAMP CIRCUIT (1) CONNECTOR INFORMATION 4810-01 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 88: 7770-02 Interior Lamp Circuit

    04-54 7770-02 INTERIOR LAMP CIRCUIT (1) CONNECTOR INFORMATION 7770-02 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 89: 7770-10 Auto Dimming Room Mirror Circuit

    04-55 7770-10 AUTO DIMMING ROOM MIRROR CIRCUIT (1) CONNECTOR INFORMATION 7770-10 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 90 04-56 8910-01 AUDIO (1) CONNECTOR INFORMATION 8910-01 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 91 04-57 8930-01 A/V SYSTEM (1) CONNECTOR INFORMATION 8930-01 1) NAVI UNIT, A/V HEAD UNIT, DVD CHANGER, TUNER UNIT, AUX JACK (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 92 04-58 8930-01 2) A/V HEAD UNIT, DSP/AMP, TUNER UNIT, WOOFER AMP, SPEAKER (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 93 04-59 8930-01 3) MP3 MULTI JACK STATION, A/V HEAD UNIT, AUDIO, MP3 SW (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 94: 8790-01 Rr Parking Aid System

    04-60 8790-01 RR PARKING AID SYSTEM (1) CONNECTOR INFORMATION 8790-01 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...

  • Page 95: 8790-01 Frt/Rr Parking Aid System

    04-61 6810-15 FRT/RR PARKING AID SYSTEM (1) CONNECTOR INFORMATION 6810-15 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 96 04-62 6810-15 PTC (POSITIVE TEMPERATURE COEFFICIENT) (1) CONNECTOR INFORMATION 6810-15 　 HEATER (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 97 04-63 6910-01 FFH (FUEL FIRED HEATER) (1) CONNECTOR INFORMATION 6910-01 (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 98 04-64 6810-20 FATC (FULL AUTO TEMP. CONTROL) CIRCUIT (1) CONNECTOR INFORMATION 6810-20 1) CONDENSOR FAN, SENSOR (D27DT, GSL) (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 99 04-65 6810-20 2) CONDENSOR FAN, SENSOR (D27DT EU IV / D27DTP - A/T) (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 100 04-66 6810-20 3) PWM MOTOR, SENSOR (D27DT EU IV / D27DTP - M/T) (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
  • Page 101 04-67 6810-20 4) MOTOR (MODE, INTAKE), BLOWER, POWER TR (1) CONNECTOR INFORMATION (2) CONNECTOR IDENTIFICATION SYMBOL & PIN NUMBER POSITION CIRCUIT REXTON 2010.01...
