Avaya DEFINITY Server CSI Maintenance Manual page 332

Maintenance Commands
R1:
Message[7,8]
NOTE:
The Link ID has no meaning for the link establish request, therefore the Link
ID field will contain 0xff 0xff
Message[9]
Message[10]
Message[11]
NOTE:
The cancel byte will only be present if the message was built, but could not
be sent.
332
Issue 5 October 2002
= Link ID
= Downlink encode
0x01 - BRI Link Events
0x02 - TEI Management Message
0x03 - XID Message
= BRI Link Events:
0x02 - link release request
0x0f - link establish request sent to and received by
the lower level
= TEI Management Message
0x02 - Identity Assigned
0x04 - Identity Check Request
0x06 - Identity Remove
= XID Messages
0x01 - XID Request
0x02 - XID Response
= 0xCA - Cancel Byte
555-233-119
