Low-power timer (LPTIM)
15
14
13
12
Res.
Res.
Res.
Res.
Bits 31:2 Reserved, must be kept at reset value.
Bit 1 OR_1: Option register bit 1
0:
LPTIM2 input 1 is connected to I/O
1:
LPTIM2 input 1 is connected to COMP2_OUT
Bit 0 OR_0: Option register bit 0
0:
LPTIM2 input 1 is connected to I/O
1:
LPTIM2 input 1 is connected to COMP1_OUT
Note:
When both OR_1 and OR_0 are set, LPTIM2 input 1 is connected to (COMP1_OUT OR
COMP2_OUT).
1044/1693
11
10
9
8
Res.
Res.
Res.
Res.
DocID024597 Rev 3
7
6
5
4
Res.
Res.
Res.
Res.
RM0351
3
2
1
0
Res.
Res.
OR_1
OR_0
rw
rw
