INSTALLATION
Install drive shaft assembly by reversing removal procedure and
noting the following points.
D Clean front wheel bearing oil seal and then apply grease.
Replace it if required.
"A": Grease 99000-25010
1. Front wheel bearing
D Install wheel side joint to steering knuckle first and then DOJ to
oil seal
2. Suspension arm
differential side.
D Apply sealant to drain plug for manual transmission.
D Fill transmission with oil as specified.
CAUTION:
D Protect oil seals and boots from any damage, pre-
venting them form unnecessary contact while
installing drive shaft.
D Do not hit joint boot with hammer. Inserting joint
only by hands is allowed.
D Make sure that differential side joint is inserted fully
and its snap ring is seated as it was.
FRONT DRIVE SHAFT 4-11
