Uni Mirroring-Port - 3Com S7906E Command Reference Manual

Default Level
2: System level
Parameters
group-id: Port mirroring group number, in the range of 1 to 4.
Description
Use the monitor-port command to configure a port as the destination mirroring port of a port mirroring
group.
Use the undo monitor-port command to remove the destination mirroring port from a port mirroring
group.
If you do not specify the mirroring-group group-id keyword-argument combination, the monitor-port
command adds the current port to port mirroring group 1.
Note that:
If you do not specify the mirroring-group group-id keyword-argument combination, these two
commands apply to port mirroring group 1.
A remote source mirroring group cannot contain destination mirroring ports.
Member ports of existing port mirroring groups cannot be destination ports.
The remote destination mirroring port can be an access, trunk, or hybrid port. It must be assigned
to the remote mirroring VLAN.
Before adding the destination port for a port mirroring group, make sure the port mirroring group
exists.
Do not enable STP, RSTP, or MSTP on the destination port. Otherwise, the mirroring function may
be affected.
Do not use the destination mirroring port for any purpose other than port mirroring.
Examples
# Add port Ethernet 2/0/1 to port mirroring group 1 (a local port mirroring group) as the destination port.
<Sysname> system-view
[Sysname] mirroring-group 1 local
[Sysname] interface Ethernet 2/0/1
[Sysname-Ethernet2/0/1] monitor-port

uni mirroring-port

Syntax
uni uni-number mirroring-port { both | inbound | outbound }
undo uni uni-number mirroring-port
View
ONU port view
Default Level
2: System level
1-8
