General-purpose timers (TIM15/16/17)
28.6.4 TIM16&TIM17 status register (TIMx_SR)
Address offset: 0x10
Reset value: 0x0000
15 14 13
Res Res Res
Bits 15:10 Reserved, must be kept at reset value.
Bit 9 CC1OF: Capture/Compare 1 overcapture flag
Bit 8 Reserved, must be kept at reset value.
Bit 7 BIF: Break interrupt flag
Bit 6 Reserved, must be kept at reset value.
Bit 5 COMIF: COM interrupt flag
Bits 4:2 Reserved, must be kept at reset value.
Bit 1 CC1IF: Capture/Compare 1 interrupt flag
992/1693
12 11 10 9
Res Res Res CC1OF
rc_w0
This flag is set by hardware only when the corresponding channel is configured in input
capture mode. It is cleared by software by writing it to '0'.
0: No overcapture has been detected
1: The counter value has been captured in TIMx_CCR1 register while CC1IF flag was
already set
This flag is set by hardware as soon as the break input goes active. It can be cleared by
software if the break input is not active.
0: No break event occurred
1: An active level has been detected on the break input
This flag is set by hardware on a COM event (once the capture/compare control bits –CCxE,
CCxNE, OCxM– have been updated). It is cleared by software.
0: No COM event occurred
1: COM interrupt pending
If channel CC1 is configured as output:
This flag is set by hardware when the counter matches the compare value. It is cleared by
software.
0: No match.
1: The content of the counter TIMx_CNT matches the content of the TIMx_CCR1 register.
When the contents of TIMx_CCR1 are greater than the contents of TIMx_ARR, the CC1IF
bit goes high on the counter overflow
If channel CC1 is configured as input:
This bit is set by hardware on a capture. It is cleared by software or by reading the
TIMx_CCR1 register.
0: No input capture occurred
1: The counter value has been captured in TIMx_CCR1 register (An edge has been
detected on IC1 which matches the selected polarity)
8 7 6
Res BIF Res
rc_w0
DocID024597 Rev 3
5 4 3
COMIF Res Res Res
rc_w0
RM0351
2 1 0
CC1IF UIF
rc_w0 rc_w0
