Refer to Table 1-5

port hybrid protocol-vlan

Syntax
port hybrid protocol-vlan vlan vlan-id { protocol-index [ to protocol-end ] | all }
undo port hybrid protocol-vlan { vlan vlan-id { protocol-index [ to protocol-end ] | all } | all }
View
Ethernet interface view, port group view, Layer-2 aggregate interface view,
Default Level
2: System level
Parameters
vlan vlan-id: Specifies a VLAN ID, in the range 1 to 4094.
protocol-index: Protocol index, in the range 0 to 15, specified by the users or assigned by the system
automatically when the protocol-based VLAN is created. You can use the display protocol-vlan vlan
all command to display the protocol indexes.
to protocol-end: Specifies the end protocol index. The protocol-end argument must be greater than or
equal to the beginning protocol index. The range of the protocol-end argument varies with device
models.
all: Specifies all protocols bound with vlan-id.
Description
Use the port hybrid protocol-vlan vlan command to associate the hybrid port(s) with a protocol-based
VLAN.
Use the undo port hybrid protocol-vlan command to remove the association.
In Ethernet interface view, this command only applies to the current port.
In port group view, this command applies to all ports in the port group. For information about port
groups, refer to Ethernet Interface Configuration in the Access Volume.
In Layer-2 aggregate interface view, this command applies to the Layer-2 aggregate interface and
all its member ports. After you perform the configuration, the system starts applying the
configuration to the aggregate interface and its aggregation member ports. If the system fails to do
that on the aggregate interface, it stops applying the configuration to the aggregation member ports.
If it fails to do that on an aggregation member port, it simply skips the port and moves to the next
port. For information about Layer-2 aggregate interfaces, refer to Link Aggregation Configuration in
the Access Volume.
Before issuing this command, make sure that you have made the following configurations:
Create a VLAN and associate it with specified protocols.
Configure the link type as hybrid.
Configure the port to allow the protocol-based VLAN to pass through.
for description of the output.
1-24
