list communication-interface processor-channel
Field descriptions
Proc Chan
Enable
Appl
Gtwy To
Mode
Interface Link
Interface Chan
Destination Node
Destination Port
Session Local
Session Remote
Mach ID
555-233-119
Displays the BX.25 virtual channel number or the TCP/IP listen
port channel to carry this processor (virtual) channel.
Type y to enable a processor channel.
Type n to disable a processor channel.
Identifies the switch application used over this link. The application
gateway is used for conversion between ISDN and either TCP/IP
or BX.25. Use gtwy-tcp for conversion between BX.25 and
TCP/IP. Valid entries are: audix, dcs, fp-mwi, gateway, gtwy-tcp,
mis, msaamwl, msaclk, msahlwc, msallwc, msamcs, qs-mwi, blank
Identifies which processor channel the given processor channel is
serving as a gateway to. Valid entries are a number between
1-(maximum number of processor channels), or blank.
Identifies whether the IP session is passive (client) or active
(server). This field must be blank if the type of interface link is x.25
(r model) or procr-intf (si model). This field cannot be blank if the
type of interface link is ethernet or ppp.
Valid entries are client, server, or blank.
Identifies the physical link carrying this processor (virtual) channel.
Links numbered 1 through (4 times the number of PI circuit packs)
for the si model can be either x.25 or tcp/ip. The rest of the links
(up to 25) must be tcp/ip.
Identifies the BX.25 virtual channel number or the TCP/IP listen
port channel to carry this processor (virtual) channel. The channel
number 0 means any port can be used. Valid entries for link type
x.25 are 1-64; for Ethernet or ppp, 0, 5000-64500.
Identifies the switch or adjunct at the far end of this link. Enter an
adjunct name, switch name, far end IP address, node ID, or leave
blank for services local to this switch.
Identifies the port number of the destination. The number 0 means
any port can be used. Valid entries are 0, 5000-64500.
Field ported forward from R6.
Field ported forward from R6.
Field ported forward from R6.
