monitor egress port: GigabitEthernet2/0/11
remote-probe vlan: 200
Table 1-1 Description on the fields of the display mirroring-group command
Field

mirroring-group

type
status
mirroring port
monitor port
monitor egress port
remote-probe vlan
mirroring-group
Syntax
mirroring-group group-id { local | remote-destination | remote-source }
undo mirroring-group { group-id | all | local | remote-destination | remote-source }
View
System view
Default Level
2: System level
Parameters
group-id: Port mirroring group number, in the range of 1 to 4.
all: Removes All the port mirroring groups.
local: Creates/Removes a local port mirroring group.
remote-destination: Creates/Removes a remote destination port mirroring group.
remote-source: Creates/Removes a remote source port mirroring group.
Description
Use the mirroring-group command to create a port mirroring group.
Use the undo mirroring-group command to remove a port mirroring group.
You need to specify the type of the port mirroring group to be created when creating it.
Use the keyword local to create a local port mirroring group.
Use the keyword remote-destination to create a remote destination port mirroring group.
Use the keyword remote-source to create a remote source port mirroring group.
You need to specify the port mirroring group type or the mirroring group number when removing a port
mirroring group:
Port mirroring group number
Port mirroring group type, which can be local, remote-source,
and remote-destination.
Status of a port mirroring group. "active" for already effective,
and "inactive" for not effective yet.
Source mirroring port
Destination mirroring port
Outbound mirroring port
Remote mirroring VLAN
1-2
