Low-power timer (LPTIM)
30.7.6
LPTIM compare register (LPTIMx_CMP)
Address offset: 0x14
Reset value: 0x0000 0000
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 CMP: Compare value
CMP is the compare value used by the LPTIM.
The LPTIMx_CMP register's content must only be modified when the LPTIM is enabled (ENABLE bit
is set to '1').
30.7.7
LPTIM autoreload register (LPTIMx_ARR)
Address offset: 0x18
Reset value: 0x0000 0001
31
30
29
28
Res.
Res.
Res.
Res.
15
14
13
12
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 ARR: Auto reload value
ARR is the autoreload value for the LPTIM.
This value must be strictly greater than the CMP[15:0] value.
The LPTIMx_ARR register's content must only be modified when the LPTIM is enabled (ENABLE bit
is set to '1').
1042/1693
27
26
25
24
Res.
Res.
Res.
Res.
11
10
9
8
27
26
25
24
Res.
Res.
Res.
Res.
11
10
9
8
DocID024597 Rev 3
23
22
21
Res.
Res.
Res.
7
6
5
CMP[15:0]
rw
23
22
21
Res.
Res.
Res.
7
6
5
ARR[15:0]
rw
20
19
18
17
Res.
Res.
Res.
Res.
4
3
2
1
20
19
18
17
Res.
Res.
Res.
Res.
4
3
2
1
RM0351
16
Res.
0
16
Res.
0
