LPTIM registers

30.7.1 LPTIM interrupt and status register (LPTIMx_ISR)
Address offset: 0x00
Reset value: 0x0000 0000
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
Res. Res. Res. Res.
Bits 31:7 Reserved, must be kept at reset value.
Bit 6 DOWN: Counter direction change up to down
In Encoder mode, DOWN bit is set by hardware to inform application that the counter direction has
changed from up to down.
Bit 5 UP: Counter direction change down to up
In Encoder mode, UP bit is set by hardware to inform application that the counter direction has
changed from down to up.
Bit 4 ARROK: Autoreload register update OK
ARROK is set by hardware to inform application that the APB bus write operation to the LPTIMx_ARR
register has been successfully completed. If so, a new one can be initiated.
Bit 3 CMPOK: Compare register update OK
CMPOK is set by hardware to inform application that the APB bus write operation to the LPTIMx_CMP
register has been successfully completed. If so, a new one can be initiated.
Bit 2 EXTTRIG: External trigger edge event
EXTTRIG is set by hardware to inform application that a valid edge on the selected external trigger
input has occurred. If the trigger is ignored because the timer has already started, then this flag is not
set.
Bit 1 ARRM: Autoreload match
ARRM is set by hardware to inform application that LPTIMx_CNT register's value reached the
LPTIMx_ARR register's value.
Bit 0 CMPM: Compare match
The CMPM bit is set by hardware to inform application that LPTIMx_CNT register value reached the
LPTIMx_CMP register's value.
27 26 25 24
Res. Res. Res. Res.
11 10 9 8
Res. Res. Res. Res.
DocID024597 Rev 3
23 22 21 20
Res. Res. Res. Res.
7 6 5 4
Res. DOWN UP ARROK
r r r
Low-power timer (LPTIM)
19 18 17
Res. Res. Res.
3 2 1
CMPOK EXTTRIG ARRM CMPM
r r r
1035/1693
16
Res.
0
r
