Introduction
TABLE 1-24
CFC Card Attribute
State
1-144
Software Reference for SwitchBlade x3100 Series Switches (Setting Up the Switch)
CFC200 Card Attributes - Defaults are in Bold (Continued)
Values / Range
Three attributes:
- Admin State
- Operational State
- Status
Also, the CFC200 can be Active
or Inactive. When the Inactive
has an Operational status of UP,
it provides traffic switching
capacity (200G) and can take
over if the active CFC has a fault.
(The system is then in Simplex
mode.)
CFC200 Card Attributes and States (SHOW CARD
Description
These three attributes determine the state of the card;
whether it is capable of carrying traffic and the status
(Implied Operational Status)
ONLINE - Card is configured and can provide service.
(UP)
DEGRADED - There is a fault but the card can still pro-
vide service (UP). If this is the status of the active CFC
and the inactive is in an ONLINE status, a switch of activ-
ity may occur.
OFFLINE - The normal status when a card is in a
DOWN state. The card requires a routine operation to
place it ONLINE and available for service. (DOWN)
CARD NOT PRESENT - For the Inactive CFC only, The
card is provisioned and enabled, but the card is not
present.
FAILED - The card has detected a hardware or software
fault that makes it unable to provide service. (DOWN)
The system is now in simplex mode.
NOT INSTALLED - Card is provisioned in software
(CREATE) but not physically present (DOWN)
NOT PROVISIONED - For the inactive CFC200 card,
the card may be physically installed but has not been pro-
visioned in software (CREATE).
RESET - Transient state as card resets (DOWN)
LOADING - The software load is being transferred from
the CFC to the flash memory in the card. (DOWN)
BOOTING - The software load is being copied from the
flash memory into its RAM memory. (DOWN)
INITIALIZING - Card is being initialized as part of
attempt to restore it to service (DOWN)
CONFIGURING - Provisioning data for he card is being
copied from the CFC to the RAM memory on the card.
(DOWN)
TERMINATING - The card is performing an operation in
preparing to go out of service. (UP or DOWN)
