monitor system
This field contains a value of 0 or 1 depending related to
Next_hour
measurements taken this hour or the next. This hour reflects
maximum call rates. When this flag is set, statistics accumulate for
the next hour and shortly thereafter.
This field holds the total time slots in use during the time period
tot_ts_req
elapsed since the top of the last hour. Data is internally collected
every 100 seconds. When the timer fires and the data collection
occurs, a check is made as to how many time slots are currently in
use. That's where the total comes from. There are three numbers
displayed for this field on the form; one for each of the pnns
requested. This field represents real-time status data.
This field records total time slots requests denied since the beginning
ts_denied
of the last hour. Data is collected internally every 100 seconds. Three
numbers display for this field; one for each requested pnn. This field
represents real-time status data.
This field represents the total number of requested fiber time slots.
tot_fts_req
This field increments each time a fiber time slots is allocated since the
last top of the hour measurement polling. Three values display; one
for each requested pnn. This field represents real-time status data.
The value in this field represents the requests for time slots during the
ts_count
last 100 second interim. An internal timer initiates polling every 100
seconds. Three numbers display for this field on the form; one for
each requested pnn. This field represents real-time status data.
This field represents the total number of time slots requested since
ts_total
the top of the last hour. This field represents real-time status data.
The value in this field represents the requests for fiber time slots
fts_count
during the last 100 second interim. An internal timer initiates polling
every 100 seconds. Three numbers display for this field; one for each
requested pnn. This field represents real-time status data.
This field indicates the total number of fiber time slots during the last
fts_total
100 second interim. This field represents real-time status data.
This field reflects the total number of requested touch tone receivers
Requests-TN748
TTRs
that are currently-active. It decrements when tone receivers are freed
and increments when they are requested. This field applies strictly to
the TN748 board. This field represents real-time status data.
This field reflects the total number of requested call progress tone
Requests-TN748
CPTRs
receivers that are currently active. It decrements when call progress
tone receivers are freed and increments when they are requested.
This field applies strictly to the TN748 board. This field represents
real-time status data.
