8100 V2 Modules Series

Portable, modular platform

designed for the construction,

validation and maintenance of

optical fiber networks

User Manual

Table of Contents

Advertisement

Table of Contents

Troubleshooting

Need help?

Need help?

Do you have a question about the 8100 V2 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Viavi 8100 V2 Series

Page 1 8100 V2 Modules Series Portable, modular platform designed for the construction, validation and maintenance of optical fiber networks User Manual...
Page 3 8100 V2 Modules Series Portable, modular platform designed for the construction, validation and maintenance of optical fiber networks User Manual Viavi Solutions 1-844-GO-VIAVI www.viavisolutions.com...
Page 4 User Manual XXXXXXXXX Rev. ???
Page 5 Every effort was made to ensure that the information in this document was accurate at the time of printing. However, information is subject to change without notice, and VIAVI reserves the right to provide an addendum to this document with information not available at the time that this document was created.
Page 6 In the Euro- pean Union, all equipment and batteries purchased from VIAVI after 2005- 08-13 can be returned for disposal at the end of its useful life. VIAVI will ensure that all waste equipment and batteries returned are reused, recy- cled, or disposed of in an environmentally friendly manner, and in compli- ance with all applicable national and international waste legislation.
Page 7: Table Of Contents
Contents About this guide xxxiii Purpose and scope ......... xxxiv Assumptions.
Page 8 Contents Chapter 2 Getting started Unpacking the device - Precautions ......12 Laser Safety instructions .
Page 9 Contents Selecting the Smart Test function ......26 Principle of the Smart Test........26 Selecting Smart Test .
Page 10 Contents Common functions ......... . . 68 Display of events on the trace .
Page 11 Contents Saving results in Smart Test mode ......100 Saving results and creating a report in Expert OTDR mode ..102 Opening a report .
Page 12 Contents Configuring the Reflectometry test for FTTA network ... .128 FTTA setup ........... . .129 Alarms parameters .
Page 13 Contents Files and Project storage ........164 Text file content .
Page 14 Contents Setting the zero value of the power meter ..... 189 Carrying out the reference ........189 Carrying out the side by side reference .
Page 15 Contents Saving results and creating a report from results page ... 209 Opening a report ..........211 Recalling OEO traces .
Page 16 Contents OTDR ............237 Saving results and generating a report .
Page 17 Contents Display functions ..........262 Zoom function .
Page 18 Contents EDFA measurements ........279 EDFA results .
Page 19 Contents Analysis parameters ......... 312 Channel Detection .
Page 20 Contents Chapter 10 Polarization Mode Dispersion Measurement Recommended equipment ........334 PMD Activation and self calibration .
Page 21 Contents Chapter 11 I-PMD Measurement Recommended equipment ........358 I-PMD Activation and Configuration .
Page 22 Contents PMD standards and limits ........379 Chapter 12 High Resolution OSA Measurement Cleaning of Connectors .
Page 23 Contents Principle of "On/Off-OSNR Measurement" ..... .400 Setup ............401 Limitations .
Page 24 Contents Trace display ..........418 Spectrum/Profile .
Page 25 Contents Functions available ......... . 441 Delay / Dispersion / Slope .
Page 26 Contents IL/ORL referencing ......... . 463 IL/ORL referencing with the integrated FiberComplete®...
Page 27 Contents Fiber Characterization with FC1 Test Kit (Unidirectional) ..479 Selecting data storage directory........479 Launching the Link Characterization script .
Page 28 Contents Configuring the LTS ......... 499 Configuring the alarm parameters .
Page 29 Contents Creating a report from results page......519 Opening a report ..........520 File Management .
Page 30 Contents Directory and files editing function ......535 Saving and loading files ........535 Saving Files from the Explorer .
Page 31 Contents B, C & D Modules ..........552 A Modules .
Page 32 Contents Appendix A RoHS Information Concerned products: 8100 V2 modules series ....576 Concerned products: OTDR 8100 V2 Modules Series ....577 Concerned products: OTDR VLR 8100 V2 Modules Series .
Page 33: About This Guide
About this guide The MTS/TBERD series of Viavi provides a portable, modular platform designed for the construction, validation and maintenance of optical fiber networks. The modules described in this document are applicable for the following platforms: • MTS 8000 •...
Page 34: Purpose And Scope
This guide includes task-based instructions that describe how to install, configure, use, and troubleshoot the Product Name/Family Brand. Additionally, this guide provides a complete description of Viavi’s warranty, services, and repair informa- tion, including terms and conditions of the licensing agreement.
Page 35: Conventions
About this guide Conventions Conventions This guide uses naming conventions and symbols, as described in the following tables. Table 1 Typographical conventions Description Example User interface actions appear in this typeface. On the Status bar, click Start Buttons or switches that you press on a unit Press the switch.
Page 36 About this guide Conventions Table 3 Symbol conventions CAUTION This symbol represents a general hazard. DANGER This symbol represents a risk of electrical shock NOTE This symbol represents a Note indicating related information or tip. This symbol, located on the equipment or its packaging, indicates that the equipment must not be disposed of in a land-fill site or as municipal waste, and should be disposed of according to your national regulations.
Page 37: Principles Of Measurement
Principles of measurement Chapter 1 This chapter gives the principles of the measurements made by the reflectometer (OTDR) plug-ins, OSA spectrum analyzers (WDM technology) and PMD analyzers (Polarization mode dispersion). The topics discussed in this chapter are as follows: • “Principle of reflectometry measurements”...
Page 38: Principle Of Reflectometry Measurements
Chapter 1 Principles of measurement Principle of reflectometry measurements Principle of reflectometry measurements Optical time domain reflectometry consists in injecting a light pulse into one end of the optical fiber to be analyzed and observing, at the same end, the optical intensity passing through the fiber in the opposite direction to the propagation of the pulse.
Page 39: Validity Of Measurement
Chapter 1 Principles of measurement Principle of reflectometry measurements To locate faults, a reflectometer measures only time. Consequently, group velocity must be introduced in order to determine the distance of the loca- tion. This is done by introducing the refractive index of the fiber into the instrument.
Page 40: Principle Of Bi-Directional Measurement
Chapter 1 Principles of measurement Principle of bi-directional measurement • typical values of the backscatter coefficient for a pulse of 1 ns and – for a single-mode fiber: -79 dB to 1310 nm -81 dB to 1550 nm and 1625 nm –...
Page 41: Principle Of The Optical Power And Attenuation Measurements
Chapter 1 Principles of measurement Principle of the optical power and attenuation measurements Figure 3 Positive splice (A ->B) / Negative Splice (B -> A) The sum gives the bi-directional or average splice loss value: ------------------ - Bi-directionnal measurement consists in performing a measurement from the extremity of fiber A, then another measurement from the extremity of fiber B, finally get events of both traces and calculate the average for all slope, splice and reflectance measure- ments.
Page 42 Chapter 1 Principles of measurement Principle of the optical power and attenuation measurements Laser light Power meter source of the Reference Platform 8000 Link under test fiber Attenuation A = P1 - P2 (dB) (dBm) (dBm) To perform accurate measurements, the following conditions are vital •...
Page 43: Pmd Principle
Chapter 1 Principles of measurement PMD principle PMD principle The transmission rate and range are two of the most important parameters of fiber optics paths and must therefore be optimized. And, since more and more paths (including those already installed) are being used for transmitting Wavelength Division Multiplex (WDM) signals or for bit rates of 10 Gbit/s, it is becoming all the more important to deter- mine the Polarization Mode Dispersion (PMD).
Page 44 Chapter 1 Principles of measurement PMD principle Figure 5 Fixed Analyzer Method used to measure the PMD Broadband Fixed Rotatable Optical Spectrum light source Polarizer Analyzer (OSA) Polarizer Link under test (SLED) The method used to measure PMD is the Fast Fourier Transform Method (FFT). From the spectrum, the mean period of the amplitude modulation is measured.
Page 45: Phase Shift Method
Chapter 1 Principles of measurement Principle of measurement of Chromatic Dispersion (CD ODM) using phase shift method Principle of measurement of Chromatic Dispersion (CD ODM) using phase shift method The Phase shift method A modulated broadband light is sent over the Fiber Under Test. The phase of the test signal is compared to the phase of the reference signal.
Page 46 Chapter 1 Principles of measurement Standards and l0 for different types of fiber Most suitable method of approximation according to trace zone Single Mode Fiber ITU-T Wavelength Range Approximation Type Dispersion unshifted G.652 around 1310 nm 3-term Sellmeier fiber (standard fiber) 1550 nm region Quadratic Full wavelength range...
Page 47: Getting Started
Getting started Chapter 2 This chapter describes how to start using the T-BERD/MTS 8000 V2 or T-BERD/MTS 6000/6000A V2. The topics discussed in this chapter are as follows: • “Unpacking the device - Precautions” on page 12 • “Laser Safety instructions” on page 12 •...
Page 48: Unpacking The Device - Precautions
Using the original packing material ensures that the device is properly protected during shipping. If another packaging is used (for returning the equipment for example), Viavi cannot give warranty on good protection of the equipment.
Page 49 Chapter 2 Getting started Laser Safety instructions Ref. EN 60825-1, Edition 1.2, 2001-08 FDA21CFR§1040.10 standard CLASS 1 Class 1 LASER PRODUCT Class 1M Class 2 Measurements on optical fibers are difficult to execute and the preci- sion of the results obtained depends largely on the precautions taken by the user.
Page 50: Ac/Dc Safety Information
AC/DC safety information Do not use any mains adaptor other than the one supplied with the instrument, or supplied by Viavi as an option for this instrument. If another adapter is used, it may damage the Product Name/Family Brand/ T-BERD/ MTS-6000A V2 itself.
Page 51: Installing A Module In A Receptacle And Removing It
Chapter 2 Getting started Installing a module in a receptacle and removing it Installing a module in a receptacle and removing it With the T-BERD/MTS-8000 V2, a module may be inserted into either of the two slots provided for the purpose. With the T-BERD/MTS-6000/6000A, only one module may be installed into the Platform.
Page 52: Removing A Module
Inspecting and cleaning connector end faces Always inspect and clean the connector end face of the optical fiber cable and the test port before mating both together. Viavi is not responsible for damage and reduced performance caused by bad fiber handling and cleaning. •...
Page 53: Optical Connector Types
Chapter 2 Getting started Connecting fiber optic cable Figure 8 "Inspect Before You Connect" process Optical connector types There are many optical connectors in the market place. Always ensure to use a high quality connector that meets the international standards. Two main types of connectors are deployed in the telecommunication industry: Straight polished connectors, so called PC or UPC Angled polished connectors, so called APC...
Page 54 Figure 10 PC/APC bad connection WARNING Viavi declines responsibilities of connector damages if a poor quality con- nector is used or APC to PC connections made. Test port connector repair will be charged User Manual...
Page 55: Connecting Fiber Optic Cable To Test Port
Chapter 2 Getting started Optical connectors and interchangeable adapters WARNING All the universal connectors are available on the OTDR Modules, except on the LA Module. Connecting Fiber optic cable to test port After ensuring proper cleaning of both end connectors, follow the below steps in order to correctly and safely connect the optical fiber into the test port: Carefully align the connector and test port to prevent the fiber end from touching the outside of the port and scratching the end face.
Page 56: Adapter Types
Optical connectors and interchangeable adapters Adapter types Viavi offers 5 different adapters, all compatible with this connector, allowing the user to switch from one adapter to another according to which fiber type he intends to work with. Adapter types supplied are: FC, SC, DIN, ST and LC.
Page 57: Display Screen
Chapter 2 Getting started Display screen Display screen The display screen is divided into a number of different zones. Starting from the top, these are: a status bar in which various icons indicate the current functions: a bar displaying a scaled-down representation of the trace, showing the zoom zone and the parameters of the measurement on display (signature of the measurement).
Page 58: Top Status Bar
Chapter 2 Getting started Display screen Top status bar The top status bar on the screen shows, on the right, current date and time, and in the form of icons: • the type of power supply: mains or battery, and if the power supply is on battery the level of charge (see Battery management in chapter 2 from the Platform manual) •...
Page 59: Main Display Zone
Chapter 2 Getting started Display screen Main display zone The central zone of the screen can display the configuration of the instrument or the measurement, the memory explorer of the Platform , the measurement results, etc. Refer to the chapter dealing with the measurement in progress. Tabs When the instrument performs several different functions (OTDR, PMD, Power Meter, etc.), the various configuration or results pages are accessible from tabs.
Page 60: Soft Keys
Chapter 2 Getting started Display screen • Green icon: the function has been selected and the corresponding module currently performs an acquisition. Soft keys The 7 softkeys at the side depend on the current configuration and the context. Their use is symbolized by an icon. Icons shows that the action is immediate when the key is pressed.
Page 61: Reflectometry Measurements
Reflectometry measurements Chapter 3 Pressing the S key is all that is needed to start or stop a measurement. TART However, it is necessary to configure the measurement and the type of results desired. This chapter describes the different stages in a reflectometry measurement made using an OTDR module.
Page 62: Activating The Otdr Function
Chapter 3 Reflectometry measurements Activating the OTDR function Activating the OTDR function Once the OTDR module is correctly set onto the equipment and the T-BERD/MTS is switched on, the desired OTDR function must be selected before any OTDR configura- tion, or measurement. Selecting the Smart Test function Principle of the Smart Test The Smart Test is used to perform OTDR acquisitions using a pre loaded configuration...
Page 63: Selecting The Expert Otdr Function
Chapter 3 Reflectometry measurements Activating the OTDR function The icon turns yellow NOTE The selection of Smart Test icon automatically deselects the Expert OTDR icon and vice-versa. NOTE In the case a Singlemode/Multimode module, one line contains the Multi- mode icons and a second one the Singlemode icons. To distinguish both modes, multimode icons contain the MM mark.
Page 64: Configuring The Reflectometry Test
Chapter 3 Reflectometry measurements Configuring the reflectometry test NOTE In the case a Singlemode/Multimode module, one line contains the Multi- mode icons and a second one the Singlemode icons. To distinguish both modes, multimode icons contain the MM mark. Configuring the reflectometry test Configuring the unit for Smart Test Once the Smart Test icon is validate, press S ETUP...
Page 65: Selecting The Configuration File
Chapter 3 Reflectometry measurements Configuring the reflectometry test Selecting the configuration file To load the configuration file to be used for Smart Test test: If necessary, click on the button to display the superior level of the direc- tory. In the selection file screen, select the configuration file to be used for the acquisi- tion on Smart Test mode.
Page 66 Chapter 3 Reflectometry measurements Configuring the reflectometry test Figure 17 Smart TestSetup page • Laser The acquisition will be carried out on the wavelength(s) selected (for multiple-wavelength modules). In case of a multi- wavelength module, select All to perform a measurement for all the wavelengths available (this parameter visible exclusively on modules with one single OTDR port).
Page 67: Configuring The Test In Expert Otdr
Chapter 3 Reflectometry measurements Configuring the reflectometry test • Alarms Define if alarms thresholds must be applied for the acquisition: Select No if no alarm thresholds must be applied. Select Yes to define alarms, and press Alarm Level to define the pre-defined thresholds for the acquisition.
Page 68: Configuring The Acquisition Parameters
Chapter 3 Reflectometry measurements Configuring the reflectometry test Figure 18 OTDR Setup screen In these windows, the parameter selected is in video inverse. Configuring the Acquisition parameters You can choose the OTDR acquisition parameters. Once the Setup page is displayed, press Acquisition menu key to configure the Acquisition parameters.
Page 69 Chapter 3 Reflectometry measurements Configuring the reflectometry test Laser The acquisition will be carried out on the wavelength(s) selected (for multiple-wave- length modules). In case of a multi-wavelength module, select All to perform a measure- ment for all the wavelengths available (this parameter visible exclusively on modules with one single OTDR port).
Page 70 Chapter 3 Reflectometry measurements Configuring the reflectometry test In the case of a multi wavelength acquisition: – you can define a pulse for each wavelength: select each wavelength in the Laser line and define a pulse Once all lasers are configured, go back to the pulse line and select Multi. –...
Page 71 Chapter 3 Reflectometry measurements Configuring the reflectometry test Manual Enter the acquisition time desired (from 5 s. to 5 minutes max). Predefined Select one of the acquisition times predefined: 10 seconds / 20 seconds / 30 seconds / 1 minute / 2 minutes / 3 minutes. If the option OptiPulse is available, see “Configuring the OTDR acquisition with Opti- Pulses mode”...
Page 72: Configuring The Alarms Parameters
Chapter 3 Reflectometry measurements Configuring the reflectometry test Figure 19 Launch Cable / Receive Cable Launch Cable Receive Cable Fiber Under Test OTDR Launch Receive Cable end Cable start Distance of the Distance of the launch cable receive cable Include Link Start Connector / Include Link End Connector Defining the Launch Cable End parameter with an event number or a distance will auto- matically activate the corresponding parameter Include Link Start Connector.
Page 73 Chapter 3 Reflectometry measurements Configuring the reflectometry test Alarms > Threshold None The alarm function is not active. Fail This menu lists possible major alarm thresholds that the user could select. If results are above those thresholds, they will be highlighted in red in the table of results, and the icon will appear at the top right of the screen.
Page 74: Configuring The Analysis Parameters
Chapter 3 Reflectometry measurements Configuring the reflectometry test Table 2 Multimode Modules Default TIA-568C & ISO/IEC 11801 Splice Loss > 0.20 dB > 0.30 dB Connector Loss > 0.50 dB > 0.75 dB Slope 850 nm > 3.50 dB/km > 3.50 dB/km Slope 1300 nm >...
Page 75 Chapter 3 Reflectometry measurements Configuring the reflectometry test None The section attenuation and Loss values are not displayed in the table of results. Section Length Choose to display or not the section length in the table of results. Index of refraction Choice of group refraction index of the whole fiber.
Page 76 Chapter 3 Reflectometry measurements Configuring the reflectometry test Wavelength (nm) 1310 SM 1360 - 1510 SM 1550 SM 1625 - 1650 SM Corning SMF-28 1.46750 1.46810 1.46810 1.46810 Corning SMF-DS 1.47180 1.47110 1.47110 1.47110 Corning SMF-LS 1.47100 1.47000 1.47000 1.47000 Corning-Leaf 1.46890 1.46840...
Page 77 Chapter 3 Reflectometry measurements Configuring the reflectometry test In Multimode, two predefined scatter coefficients are available: – Generic 50: 850 MM - > -66.3 dB 1300 MM -> -73.7 dB – Generic 62.5: 850 MM -> -66.1 dB 1300 MM -> -70.3 dB The default values are given in the paragraph “Reflectance”...
Page 78 Chapter 3 Reflectometry measurements Configuring the reflectometry test Detection Splice Select if a level of detection for splice must be defined. Press Edit Number soft key and select a value: – Enter a min level of detection, from 0.01 to 1.99 dB –...
Page 79: Configuring The Link Parameters
Chapter 3 Reflectometry measurements Configuring the reflectometry test Event After Fiber End If Yes, the events after the end of the link are detected. Total Loss Before evt for a given line on table, the total loss result does not include the splice/connector loss of the corresponding line After evt on the table, for a given line, the total loss measurement on the table...
Page 80 Chapter 3 Reflectometry measurements Configuring the reflectometry test The fiber code corresponds to the fiber color if, in the Cable Structure, the parameter Color coding is defined on Yes. Select the parameter Fiber Number/Fiber Code and modify the parameter using the left and right direction keys.
Page 81 Chapter 3 Reflectometry measurements Configuring the reflectometry test Note: to decrement the number, enter the sign «-» before the number. Example: - Min: -999 / Max: 999 / Auto: 0 the Fiber number must not automatically modified. Extremities are different In some cases, it is interesting to save different information for the origin and the extremity of the cable.
Page 82 Chapter 3 Reflectometry measurements Configuring the reflectometry test Figure 23 Cable structure menu NOTE The Cable Structure window is specific to an extremity. Each structure keeps its own parameters by default. Modifications made to the one are not automatically applied to the other. Thus, after the values relating to the origin have been modified, it is normal not to find these same values entered for the extremity.
Page 83 Chapter 3 Reflectometry measurements Configuring the reflectometry test – Tube/Ribbon/Fiber The color code of the fiber is preceded by that of the tube, then by that of the ribbon; the three being separated by a ’/’ (example: ’Br/Bl/Or’). See “Fiber Code / Fiber Num” on page 133.
Page 84: Configuring The File Parameters
Chapter 3 Reflectometry measurements Configuring the reflectometry test Figure 24 Color code definition Project Information Technician Id Use the arrow to enter the name of the operator carrying out the measurement. Job Id Use the arrow to enter a description of the measurement to be performed. Comment In contrast to the other data in this menu, the comment is specific to a fiber.
Page 85 Chapter 3 Reflectometry measurements Configuring the reflectometry test NOTE The softkey Copy File/Link To all is displayed when one parameter is selected in the Link or File Setup page and when the Powermeter or Source function is active. It allows to apply the Link and File configuration parameters of the current applications to all the other active Fiber Optic applications (powermeter, and source).
Page 86 Chapter 3 Reflectometry measurements Configuring the reflectometry test Press Default Filename to apply the name by default to the file: (hard)disk/[Cable_Id] Press Clear and validate (Enter key) in order to define the [Current directory] selected as directory for saving measurements. This parameter cannot be configured, and display the directory selected by default into which the file(s) will be saved.
Page 87 Chapter 3 Reflectometry measurements Configuring the reflectometry test Fiber[Cable_Id][Fiber_Num]_[Lambda]_[Direction][Pulse] The name of the file is displayed in grey under Filenaming parameter File Content In this parameter, select the file content for traces saving: One Trace in case of traces in overlay, each trace is saved in a distinct file (.sor extension).
Page 88: Configuration In Test Auto Mode
Chapter 3 Reflectometry measurements Configuring the reflectometry test Consolidated in multi-traces display, one report page is generated for all traces Report naming Select Report naming parameter and press the right arrow key to modify the name of the report file for the result trace. In the edition keypad, enter a name manually for the file and press Enter to validate.
Page 89: Saving Otdr Configuration In A File
Chapter 3 Reflectometry measurements Configuring the reflectometry test Acquisition Laser CQUISITION Reflectance Ghost Fiber End Auto Bend Auto Event After Fiber End Total Loss Before evt. Link Description Change Fiber Nr Increment Dir. Naming [Current Dir.] EPORT File configuration Filenaming Auto filenaming Fiber[Cable_Id][Fiber_Num]_[Lambda]_[Direction] Auto Store...
Page 90: Loading An Existing Otdr Configuration File
Chapter 3 Reflectometry measurements Configuring the reflectometry test Figure 27 Save Configuration file - Edition keypad Directory into which file is saved NOTE Configuration file is saved in the directory config, into the disk. Press Enter to validate A sound is emitted to indicate the file is saved. The configuration file is saved with the extension ".fo_cfg"...
Page 91 Chapter 3 Reflectometry measurements Configuring the reflectometry test • Press S hard key to display the OTDR acquisition parameters saved in the ETUP selected configuration file. You can modify some acquisition or file storage parameters, and save them in a new configuration file (see “Saving OTDR configuration in a file”...
Page 92: Traffic Detection And Connection Quality Indicator
Chapter 3 Reflectometry measurements Traffic Detection and connection quality indicator Traffic Detection and connection quality indicator Traffic Detection Traffic on the fiber under test is automatically detected and reported. Press the S key to begin the measurement. TART A message indicates there is traffic on the fiber and asks you if you wish to continue or not: •...
Page 93: Performing Otdr Acquisitions
Chapter 3 Reflectometry measurements Performing OTDR acquisitions Table 3 Quality of connection Possible causes of a bad result: - There are several connectors close to the external connector of the T-BERD/ MTS. - One of the connectors is dirty or badly connected. Replace the launch cable, make the connection again properly or clean the connector of the OTDR or of the jumper.
Page 94 Chapter 3 Reflectometry measurements Performing OTDR acquisitions • Hold the S key down for about three seconds, to launch the acquisition in TART real time, either in Smart Test or Expert OTDR mode, whatever is the acquisition mode selected. If the Time parameter is defined with Real Time in Setup page in Expert OTDR mode, press S hard key.
Page 95: Stopping The Real Time Acquisition
Chapter 3 Reflectometry measurements Performing OTDR acquisitions NOTE During acquisition, the traffic on fiber is automatically detected (see “Traffic Detection” on page Stopping the real time acquisition To stop an acquisition in real time mode, press the S key at any time. TART Performing a measurement with Smart Test The acquisition is carried out with the parameters saved in the Configuration file.
Page 96: Performing An Acquisition With Expert Otdr
Chapter 3 Reflectometry measurements Performing OTDR acquisitions At the end of the acquisition, a beep is emitted, and the measurements are displayed in SLM view, NOTE During acquisition, the traffic on fiber is automatically detected (see “Traffic Detection” on page Performing an acquisition with Expert OTDR In this mode, the T-BERD/MTS carries out a number of averagings defined as a function of the maximum acquisition time specified in the Acquisition menu, and then terminates...
Page 97: Performing An Acquisition From Results Page
Chapter 3 Reflectometry measurements Performing OTDR acquisitions Figure 31 Acquisition in progress with Expert OTDR Elapsed Number of averages Elapsed Total acquisition acquisition time calculated time time At the end of the acquisition, a beep is emitted, the trace is displayed and an automatic measurement is started.
Page 98: Multi-Wavelength Acquisition
Chapter 3 Reflectometry measurements Performing OTDR acquisitions CAUTION Before launching a new OTDR acquisition, make sure the trace(s) displayed have been previously saved if necessary, as the new acquisition will auto- matically delete the displayed results. On Results page,in Expert OTDR mode, press the softkey Quick Setup: the acquisition parameters to be modified are displayed under the results trace.
Page 99: Actions On Trace During Acquisition
Chapter 3 Reflectometry measurements Performing OTDR acquisitions Once the acquisition for the first wavelength is finished, the acquisition for the following wavelength starts automatically. To stop manually the acquisition for current wavelength, click on Stop Wave- length. This will allow to automatically start the measurement for the following wavelength.
Page 100 Chapter 3 Reflectometry measurements Performing OTDR acquisitions Displaying Trace or SmartLink page Use the menu key Trace/SmartLink to display either: • the acquisition trace in progress and the bar graph of time • the SmartLink page with exclusively the bar graph of time. In the case of measurement on several wavelengths, once a measurement is completed for one wavelength: •...
Page 101: Saving Results For Smart Test Acquisitions
Chapter 3 Reflectometry measurements Saving results for Smart Test acquisitions Zooming on the fiber end (in Real Time mode only) During a real time acquisition, you can reach the end of the fiber under test at any time: Press Zoom to End menu key. The display automatically reaches the end of the fiber under test.
Page 102 Chapter 3 Reflectometry measurements Saving results for Smart Test acquisitions The Recording Information page displays Figure 35 Save results in Smart Test mode Click on one parameter configuration (white background) to modify it using the edition or numeric keypad displayed: –...
Page 103: Results Display
Chapter 3 Reflectometry measurements Results display Once the recording information are defined as wished, select the saving mode wished: – Click on FILE ONLY to save exclusively the results trace to the .sor format – Click on FILE + PDF to save the results trace in a .sor file and to generate a pdf report of the results.
Page 104: Common Functions
Chapter 3 Reflectometry measurements Results display • On the upper right side, the alarm icon is displayed (if some alarm thresholds are defined in the pre loaded configuration file or in the Setup screen in Expert OTDR mode). Table 4 Alarms display Indicates that at least one result exceeds the alarm thresholds Fail...
Page 105: Results Table
Chapter 3 Reflectometry measurements Results display The following table gives some examples of detection of events for different threshold values. The T-BERD/MTS displays a value if the Value of the thresholds attenuation or the reflectance has one of the E.g. following values Attenuat.
Page 106 Chapter 3 Reflectometry measurements Results display Expert OTDR Mode Figure 37 Trace + Table results in Smart Test In Expert OTDR mode, once Trace is selected, press validation key to pass from Trace + results table on 1 line to Trace + results table on 8 lines, and vice-versa The table with one line displayed under the trace gives the type and characteristics of the event nearest to the cursor.
Page 107 Chapter 3 Reflectometry measurements Results display Figure 38 Example of trace and results table in Expert OTDR At the top of the table, a line shows the generic parameters of the fiber: numbers of events present, total ORL of the link and, in Expert OTDR mode, reference trace icon (if trace is the reference trace - see “Reference Trace function”...
Page 108 Chapter 3 Reflectometry measurements Results display Event marker when a measurement cannot be carried out. If the event to be added is too close to an existing event, the icon appears on the trace and the table, but no measurement is carried out: to obtain the results for this event, a manual measurement is necessary.
Page 109: Cursors
Chapter 3 Reflectometry measurements Results display The distance of the event from the beginning of the fiber, in Distance meters (or miles) Loss The attenuation due to the event, in dB Reflect. The reflectance of the event, in dB Slope The slope before the event, in dB/km (or dB/kft) if it can be (Expert OTDR only) measured...
Page 110 Chapter 3 Reflectometry measurements Results display When the cursor function is selected, the keys move the trace vertically. Cursors information The information related to cursors are displayed exclusively when the Cursor function is selected (menu key selected). Above the trace are shown the co-ordinates of the points of intersection of the cursors A and B with the trace, together with the distance between the two points.
Page 111: Zoom Function
Chapter 3 Reflectometry measurements Results display If another key than the key Cursor A / Cursor B is activated when the validation key is pressed (Trace or Zoom), the cursors’ position is unchanged. Cursor function not selected When Cursor menu key is not selected, the upper banner displays information, different according to the menu key selected: •...
Page 112 Chapter 3 Reflectometry measurements Results display Figure 41 Zoom on trace using touchscreen First Zoomed area Second press Defining a zoom level on the trace using direction keys Select Cursor A or B and center it on the zone to be examined Press Zoom softkey in Smart Test or select the Zoom function on key Zoom/...
Page 113: Shift Function (Expert Otdr Only)
Chapter 3 Reflectometry measurements Results display • once a zoom is performed, double click on the zoomed zone to undo the zoom Zooming on the different events in succession Zoom on one of the events detected as shown above. On the Trace/Summary key, select the Trace function. Use the keys to move the zoom on to the successive events.
Page 114 Chapter 3 Reflectometry measurements Results display Figure 42 Traces in overlay Selecting one trace from overlaid traces To make actions on a trace in overlay (move on events, set a cursor...), it must first be swapped with the active trace. To do this: Press the Trace key Press the direction keys , as many times as necessary,...
Page 115: Traces Display In Double Acquisition Mode
Chapter 3 Reflectometry measurements Results display Traces display in double acquisition mode When a double acquisition has been performed, i.e. a short acquisition preceding a stan- dard one (see page 33), two traces are displayed in the same window. Figure 43 Traces display in double acquisition mode Standard acquisition (in green)
Page 116 Chapter 3 Reflectometry measurements Results display Figure 44 SmartLink function Zone 1 Zone 2 Zone 3 The screen is divided into three zones: • Zone 1: Graphical representation of the link, with icons symbolizing the different events detected. Receive Cable End Cable Splice Splitter...
Page 117: Show The Detailed Information Of One Event
Chapter 3 Reflectometry measurements Results display Front OTDR connector Merged connectors • Zone 2: Link Table, which gives a summary of results for each wavelength, with results within/without thresholds in green/red (according to Alarm thresholds defined in the setup screen). •...
Page 118: Event View
Chapter 3 Reflectometry measurements Results display Event View Click on Event View menu key to display a detailed description of one event detected on trace. Select the event to be described on the graphic (underlined in yellow). The corresponding event description is displayed on the Zone 3, with a recall of alarm threshold for this event: Figure 46 SmartLink: Event View...
Page 119 Chapter 3 Reflectometry measurements Results display Press Event Code menu key Click on the event type to be applied to the selected event: Figure 47 Event Code Click on one event code to modify the selected event Click on Exit to return to Event View. Click back on Event View menu key to return to Summary screen Click on Trace View menu key to return to trace (+ table) screen.
Page 120: Results Table (Smart Test Mode)
Chapter 3 Reflectometry measurements Results display Moreover, the icon and splitter configuration is different according to the number of «clicks» on one menu key. Example with the menu key • Click once: the icon is • Click twice: the icon is •...
Page 121: Advanced Functions In Expert Otdr Mode
Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode Advanced functions in Expert OTDR mode Several actions on trace displayed can be performed in Expert OTDR mode only. Automatic measurement and detection If the instrument does not detect all the expected events, additional manual measure- ments can be carried out.
Page 122: Relative Measurement
Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode Select a cursor (A or B). Use the direction keys or touchscreen to move the cursor to the place where you want to position a marker. Press the keys: Advanced > Event.
Page 123: Modifying Types Of Events
Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode Modifying types of events The types of events are detected automatically as a function of their optical signature. This can sometimes lead the system astray, if reflection from a connector is too strong (end of fiber?), if a splice has a very low insertion loss (slope?), etc.
Page 124 Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode Splitter sub-menus The Splitter icon is different according to the menu key pressed in the Splitter sub- menus. Example: If the menu key is pressed, the icon is displayed If the menu key is pressed, the icon is displayed.
Page 125 Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode NOTE Each note is associated with an event. Consequently, if the event is deleted, the note will be deleted too. To enter a note: In the menu: Setup > Analysis > Event Notes, the Notes option must be selected On the Results page, in the table, select the event Press Advanced...
Page 126: Manual Measurements
Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode NOTE The S menu > Analysis > Event Notes line enables display of notes, of ETUP uncertainties or of neither the one nor the other. Notes cannot be displayed at the same time as uncertainties. Manual measurements As soon as you have made an acquisition, with or without automatic measurement, you can make manual measurements on any event on the trace by means of the cursors A...
Page 127 Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode Figure 50 Manual Measurement results Slope Result of slope measurement The result is displayed on the screen between the two slope indicators [ and ]. The measurement results are also available in the table: Press Exit to return to the initial results page.
Page 128: Measurement Of Orl
Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode Select Slope (after, if necessary, pressing Advanced > Modify Meas. > Manual Meas.). Press validation key : the slope of the specified trace section is deleted. Measurement of ORL It is possible to carry out an ORL measurement on a part of the fiber. Follow the following procedure to measure a part of the fiber: Position the cursors A and B to delimit the section that you wish to measure.
Page 129: Measurement Of Reflectance
Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode Measurement of Reflectance It is possible to carry out a reflectance measurement of a Fresnel for a reflective event. Follow the following procedure to measure the reflectance: Position the cursor A at the base of the peak Position the cursor B at the top of the peak of the required Fresnel, or after the peak to calculate automatically the maximum reflectance.
Page 130 Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode If very close events have created a dead zone preventing the measurement of slope by the five-cursor method, it is possible to use the two-cursor method. This considers the difference in level between the cursors. Before performing one of these measurements, define in the Setup menu the splice detection threshold.
Page 131: Memorization Of The Position Of Events
Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode NOTE If no result is displayed, it is possible that the display threshold of the attenu- ation measurement result is higher than the attenuation that you are trying to measure. NOTE If you try to measure a splice on a slope, the measurement is not carried out and the following error message is displayed: Slope found between two...
Page 132: Overlay Trace Function
Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode Provided the event memorization icon is displayed, the automatic measurement following the acquisition is carried out using the events which were present before the acquisition. If you wish to make a measurement without events, deactivate memorization of events by pressing the Free Events key.
Page 133: Display Of Traces In Overlay
Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode Press the Load key. Press View trace(s). When loading is complete, the Results screen appears: the first trace selected is the active trace (in green), the other traces being overlaid. Display of traces in overlay •...
Page 134: Changing The Traces Position
Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode Press the direction keys, as many times as necessary, until the active trace is displayed in green. traces Click on the trace numbers in the upper right side of the result page until the trace desired is selected.
Page 135: Reference Trace Function
Chapter 3 Reflectometry measurements Advanced functions in Expert OTDR mode Reference Trace function The reference trace function consists in defining trace(s) which will be «blocked» on screen and used as models before acquiring or loading other standard trace(s). Using the reference trace function in the Result page Once one or several trace(s) is/are displayed, after an acquisition or loaded from the explorer:...
Page 136: Using The Reference Trace Function In The Explorer
Chapter 3 Reflectometry measurements Saving the trace(s) and generating a report • No reference trace(s) defined: all the «standard» traces are removed and only the new trace acquired is displayed. Using the reference trace function in the explorer A trace stored in memory can be set as reference trace before loading one or several «standard»...
Page 137 Chapter 3 Reflectometry measurements Saving the trace(s) and generating a report In the Recording Information screen, click on one parameter definition to modify Figure 54 Saving results in Smart Test mode NOTE The file is saved automatically by default with the Job Id parameter. Example: if the Job Id is defined with Test Fiber 1, the otdr filename will be Test Fiber 1.sor.
Page 138: Saving Results And Creating A Report In Expert Otdr Mode
Chapter 3 Reflectometry measurements Saving the trace(s) and generating a report Click on File + PDF to save the results in a .sor file and in a pdf one. A sound is emitted to confirm the results saving. Saving results and creating a report in Expert OTDR mode To save the trace and generate a report: Press Fast Report key.
Page 139 Chapter 3 Reflectometry measurements Saving the trace(s) and generating a report In the Cable Id parameter, enter/modify the name of the Cable using the edition keypad. In the Direction parameter, select/modify the direction, to define if the measurement has been performed from Origin to Extremity (A -> B) or from Extremity to Origin (B ->...
Page 140: Opening A Report
Chapter 3 Reflectometry measurements Saving the trace(s) and generating a report Example: if 3 traces are displayed in overlay, 3 .sor files and 3 pdf/txt files will be saved. • If in the File Setup page (S > File), the parameter File Content is defined ETUP with All Traces, one single .msor file and one single txt/pdf report will be gener- ated, bringing together all traces.
Page 141: Recalling Otdr Files
Results table CAUTION To modify the Viavi logo, set by default on the header of the pdf report, save your logo in a jpg file called logo.jpg and place it to the root of the disk: disk > logo.jpg. NOTE...
Page 142: Enterprise-Slm Software Option (T-Berd/Mts-6000A V2 Only)
Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Click on Load Click on View Tace(s) Load Trace + Config. The selected file is opened For further informations on file management, see Chapter 20 “File management”. Enterprise-SLM Software option (T-BERD/MTS- 6000A V2 only) This chapter describes the use of the Enterprise-SLM option, when the software license has been purchased with an OTDR module.
Page 143: Acquisition
Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) The configuration file includes pre-defined test parameters and label schemes (for automatic file labels generation) – TIA-606A Class 2 Single Building Horizontal Link = ENTERPRISE_- Class2_Hlink – TIA-606 Class 2 Single Building Backbone Cable = ENTERPRISE_- Class2_BBCable –...
Page 144 Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Laser The acquisition will be carried out on the wavelength(s) selected (for multiple-wave- length modules). In case of a multi-wavelength module, select All to perform a measure- ment for all the wavelengths available (this parameter visible exclusively on modules with one single OTDR port).
Page 145: Alarms
Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Figure 58 Launch Cable / Receive Cable Launch Cable Receive Cable Fiber Under Test OTDR Launch Receive Cable Cable end start Distance of the Distance of the receive cable launch cable Distance Unit Define the unit of the distances displayed: km, kfeet, miles, meter, feet, inch.
Page 146: Site Info Labels
Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Splice Connector Slope Reflectance Distance Loss Loss SM: > 1.00 dB/km Default > 0.20 dB > 0.50 dB MM: 850 nm > 3.50 dB/km > -35 dB < 27 dB 1300 nm: >...
Page 147 Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Site Properties In the Site Properties box, click on the right arrow key for each parameter to define the Site Properties, the Technician Identification and the Job Identification. Labeling The Labeling box differs according to the configuration file loaded and currently used. Label Format This parameter displays the label format applied to the project according to the configu- ration file selected.
Page 148 Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Fiber Code Once selected, press the right arrow key to modify some fields of the fiber code. The structure must follow TIA-606 standards. Change Fiber Number Increment the fiber number is automatically incremented at each new file-save. Decrement the fiber number is automatically decremented at each new file-save.
Page 149 Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) • Floor Press to open the sub-menu, different according to the selected configuration: define the Type of Label (Alphabetical / Numerical / None) and enter the Min and Max values and the Separator type (No;...
Page 150: File
Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) TIA-606 Class 2 TIA-606 Class 2 TIA-606 Class 3 Label Format Simple Custom Color Single Building Single Building Campus List Horizontal Link Backbone Cable Backbone Cable Fiber Count Fiber Prefix Fiber Code Fib.
Page 151: Simple Otdr Testing (For Single Fiber)
Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Simple OTDR Testing (for single fiber) The OTDR Enterprise Option can be use to test single fibers, with the optimum acquisi- tion parameters automatically applied. Select the OTDR Enterprise icon (MM or SM) and validate From the results page, press S button.
Page 152: Creating A Project From The Setup Page
Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Figure 59 Select Project file Press Open Project menu key. The Project displays, with a list of labels to be tested. Click on the label arrow to open the list of fibers to be tested for this label. NOTE In Simplex mode, only the label is available as it represents the single fiber.
Page 153: Project Display
Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Once all parameters are configured, press Save Config. to save the current configuration in a file. Press Import Label List top right soft key. Select the csv file that includes the list of labels / Cable Ids to be tested: Simplex: 1 label = 1 fiber Duplex: 1 label = 2 fibers MPO: 1 label = up to 24 fibers...
Page 154 Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Figure 60 Example of Project The icon displays on the upper banner, indicating a project is opened. Click on the label to open the sub-menu where the fiber numbers are displayed. Note;...
Page 155: Testing Mpo
Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Figure 61 Fibers 4 and 6 deactivated The disable fibers will be skipped while moving to the next fiber test. If Disable Fiber Test is pressed while a tested fiber is selected, a dialog box displays: «You’re about to delete acquisition files.
Page 156: Stopping The Test
Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Press Yes to launch a new acquisition or No to stop the acquisition and return to project screen. Stopping the test The test stops automatically once the label/fiber test is completed; or the user can press the Start/Stop button at any time to stop the test in progress.
Page 157: View Trace
Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) Pass Fail The number of fiber is highlighted in different color according to the alarm status: Pass No Alarm defined No test performed on the fiber Fail View Trace In the project page, click on the fiber number for which you want to display the corresponding OTDR trace (e.g.
Page 158: Smartlink View
Chapter 3 Reflectometry measurements Enterprise-SLM Software option (T-BERD/MTS-6000A V2 only) • Save the traces and create a report (see “Saving the trace(s) and generating a report” on page 100). • Analyze and visualize the different events (see “Results table” on page 69).
Page 159: Optipulses Option
Chapter 3 Reflectometry measurements OptiPulses option The screen is divided into three zones: • Zone 1: Graphical representation of the link, with icons symbolizing the different events detected. • Zone 2: Link Table, which gives a summary of results for each wavelength, with results within/without thresholds in green/red (according to Alarm thresholds defined in the setup screen).
Page 160: Results In Optipulses Mode
Chapter 3 Reflectometry measurements OptiPulses option Figure 66 OptiPulses configuration page 33 for information on principle of the acquisition. Configure the other parameters for the OTDR acquisition to be performed Launch the acquisition pressing S TART A beep is emitted at the end of the acquisition. Results in OptiPulses mode Once the acquisition is completed, a screen as the following one displays: Figure 67...
Page 161: Ftta-Slm Option
Chapter 3 Reflectometry measurements FTTA-SLM option With the OptiPulses option, the screen is as follows: – Two traces for each wavelength measured: the trace with shortest pulse and the standard one, – One single results table per wavelength with results from both traces merged. Example: if OTDR acquisition if performed on two wavelengths, the screen displays 4 traces and 2 results table.
Page 162: Acceptance Testing
Chapter 3 Reflectometry measurements FTTA-SLM option mainframe as a license key (see the 2000/4000 base-unit user manual for the instruc- tions on license files installation). FTTA-SLM simplifies OTDR testing for cell-tower technicians and eliminates complexi- ties of result interpretation. In a FTTA environment, the OTDR module, associated with the FTTA-SLM application, allows to: •...
Page 163: Troubleshooting Testing
Chapter 3 Reflectometry measurements FTTA-SLM option Figure 69 Acceptance Testing 20m cable leash recommended Loopback Device TX Feeder RX Feeder Launch lead Receive lead Troubleshooting Testing An OTDR from the BBU or fiber patch panel location will troubleshoot the fiber link up to the RRU/RRH.
Page 164: Configuring The Reflectometry Test For Ftta Network
Chapter 3 Reflectometry measurements FTTA-SLM option Figure 70 Troubleshooting Testing RX Feeder Launch Lead Configuring the Reflectometry test for FTTA network Once the OTDR module is set into the T-BERD/MTS, and the FTTA-SLM license installed: Select the FTTA-OTDR icon The results page automatically displays. Press S hard key to display the OTDR configuration screen for FTTA ETUP...
Page 165: Ftta Setup
Chapter 3 Reflectometry measurements FTTA-SLM option Figure 71 FTTA OTDR Setup See OTDR Setup: “Configuring the Link parameters” on page 43 FTTA setup In the first screen, configure the following parameters: Laser • The acquisition will be carried out on the wavelength(s) selected (for multiple- wavelength modules).
Page 166 Chapter 3 Reflectometry measurements FTTA-SLM option Figure 72 Network configurations Rooftop Tenant Rooftop Penthouse Cell Tower Config. This parameter displays the last configuration file loaded and cannot be modified unless a new configuration file is loaded. User Manual 78000010220 Rev. 024...
Page 167: Alarms Parameters
Chapter 3 Reflectometry measurements FTTA-SLM option Alarms parameters In the Setup page, press the Alarm menu key (if one parameter is selected in the current screen, press Top Menu soft key to display the right menu keys and click on Alarms). Threshold None The alarm function is not active.
Page 168: Link Description
Chapter 3 Reflectometry measurements FTTA-SLM option RRU Jumper Test from the patchcord that will be plugged into RRU. (not applicable for DAS networks) Mode Select the kind of acquisition to be performed: Construction Select this mode to perform the OTDR acquisition in the case of an Acceptance Testing (see “Acceptance Testing”...
Page 169 Chapter 3 Reflectometry measurements FTTA-SLM option Base Station Id or Headend Id (in case of DAS) If known, enter the name of the Base Station using the edition keypad, displayed pressing the right arrow key. NOTE The name of Location A entered in ExpertOTDR configuration is displayed by default in this parameter (see “Location A”...
Page 170: Launching The Acquisition
Chapter 3 Reflectometry measurements FTTA-SLM option Min: -999 / Max: 999 / Auto: 0 the Fiber number must not automatically modified Distance unit Select the unit to be used for distance (km / kfeet / miles / meter / feet). Launching the acquisition CAUTION Inspect &...
Page 171 Chapter 3 Reflectometry measurements FTTA-SLM option Figure 73 Acquisition in progress Number of Elapsed Total Elapsed acquisition averages acquisition time time calculated time At the end of the acquisition, a beep is emitted, the trace is displayed and an automatic measurement is started. NOTE During acquisition, the traffic on fiber is automatically detected (see “Traffic...
Page 172: Results Page
Chapter 3 Reflectometry measurements FTTA-SLM option The different traces appear in the same window and can be managed as traces in overlay (see “Overlay trace function” on page 96). Results page The trace(s) acquired or recalled from a memory is/are displayed on the Results page. Trace View The Trace view is displayed by default once OTDR acquisition is completed.
Page 173: Smartlink View
Chapter 3 Reflectometry measurements FTTA-SLM option Detailed description of an event When clicking on one event icon in the results table, a popup window describes the event type and provides a diagnosis to help troubleshoot faulty optical elements (indi- cated in red). Figure 75 Event description Press S...
Page 174 Chapter 3 Reflectometry measurements FTTA-SLM option Figure 76 SmartLink function Zone 1 Zone 2 Zone 3 The screen is divided into three zones: • Zone 1: Graphical representation of the link, with icons symbolizing the different events detected. • Zone 2: Link Table, which gives a summary of results for each wavelength, with results within/without thresholds in green/red (according to Alarm thresholds defined in the setup screen).
Page 175 Chapter 3 Reflectometry measurements FTTA-SLM option A new window, on the lower part of the screen, gives the details of the selected event: – its type – the thresholds applied for this event – the possible causes of the alarm Figure 77 Event Detail window Results Table...
Page 176 Chapter 3 Reflectometry measurements FTTA-SLM option Event View Click on Event View menu key to display a detailed description of one event detected on trace. In this view, an algorithm automatically detects the elements of the FTTA link and label them. Select the event to be described on the graphic (highlight in yellow).
Page 177: Changing The Name Of An Event
Chapter 3 Reflectometry measurements FTTA-SLM option Merged connectors When 2 or more connectors are very close to eahc others (in the attenuation dead zone), usually the reflectances can be measured but the loss of the individuals can’t be - the loss of these connectors is "merged"...
Page 178: Ftth-Slm Software Option
Chapter 3 Reflectometry measurements FTTH-SLM Software option FTTH-SLM Software option Principle of FTTH FTTH-SLM is an OTDR software application that is delivered as an option of the OTDR module (see references in the Chapter 22 on page 567), and is installed onto the main- frame as a license key (see the 8000 V2 or 6000A V2 base-unit user manual for the instructions on license files installation).
Page 179: Configuring The Reflectometry Test For Ftth Network
Chapter 3 Reflectometry measurements FTTH-SLM Software option Configuring the Reflectometry test for FTTH network Once the OTDR module is set into the T-BERD/MTS, and the FTTH-SLM license installed: Select the FTTH-OTDR icon The results page automatically displays. Press S hard key to display the OTDR configuration screen for FTTH ETUP network.
Page 180 Chapter 3 Reflectometry measurements FTTH-SLM Software option • ONT: Optical Network Terminal (media converter and gateway in the Home) Select the direction of the measurement: – Downstream: from OLT to ONT (OLT -> ONT) – Upstream: from ONT to OLT (ONT -> OLT) Number of Splitters If known, enter the number of splitters installed in the FTTH network.
Page 181: Alarms Parameters
Chapter 3 Reflectometry measurements FTTH-SLM Software option Length Use the Edit Number key to enter a distance (Min= 0 / Max=50 km / 164.042 kfeet / 31.075 miles) or affect the active cursor value, using Set Cursor Distance key. Distance Unit Define the unit of the distances displayed: km, kfeet, miles, meter, feet Config.
Page 182: Link Parameters
Chapter 3 Reflectometry measurements FTTH-SLM Software option G.697/G.98x PON & G.697/ TIA-568C & ISO/ Default IEEE PON IEC 11801 < 27 dB < 27 dB Splitter Alarm Splitter 1x2 > 5.0 dB > 4.2 dB Splitter 1x4 > 8.0 dB >...
Page 183: File Parameters
Chapter 3 Reflectometry measurements FTTH-SLM Software option Fiber Number Select the parameter Fiber Number and modify the number of the fiber to be tested. The fiber number can be automatically incremented/decremented at each new file save if it has been configured in the Change Fiber Nbr parameter (see “Change Fiber Nbr”...
Page 184 Chapter 3 Reflectometry measurements FTTH-SLM Software option Filenaming Select the parameter and modify the name of the file for the result trace. In the edition keypad, enter a name manually for the file and/or use the predefined parameters available (ONT_Id, Feeder_Id...). Press Enter to validate.
Page 185: Launching The Acquisition
Chapter 3 Reflectometry measurements FTTH-SLM Software option File + pdf the trace(s) is/are stored in one/several file(s), with its extension and one pdf file is also generated. Auto store Select Yes to store automatically the trace or traces resulting from each acquisition according to the filenaming rules.
Page 186: Results Page
Chapter 3 Reflectometry measurements FTTH-SLM Software option NOTE During acquisition, the traffic on fiber is automatically detected (see “Traffic Detection” on page 56). If the module possesses several lasers, to perform successive acquisitions on all the wavelengths: In the Setup menu, check in Laser line, that several lasers are selected or select All.
Page 187 Chapter 3 Reflectometry measurements FTTH-SLM Software option Figure 85 FTTH OTDR Trace Once trace is displayed, you can: • Zoom on trace (see “Zoom function” on page 75). • Set Cursor A and/or Cursor B (see “Cursors” on page 73). •...
Page 188: Smartlink View
Chapter 3 Reflectometry measurements FTTH-SLM Software option Figure 86 Event description Press S hard key or Setup menu key on Results page to go back to FTTH Setup ETUP screen and modify the parameters before launching a new acquisition. SmartLink view Click on the menu key Trace/SmartLink to select SmartLink.
Page 189 Chapter 3 Reflectometry measurements FTTH-SLM Software option Figure 87 SmartLink function Zone 1 Zone 2 Zone 3 The screen is divided into three zones: • Zone 1: Graphical representation of the link, with icons symbolizing the different events detected. • Zone 2: Link Table, which gives a summary of results for each wavelength, with results within/without thresholds in green/red (according to Alarm thresholds defined in the setup screen).
Page 190 Chapter 3 Reflectometry measurements FTTH-SLM Software option A popup window, on the lower part of the screen, gives the information related to the selected event: – its type – thresholds applied for this event – possible causes of the alarm Figure 88 Diagnostic Event window Results table...
Page 191: Changing The Type Of An Event
Chapter 3 Reflectometry measurements FTTH-SLM Software option The corresponding event description is displayed on the Zone 3, with a recall of alarm threshold for this event: Figure 89 SmartLink: Event View Click on Trace View to display the selected event in the results table and zoomed on trace.
Page 192 Chapter 3 Reflectometry measurements FTTH-SLM Software option Figure 90 Event Code Click on one event code to modify the selected event Click on Exit to return to Event View. Click back on Event View menu key to return to Summary screen Click on Trace View menu key to return to trace (and table) results screen.
Page 193: Smart Link Cable Option
Chapter 3 Reflectometry measurements Smart Link Cable Option Moreover, the icon and splitter configuration is different according to the number of «clicks» on one menu key. Example with the menu key • Click once: the icon is • Click twice: the icon is •...
Page 194 Chapter 3 Reflectometry measurements Smart Link Cable Option Press S hard key to display the OTDR configuration screen and: ETUP – Configure the OTDR Acquisition parameters (see page – Configure the OTDR Alarms parameters (see page – Configure the OTDR File parameters (see page Press Link Cable menu key Configure the Link Description parameters (see...
Page 195: Saving The Project
Chapter 3 Reflectometry measurements Smart Link Cable Option Saving the project Once all configuration parameters are defined, save the project: Press Save Project soft key (displayed when one parameter of the Cable Project window is displayed). In the Edition keypad opened, enter a name for the project and press Enter to validate.
Page 196: Starting Project Test Process
Chapter 3 Reflectometry measurements Smart Link Cable Option Select the project file to be used (.prj) in Project > EXPERT_OTDR > OTDR_SM or OTDR_MM directory. Press Open Project softkey.. Figure 93 Loading a project Recall of the Cable Project parameters A summary table of all fibers and measurements is displayed.
Page 197 Chapter 3 Reflectometry measurements Smart Link Cable Option Figure 94 Cable view View «List» View «Number» page 158 Click on the first fiber to be tested. The fiber number is underlined in purple (n°1 in Figure above) Press S hard key to start the acquisition. TART CAUTION If a test is launched onto a fiber already tested, a dialog box displays: «Test...
Page 198: Trace Saving
Chapter 3 Reflectometry measurements Smart Link Cable Option Trace saving The traces are automatically stored into the project directory and according to defined filenaming convention. Results of project cable Once fibers have been tested, the project page updates on the fly: Figure 95 Cable project Description of the table...
Page 199: View Trace
Chapter 3 Reflectometry measurements Smart Link Cable Option Select the fiber number which does not need to be tested (framed in black). Click on the soft key Deactivate fiber test. Repeat the process for the fibers which do not have to be tested. Figure 96 Fibers 4 and 6 deactivated The deactivated fibers will be skipped while moving to next fiber to test.
Page 200: Files And Project Storage
Chapter 3 Reflectometry measurements Smart Link Cable Option Figure 97 Trace from fiber selected in project Name of the project Number of the fiber selected Click to return to project Files and Project storage As soon as a project is saved from Setup page (see “Saving the project”...
Page 201 Chapter 3 Reflectometry measurements Smart Link Cable Option Figure 98 Project files The project file is not visible in the explorer until the project is closed. For each project, a subdirectory with the project Id is created, containing test OTDR files and summary results (in text format): cable_co >...
Page 202: Text File Content
Chapter 3 Reflectometry measurements Smart Link Cable Option Text file content As soon as one acquisition is performed from the project, a summary text file (.txt) is associated to the OTDR test data. Each new test is inserted into the text file as project process evolves. This file contains all the summary values of all tested fibers: –...
Page 203: Chapter 4 Reduced Dead Zone Otdr Application
Reduced Dead Zone OTDR Chapter 4 application This chapter describes the Reduced Dead Zone (RDZ) function, available exclusively with a E8123AV OTDR Module. The topics discussed in this chapter are as follows: • “Description of the RDZ function” on page 168 •...
Page 204: Description Of The Rdz Function
Chapter 4 Reduced Dead Zone OTDR application Description of the RDZ function Description of the RDZ function The reduced dead zone (RDZ) multimode OTDR solution has been specifically designed to characterize and find faults on very short multimode fiber runs such as aircraft/spacecraft, submarine ships, as well as cable manufacturing.
Page 205: Acquisition Parameters
Chapter 4 Reduced Dead Zone OTDR application Selecting and configuring the RDZ function NOTE The selection of the RDZ function automatically de-selects the selection of the Multimode function on the same module ,and vice-versa. Acquisition parameters Acquisition Range Select the range of the measurement: from 50 m to 1km Click on Manual to enter manually a range.
Page 206 Chapter 4 Reduced Dead Zone OTDR application Selecting and configuring the RDZ function Evt 1, 2, 3 The results relating to the launch cable are eliminated from the table. Attenuation and distances are then measured on the basis of the marker Evt 1, 2 or 3 selected.
Page 207: Performing The Measurement
Chapter 4 Reduced Dead Zone OTDR application Performing the measurement Performing the measurement Once the measurement is correctly configured, the acquisition can be performed. Press S button on the T-BERD/MTS to launch the acquisition. TART The red Testing indicator goes on to show that the Platform 8000 is in process of acquisition and the screen displays the trace in process of acquisition.
Page 208: Results Display
Chapter 4 Reduced Dead Zone OTDR application Results display On Results page, press the softkey Quick Setup: the acquisition parameters to be modified are displayed under the results trace: Figure 104 Results page and Quick Setup menu Modify the acquisition parameters wished in the displayed menu: see page 169.
Page 209 Chapter 4 Reduced Dead Zone OTDR application Results display The 8 lines table gives the type and the characteristics of all the events detected during the measurement: the 8 first lines displayed correspond to the 8 first events nearest to the cursor. The line corresponding to the event nearest to the cursor is highlighted.
Page 210: Slm View
Chapter 4 Reduced Dead Zone OTDR application Results display Reflective event. (e.g. connector) Ghost reflection. Slope of the fiber (when no fault follows the slope). End of fiber OTDR connector Event marker when a measurement cannot be carried out. If the event to be added is too close to an existing event, the icon appears on the trace and the table, but no measurement is carried out: to obtain the results for this event, a manual measurement is necessary.
Page 211: Saving The Trace(S) And Generating A Report
Chapter 4 Reduced Dead Zone OTDR application Saving the trace(s) and generating a report Figure 107 SLM view Refer to page 79 page 123 for a complete description of the SLM screen. Saving the trace(s) and generating a report Once the results page is displayed, the trace(s) can be saved and a report can be gener- ated directly from the results screen.
Page 212 Chapter 4 Reduced Dead Zone OTDR application Saving the trace(s) and generating a report Figure 108 Fast report configuration In the Save Mode parameter, select: File Only to save exclusively the trace in a asor file. File + txt to save the trace in a asor file and to generate a txt file of the results.
Page 213 Chapter 4 Reduced Dead Zone OTDR application Saving the trace(s) and generating a report Click on Auto Filenaming menu key to apply the file name defined in the Setup screen, in Filenaming parameter (see “Filenaming” on page Press Enter to validate. NOTE The sor file and the txt or pdf file will have the same name.
Page 214: Opening A Report
Chapter 4 Reduced Dead Zone OTDR application Saving the trace(s) and generating a report Opening a report To open the report, press F hardkey In the Explorer page, in the directory selected, select the file/report. The file name is: For the txt file: trace file_sor.txt For the pdf file: trace file.sor.pdf Press Load.
Page 215: Recalling Files
Saving the trace(s) and generating a report CAUTION To modify the Viavi logo, set by default on the header of the pdf report, save your logo in a jpg file called logo.jpg and place it to the root of the disk: disk >...
Page 216 Chapter 4 Reduced Dead Zone OTDR application Saving the trace(s) and generating a report User Manual 78000010220 Rev. 024...
Page 217: Power Meter And Source Functions Of The Otdr Modules
Power meter and Source Chapter 5 functions of the OTDR Modules The source function is available: • either as an option of the OTDR Module (E81OTDRLS) • or on standard with the OTDR E81xxB and E81xxC module series The power meter is available exclusively with the OTDR E81xxB and E81xxC module series.
Page 218: Connection To The Power Meter And The Source
Chapter 5 Power meter and Source functions of the OTDR Modules Connection to the power meter and the source Connection to the power meter and the source The type of optical connector used for the power meter and/or source is the same as the OTDR port.
Page 219: Configuring The Alarm Parameters Of The Power Meter
Chapter 5 Power meter and Source functions of the OTDR Modules Configuring the Power meter Figure 110 Configuration of power measurement See OTDR Setup: “Configuring the See OTDR Setup: “Configuring the Link parameters” on page 43 File parameters” on page 48 Configuring the alarm parameters of the power meter •...
Page 220: Configuring The Measurement Parameters
Chapter 5 Power meter and Source functions of the OTDR Modules Activating the Source function Configuring the Measurement parameters In the Setup page, press Measur’t softkey (if one parameter is selected in the current screen, press Top Menu soft key to display the right menu keys and click on Measur’t) Wavelength Select wavelength: Auto: the wavelength of the input signal will be automatically...
Page 221: Result Page
Chapter 5 Power meter and Source functions of the OTDR Modules Result page Press the button Use the direction keys or touchscreen to select the Source icon in the section of the OTDR Module. With direction keys, press the key. NTER The icon is selected Result page...
Page 222: Commands Of The Power Meter Parameters
Chapter 5 Power meter and Source functions of the OTDR Modules Result page Figure 111 Results and commands of the power meter Commands of the power meter parameters When the Powermeter function is selected, the following softkeys are available on the results page: The different configuration buttons are displayed: Wavelength...
Page 223: Result Page Of The Source
Chapter 5 Power meter and Source functions of the OTDR Modules Result page • The Power Ref. menu key allows to reach the Standard Ref menu key. It also allows to reach the Jumper Ref menu key if Power meter function is associated with Source function onto another unit (see “Carrying out the reference in loop- back mode”...
Page 224: Performing The Power Level Measurement
Chapter 5 Power meter and Source functions of the OTDR Modules Performing the power level measurement Mode To vary the mode of emission of the source. Possible modulation values are: – 270 Hz / 330 Hz / 1 kHz / 2 kHz –...
Page 225: Performing The Insertion Loss Measurement
Chapter 5 Power meter and Source functions of the OTDR Modules Performing the insertion loss measurement Connect the light source to be tested to the rear connector (see "Connection to the power meter and the source" page -182). In the menu, choose the units dBm, dB or Watts.
Page 226 Chapter 5 Power meter and Source functions of the OTDR Modules Performing the insertion loss measurement Figure 113 Side by side reference MTS / BERD 8000 V2 (1) MTS / BERD 8000 V2 (2) Bulkhead Mainframe or connector OTDR OTDR module Source Jumpers Before connecting fiber/jumper, use appropriate cleaning tool to clean connector...
Page 227: Carrying Out The Reference In Loopback Mode
Chapter 5 Power meter and Source functions of the OTDR Modules Performing the insertion loss measurement Carrying out the reference in loopback mode This reference can be carried out when the units are separated, at different locations. It is made using the OTDR source and the power meter built-in the platform. NOTE Each platform must be equipped with a power meter set onto the base-unit.
Page 228: Measurements On The Fiber Under Test
Chapter 5 Power meter and Source functions of the OTDR Modules Storing and reloading results A popup message appears once done. Press any key to continue The reference levels are stored into the unit, and have been automatically filled into the setup.
Page 229: Loading Results
Chapter 5 Power meter and Source functions of the OTDR Modules Storing and reloading results • The first file is to be used with the Attribute/Descriptor and allows to retrieve all measurement results. It is saved with the extension .Lts. •...
Page 230 Chapter 5 Power meter and Source functions of the OTDR Modules Storing and reloading results User Manual 78000010220 Rev. 024...
Page 231: Bi-Directional Otdr
Bi-directional OTDR Chapter 6 This chapter describes the different steps to perform an automatic bi-directional measurement (also called OEO measurement = Origin-End-Origin).This measurement requires that two T-BERD/MTS-8000 V2 or 6000(A) are connected at each extremity of the fiber under test. Every MTS/T-BERD must be equipped with the software option called «OEO-OTDR»...
Page 232: Definition Of Terms Used
Chapter 6 Bi-directional OTDR Definition of terms used Definition of terms used Master / Slave unit The master unit is the MTS/T-BERD that initiates the measurement at one extremity of the fiber. The slave unit is the MTS/T-BERD connected on the other extremity of the fiber, and connected to the master unit via the data connection.
Page 233: Summary Of The Automatic Operation Procedure
Chapter 6 Bi-directional OTDR Description of the measurement NOTE For automatic bidirectional OTDR testing, two units having the talkset option and the E80 bidirectional option are required. Example with 6000 series Data Tested Fiber Fully automatic bi-directional acquisitions can not be performed with- out a data connection (see «Data transfer»...
Page 234: Configuration Of Bi-Directional Measurement
Chapter 6 Bi-directional OTDR Configuration of bi-directional measurement • Trace transfer to the slave unit • Acquisition start on the slave unit • Trace transfer to the master unit • Bi-directional measurement on both units • Results storage in a single «.OEO» file or in two «.SOR» files. All this test procedure is fully automatic, and all results are immediately accessible on both units.
Page 235: Acquisition Parameters
Chapter 6 Bi-directional OTDR Configuration of bi-directional measurement Figure 116 OEO test setup menu See OTDR Setup: “Configuring the Alarms parameters” on page 36 See OTDR Setup: “Configuring the Analysis parameters” on page 38 See OTDR Setup: “Configuring See OTDR Setup: “Configuring the Link parameters”...
Page 236: Configuration Of Files Parameters
Chapter 6 Bi-directional OTDR Performing a bi-directional measurement Configuration of files parameters To access the files configuration menu of the OEO-OTDR tab, press the button F Related parameters are then displayed. All parameters to describe the files, the fiber and the link are proposed in order to save all measurements.
Page 237 Chapter 6 Bi-directional OTDR Performing a bi-directional measurement The key View Process/Curves/Summary allows to change from the Curve page to the Process page and to the Summary page. In order to select and follow the status of a measurement, go to the Process page. NOTE When a measurement has been started, the slave MTS/T-BERD automati- cally displays the Process page.
Page 238: Fiber Link Check
Chapter 6 Bi-directional OTDR Performing a bi-directional measurement Measurement status zone: When a bi-directional measurement has been launched, all the different steps in the measurement process are presented in this zone. Each one is detailed later in this chapter. NOTE The general information banner is displayed at the top of the screen as for all other tabs.
Page 239: Measurement Process
Chapter 6 Bi-directional OTDR Performing a bi-directional measurement Measurement process Fiber measurement Step 1 Choose to use the markers stored in memory or not by selecting Lock Evt Free Evts. NOTE If the markers events are already defined for the link, you may select the Lock Evt key.
Page 240 Chapter 6 Bi-directional OTDR Performing a bi-directional measurement Step 2 The line <Check if same fiber for both units> becomes <In progress...>. If the master MTS/ T-BERD successfully detects the other MTS/T-BERD at the extremity of the fiber under test, the validation symbol is displayed, and the process proceeds to Step 3. Otherwise, the red cross is displayed and the measurement is stopped.
Page 241: Trace Display Functions
Chapter 6 Bi-directional OTDR Trace display functions It is also possible to request from the slave MTS/T-BERD that the measurement is stopped, by pressing the button S . The master unit receives the request via TART a message on the screen: <Remote asks for stop, do you agree ?>. If Yes, the measurement is stopped, if No, the measurement resumes.
Page 242: Origin And End Traces
Chapter 6 Bi-directional OTDR Trace display functions NOTE The remote trace is reversed in order to superpose both traces in a «butterfly fashion» (see Figure 118 on page 205). NOTE You may only use this key to change page when the measurement is com- pleted.
Page 243: Oeo Trace
Chapter 6 Bi-directional OTDR OEO Result table OEO trace Only one couple of OE and EO traces is displayed, corresponding to one wavelength. If the measurement has been performed on different wavelengths, select Wavelength on the key Wavelength/Evt in order to go from one couple of traces to another, using direction keys.
Page 244: Addition Of Markers
Chapter 6 Bi-directional OTDR Test of a cable Addition of markers In order to modify a marker on any of both origin and end traces, select cursor A or B, position your cursor when you want to modify or add a marker and press the key Event: –...
Page 245: Saving The Traces And Generating A Report
Chapter 6 Bi-directional OTDR Saving the traces and generating a report Finally, a bi-directional automatic measurement is performed for each fiber. Results are stored in either one «.OEO» file or two «.SOR» files. Saving the traces and generating a report Once the results page is displayed, the traces can be saved and a report can be gener- ated directly from the results screen.
Page 246 Chapter 6 Bi-directional OTDR Saving the traces and generating a report NOTE Traces are saved in oeo or sor format according to the configuration of the parameter File Content (F > Setup). See “Saving and report for traces in overlay” on page 211 In the Cable Id parameter, enter/modify the name of the Cable using the edition keypad.
Page 247: Opening A Report
Chapter 6 Bi-directional OTDR Saving the traces and generating a report NOTE The file saving can also be performed from the F > Explorer page (see “Saving Files from the Explorer” on page 535). Saving and report for traces in overlay As several traces are displayed in overlay in the results page, one or several file(s)/ report(s) is/are generated: •...
Page 248 Trace Results table CAUTION To modify the Viavi logo, set by default on the header of the pdf report, save your logo in a jpg file called logo.jpg and place it to the root of the disk: disk > logo.jpg.
Page 249: Recalling Oeo Traces
Chapter 6 Bi-directional OTDR Troubleshooting Recalling OEO traces Recalling a «.OEO» file: If the OEO software option is available, loading a «.OEO» file with the Load key followed View Trace key will open automatically the OEO-OTDR tab in order to display the OEO trace.
Page 250: Warning/Errors Resulting From Common Configurations
Chapter 6 Bi-directional OTDR Troubleshooting Error message Possible problem Possible solution No response from remote Data link problem Check the data connection Unit Warning/errors resulting from common configurations Message Action possible No common laser: acquisi- Select a Platform equipped with the same type OTDR plug-in tion is impossible Lasers are different.
Page 251 FiberComplete Modules Chapter 7 This chapter describes the functions of the FiberComplete modules (Combined OTDR or Fault Finder and auto bidirectional IL/ORL and Distance) and their use. The topics discussed in this chapter are as follows: • “General introduction” on page 216 •...
Page 252: Fibercomplete Modules
Chapter 7 FiberComplete Modules General introduction General introduction Principle FiberComplete is used to perform automatically and through a single connection port, the following tests: • Bidirectional insertion loss (IL) • Unidirectional / Bidirectional optical return loss (ORL) using the continuous wave method (OCWR) •...
Page 253: Configurations
Chapter 7 FiberComplete Modules General introduction Figure 121 Configuration for FiberComplete function Remote Local Distance / IL / ORL / Acquire Analyze Report Measure Bidir IL & ORL Locate failures with Save all the results and OTDR Fault Finder automatically NOTE The FiberComplete function can be performed with one T-BERD/MTS-8000 V2 and one T-BERD/MTS-6000/6000A.
Page 254 Chapter 7 FiberComplete Modules General introduction Figure 122 Construction/Installation Test Reference Source and power meter on Units A & B Setup Units A & B (Measurement and File parameters) Press button to launch the TART measurements Measure loss A->B, B->A, and Avg and Next store/display on both units Fiber...
Page 255: Activating The Function
Chapter 7 FiberComplete Modules Activating the function Figure 123 Acceptance Test Reference Source and power meter on Units A & B Setup Units A & B (Measurement and File parameters) Press button to launch the TART measurements Measure loss A->B, B->A, and Avg and store/display on both units Next Fiber...
Page 256: Reference Stage Process
Chapter 7 FiberComplete Modules Establishing References nected from the test instruments and/or have been contaminated by dirt or dust, they have to be re-inspected and referencing stage has to be redone. Reference methods for insertion loss and ORL testing Table 5 Reference methods for Insertion Loss and ORL Testing IL Loopback IL Side-by-side...
Page 257: Loopback Referencing Method
Chapter 7 FiberComplete Modules Establishing References Each test equipment must set its own references and conform to the following process: Press R button ESULTS Press References > Take Refs keys and follow the step by step instructions to perform references on each unit. Choose between side by side or loopback for you loss referencing method.
Page 258 Chapter 7 FiberComplete Modules Establishing References Figure 125 Self reference Powermeter of the OTDR Module port 8000 V2 platform The reference values are stored and displayed at the end of referencing. The zero ORL reference is necessary for ORL testing. Once the self reference measurement has been carried out, the Zero ORL adjustment can be performed Connect the jumper from the module port to the non-reflective termination via a mating sleeve.
Page 259: Side-By-Side Referencing Method
Chapter 7 FiberComplete Modules Establishing References Figure 126 Zero ORL reference Non-reflective OTDR port termination (or mandrel) NOTE Non-reflective terminations are mandatory when bend insensitive jumpers are used. Side-by-Side referencing method The side-by-side referencing is used when the two units are at the same location and is the preferred method for better loss measurement accuracy.
Page 260: Factory References
Chapter 7 FiberComplete Modules Establishing References Connect the jumper from the module port to the non-reflective termination via a mating sleeve. If you don't have a non-reflective termination a mandrel can be used. Press Ok to start referencing. Figure 126 on page 223 For the loss reference, connect the jumper from the module port of the primary unit, toward the module port of the secondary one via a mating sleeve.
Page 261: Configuring The Units
Chapter 7 FiberComplete Modules Configuring the units Figure 128 Factory References Configuring the units Once references have been taken on both 8000 V2 Units, the acquisition parameters must be configured. Press S button to display the FiberComplete Setup menu. ETUP CAUTION The Laser selection and Results Screen parameters must be configured on both units.
Page 262: Acquisition Parameters
Chapter 7 FiberComplete Modules Configuring the units Acquisition parameters Laser select the desired wavelength(s). All: acquisition is performed for all wavelengths available in the instruments. IL/ORL Measurement ORL standalone: select this parameter to perform exclusively an ORL measure- ment in unidirectional mode. IL/ORL Bidir: select this parameter to perform both an ORL and an Insertion Loss measurement, in bidirectional mode.
Page 263: Alarms Parameters
Chapter 7 FiberComplete Modules Configuring the units The following parameters, defined on master unit, are automatically applied/transferred to the slave unit: Laser - IL/ORL Bidir. - OTDR Acquisition Auto (if OTDR Acquisition is defined on Manual, both units will performed a manual measurement, but according to their own configura- tion in the OTDR tab: the parameters can then be different).
Page 264: Link Parameters
Chapter 7 FiberComplete Modules Configuring the units NOTE If Fiber View is selected, and if results are stored, then the filenaming con- vention is; [fiber Id][fiber Num]. Therefore, the unit will generate one IL / OLR / Distance file per fiber. •...
Page 265: Automatic Configuration
Chapter 7 FiberComplete Modules Configuring the units Filenaming Select Filenaming parameter and press the right arrow key to modify the name of the file for the result trace. In the edition keypad, select the pre-defined parameters available or, press abc key to enter a name manually for the file.
Page 266: Saving Parameters From Configuration
Chapter 7 FiberComplete Modules Configuring the units • IL/ORL Measurement: IL/ORL Bidir. • Length Measurement: Yes • OTDR Measurement: None • Fault Finder: No • Table View: Fiber • Thresholds: Default Saving parameters from configuration Once the File and Measurement parameters are configured, it can be saved in a config- uration file.
Page 267: Loading A Configuration File Fibercomplete
(see “Saving parameters from configuration” on page 230). NOTE Some Viavi pre-defined configuration files for FiberComplete are already available into the equipment, in F disk > config > FCOMP. Performing the tests Once Setup is configured on both units, they can be linked to the fiber to be tested.
Page 268: Sending A Message To The Distant Platform
Chapter 7 FiberComplete Modules Performing the tests Automatic pairing / continuity check As soon as the secondary (B) unit is connected to the fiber, the primary (A) unit detects it (and vice-versa). One unit is disconnected of the fiber link, or Both unit are connected to the same fiber there is a break Sending a message to the distant Platform...
Page 269: Starting The Test
Chapter 7 FiberComplete Modules Performing the tests NOTE If the message «Go to Fiber N°» is selected, use left and right direction keys to decrement/increment the fiber number. Press the Send Message softkey. The message displays automatically on distant Platform. Figure 133 Receipt of the message on the distant Platform Starting the test...
Page 270: Results Screen
Chapter 7 FiberComplete Modules Results screen Figure 134 Test in progress Once all tests are performed, results are displayed on both units If OTDR parameter is set to Auto or Manual in the Setup menu, the OTDR acquisition starts. If Fault Finder parameter is set to Yes and an IL or ORL value reaches one of the user defined thresholds, the Fault Finder starts.
Page 271: Fiber View
Chapter 7 FiberComplete Modules Results screen Figure 135 Result Cable View The Cable View allows to display results of multiple fibers: – the average loss at each wavelength – the ORL A and ORL B at each wavelength – the distance is displayed on top of the screen NOTE In order to erase the results table, the Cable ID must be modified in the File Setup menu (see...
Page 272: Fault Finder
Chapter 7 FiberComplete Modules Results screen Figure 136 Result Fiber View The Fiber View allows to display results of one fiber: – Loss B -> A and loss A -> B at each wavelength – the average loss at each wavelength –...
Page 273: Otdr
Chapter 7 FiberComplete Modules Results screen Figure 137 Fault finder result screen OTDR If the OTDR Measurement parameter has been set to Unidir. or Bidir., the OTDR acquisition is launched and the trace can be seen by selecting the OTDR tab at the bottom of the screen.
Page 274: Saving Results And Generating A Report
Chapter 7 FiberComplete Modules Saving results and generating a report NOTE In Auto mode, the wavelengths selected for IL/ORL are also used for OTDR testing. In Manual mode, all the OTDR parameters can be adjusted in the OTDR setup menu. NOTE To go from one tab to the other one, press the R button or, with touch-...
Page 275 Chapter 7 FiberComplete Modules Saving results and generating a report Figure 139 Fast report configuration In the Save Mode parameter, select: txt file select Yes to save the results in a blts file and to generate a txt file of the results. pdf file select Yes to save the results in a blts file and to generate a report in a pdf file.
Page 276: Opening A Report
Chapter 7 FiberComplete Modules Saving results and generating a report Once saving is completed, a sound is emitted onto the Platform. NOTE The file and the report are saved in the last storage media and directory selected. Opening a report To open the report, press F hardkey In the Explorer page, in the directory selected, select the file of the report.
Page 277: Recalling Otdr Files
Saving results and generating a report CAUTION To modify the Viavi logo, set by default on the header of the pdf report, save your logo in a jpg file called logo.jpg and place it to the root of the disk: disk >...
Page 278 Chapter 7 FiberComplete Modules Saving results and generating a report [Cable_Id] The cable results, which includes all fibers, are stored in a .blts file. As soon as the Cable Id changes, the result table is cleared and the next tests are stored with the new Cable Id name.
Page 279: Chapter 8 Optical Spectrum Measurement
Optical Spectrum Chapter 8 Measurement This chapter describes the different stages in carrying out a spectrum analysis of an optical signal, or analyzing effects from an optical components or network elements like EDFA, DFB-sources..., by a Platform equipped with an OSA of the OSA-50X series or the OSA-100 series.
Page 280 Chapter 8 Optical Spectrum Measurement NOTE Looking for the OSA-type and series Nr, on the Home page, press Settings > Help page. The topics discussed in this chapter are as follows: • “Laser safety” on page 245 • “Transportation” on page 245 •...
Page 281: Laser Safety
Using the original packing material ensures that the device is properly protected during shipping. Otherwise, Viavi cannot give warranty on modules good protection. If you need a new packaging, please contact Viavi Technical Assis- tance Center. User Manual 78000010220 Rev. 024...
Page 282: Configuration Of The Instrument
Chapter 8 Optical Spectrum Measurement Configuration of the instrument Configuration of the instrument The instrument configuration menu will be displayed directly after power up or by pressing the H -button. The actual module status will be shown (ON/OFF) on system window For configuring the OSA press the OSA-icon (by touchscreen) , or select the function icon by arrow-keys and press E NTER...
Page 283 Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup Setup in Test Auto mode Test Auto I-OSNR (only Parameter Test Auto WDM OSA-500R, OSA-500RS & OSA-110R) Acquisition settings Mode I-OSNR Sweep single Sweep range Full ext. C Band Averaging acquisition Not available I-OSNR Range (OSA- Not available...
Page 284 Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup Configuration of the file set-up (see Chapter Filenaming [Cable_id][Fiber_Num][Test_Poin ][Direction] Auto Store Nb Fiber Increment or define your own configuration The parameter to be modified must be selected by means of the direction keys .
Page 285: Loading A Configuration File
Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup On Setup page, you may select one of the sub-chapter by pressing one of the softkey F1 to F5. The various parameters proposed are defined below. Loading a configuration file To load the configuration file to be used for OSA test: Press S hard key.
Page 286 Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup EDFA Module is used to analyze results from an EDFA. EDFA results are displayed in the results table. (See “EDFA results analysis” on page 279) Module is used to analyze results from a DFB. DFB results are displayed in the results table (See “DFB results analysis”...
Page 287 Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup OSNR≤15dB or at data rates up to 12.5Gbps and OSNR values ≤ 25dB Up to 20dB recommended for data rates of = 40Gbps and OSNR ≤ 20 dB, or for data rates up to 12.5Gbps and OSNR ≥ 25dB. Full recommended for data rates of ≥...
Page 288: Analysis Parameters
Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup Manual The measurement is done manually, once the key Stop Wait pressed Period The measurement is automatically done, after the wait period selected (see hereunder). Wait Period The Wait Period parameter allows to enter a wait period before the measurement start (only active if Long Term is positioned on Period) •...
Page 289: Channel Detection
Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup Channel Detection Signal threshold Threshold of detection of channels (see “Channel detection threshold” on page 266). Auto. the threshold is determined automatically. Manual the threshold can be set from -79.9 to +30 dBm Use direction keys or Edit Number to modify values.
Page 290: Osnr
Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup This parameter is also used to set the range for integration to measure the accurate total signal power of an optical channel. The window for channel power integration will be ±1/ 2 the min.
Page 291: Splitter Compensation
Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup measurement is taken (left, right, average left and right, worst case of left and right). S<->N Distance (only available in OSNR mode) Distance between the peak of the channel and the point of reference for the noise.
Page 292: Display Parameters
Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup For example, with a 10 dB splitter, the results will be augmented by 10 dB. The trace will be offset upwards by 10 dB. A channel measured at -30 dBm will be displayed -20 dBm.
Page 293 Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup Table 6 Grid menu options for each type of grid ITU CWDM ITU DWDM Regular Manual Editable, from Editable, from 1250.05 to 1649.93 Editable from First ITU 1270 to 1611 nm, nm, by increments 1250 to 1650 nm, channel (with...
Page 294: Alarms
Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup Alarms When Channel Detection is positioned on Grid, it is possible to activate an alarm system. This system is based on a system of thresholds. Any measurement results that exceed these thresholds are displayed in red in the table, and the icon appears at the top right of the screen.
Page 295: Zoom Mode (Osa-500)
Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup P Max. From -79.9 dBm to +10 dBm (above min. threshold) OSNR From 0 to 50 dB Zoom Mode (OSA-500) The OSA module performs a measurement over the sweep range, but the display shows the part defined by the Zoom mode.
Page 296: Saving Configuration In A File
Chapter 8 Optical Spectrum Measurement OSA optical spectrum analyzer Setup • Wavelength in nm Table Content Standard The result table displays the columns Ch-Number, Ch-ID, Wavelength/Frequency, Spacing/Offset, Ch-Power, OSNR, Noise Statistics The result table displays the columns Ch-Number, Ch-ID, Wavelength/Frequency, minimum Wavelength/Frequency, maximum Wavelength/Frequency, Ch-Power, minimum Ch- Power, maximum Ch-Power Pass/Fail...
Page 297: Acquisition
Chapter 8 Optical Spectrum Measurement Acquisition Press Enter to validate A sound is emitted to indicate the file is saved. The configuration file is saved with the extension ".fo_cfg" (icon ) and can be recalled at any time from the Explorer page. Acquisition To start a measurement press S key.
Page 298: Display Functions
Chapter 8 Optical Spectrum Measurement Trace display functions NOTE If several acquisitions are performed, the trace displayed is the one corre- sponding to the last acquisition. Figure 142 Example of OSA test result (with grid) Filename Number of acquisitions Fiber number Multi-traces display Wavelengths and power at point of trace...
Page 299: Cursors Function
Chapter 8 Optical Spectrum Measurement Trace display functions To define a zoom on the trace: Select Cursor A or B and center it on the zone to be examined On the Shift/Zoom key, select the Zoom function. Use the key to increase or reduce the zoom factor. Use touchscreen and click on trace to position the upper left and bottom right corners of the zoomed area.
Page 300: Full Scale
Chapter 8 Optical Spectrum Measurement Trace display functions Cursors information The informations on Cursors are always display on the upper part of the screen. Above the trace are shown the co-ordinates of the points of intersection of the cursors A and B with the trace, together with the distance between the two points. Cursor X and Y Two types of cursors can be defined: •...
Page 301: Trace /Table Key
Chapter 8 Optical Spectrum Measurement Trace display functions Use the direction keys or touch and hold screen to shift the trace in the desired direction. Trace /Table key This key offers a choice from the following displays: Trace alone: main display of the trace with a single line of the table at the foot of the page (see Figure 142 on page 262).
Page 302: Channel Detection Threshold
Chapter 8 Optical Spectrum Measurement Trace display functions Table: display of the table alone Figure 144 OSA Results - Table Channel detection threshold On the trace, some peaks corresponding to noise could be mistaken for channels. It is therefore necessary to fix a power threshold level: only peaks that exceed this threshold will be considered as channels and included in the table of results.
Page 303: Display Of Gain Tilt (Delta) And Gain Slope Results
Chapter 8 Optical Spectrum Measurement Trace display functions The space between the trace and the two cursors is greyed out and the power is displayed in the form "P=-4.95dBm". Pressing the key Total Power A<-->B a second time removes the result of the total power measurement.
Page 304: Overlay Trace Function
Chapter 8 Optical Spectrum Measurement Overlay trace function Figure 145 Display of total power, gain tilt and slope of the gain between the cursors Overlay trace function This very useful function enables up to eight traces to be displayed on the screen at once: •...
Page 305: Overlaying The Current Trace
Chapter 8 Optical Spectrum Measurement Overlay trace function On the Menu/Explorer key, select Explorer. Select the files of the traces for display. Press the Load key. Press View trace(s) or Load traces + config. When loading is complete, the Results screen appears: the first trace selected is the active trace, the other trace being overlaid.
Page 306: Swapping Overlay Traces
Chapter 8 Optical Spectrum Measurement Overlay trace function Figure 146 OSA - Overlaid traces Swapping overlay traces Measurements can only be made on the active trace and not on overlaid traces. To make measurements on a trace in overlay, it must first be swapped with the active trace. To do this: Press the Trace...
Page 307: Trace Resulting From The Difference Between Two Traces
Chapter 8 Optical Spectrum Measurement Table of results Trace resulting from the difference between two traces It is possible to obtain the trace corresponding to the point-by-point difference between the current trace and the trace in overlay (if only two traces are displayed simultane- ously).
Page 308: Type Of Display
Chapter 8 Optical Spectrum Measurement Table of results Type of display The table may be displayed in a single line, on half of the screen or the whole screen as a function of the Trace/Table key (see “Trace /Table key” on page 265) Contents of the table with statistics When selecting the Statistics measurement mode and multiple acquisitions are...
Page 309: On/Off-Osnr Method
Chapter 8 Optical Spectrum Measurement On/Off-OSNR Method Move the cursor on to the channel that is to serve as the reference. Press the Set Ref. Channel key. The results are recalculated with respect to this channel of reference. On/Off-OSNR Method Challenge This is a precise out-of-service method used for measuring the in-band OSNR of stan- dard and also of polarization-division multiplexed (PDM) systems.
Page 310 Chapter 8 Optical Spectrum Measurement On/Off-OSNR Method Step 1: Reference measurement In the Results page, select 'Ref. Acquisition' and perform (Start) an OSA measurement (all channels ON). All channels will be detected and the total channel power (=integrated ch-power) of each channel will be shown and stored in the table = P_ch (Power [dBm]).
Page 311: Limitations
Chapter 8 Optical Spectrum Measurement Channel filtering Noise power is measured at the center frequency of the switched-off channels. Noise power is normalized to Noise Acq BW (i.g. 0.1nm) according to the setup param- eter. OSNR will be calculated and displayed in the table based on stored P_ch (step 1). Limitations The On/Off-OSNR method requires an intervention into the optical system as the optical channel to be measured needs to be switched-off.
Page 312: Configuration
Chapter 8 Optical Spectrum Measurement Channel filtering Configuration To obtain filtering of a given canal to the drop port, go into theS menu of the OSA ETUP module. Choose Acquisition, then Sweeps and select Filtering. The options of the acquisition menu then change and offer: Choice of channel In the Choice of Channel option, either a value may be entered manually or the current value from the table can be taken.
Page 313: Drift Measurement
Chapter 8 Optical Spectrum Measurement Drift measurement Drift measurement The OSA-xxx modules provide a Drift measurement application to perform multiple measurements and display the recorded results in a graphical format (trace) over the time. This can be used to monitor the drift of power, wavelength and SNR of optical systems or components.
Page 314 Chapter 8 Optical Spectrum Measurement Drift measurement Figure 148 Example of drift measurement, wavelength over time In the Drift display the measurement result is shown in a graphical format (trace over time / scans) and a tabular format. The table shows the following parameters: Channel number number of the displayed channel Wavelength or Frequency of the displayed channel...
Page 315: Edfa Results Analysis
Chapter 8 Optical Spectrum Measurement EDFA results analysis EDFA results analysis This feature applies only to instruments OSA-50X series. The results analysis of an EDFA consists in performing two spectrum analysis: one before the signal is amplified and another one after the signal is amplified. Both traces are further compared, providing the resulting power gain and noise figure.
Page 316: Edfa Results
Chapter 8 Optical Spectrum Measurement EDFA results analysis Figure 149 EDFA measurements Select which acquisition you are working on Select which trace to view Measurement procedure, using two ports: If two ports are selected, the Platform will perform both «Acq. In» and «Acq. Out» in one step.
Page 317: Dfb Results Analysis
Chapter 8 Optical Spectrum Measurement DFB results analysis Noise figure from EDFA (expressed in dB) <Channel> allows moving the cursor from one channel to another, both in the trace and in the table of results. Saving EDFA results Results are not saved in a file. Nevertheless, both traces may be stored as regular WDM traces.
Page 318: Dfb Measurements
Chapter 8 Optical Spectrum Measurement DFB results analysis In the Measurements section, set Type on DFB. A new DFB sub-menu is offered while other Setup parameters are the same for DFB as for WDM measurements. Refer to “OSA optical spectrum analyzer Setup” on page 246 for a complete description.
Page 319: Dfb Results
Chapter 8 Optical Spectrum Measurement DFB results analysis Cursors A and B are automatically positioned on the first DFB laser, respectively on the max SMSR and the pick of the main component. DFB results A table is displayed (see “DFB measurements” on page 282) showing for each DFB: Channel Number of DFB laser detected...
Page 320: Testing Roadm Networks
Chapter 8 Optical Spectrum Measurement Testing ROADM networks Testing ROADM networks In ROADM networks, each channel may traverse different routes, optical amplifiers, and add-drop filters, resulting in different OSNR for each channel. Conventional OSA measurements are unreliable, as they indicate OSNR values that are too high: up to 10dB above the true OSNR.
Page 321: Measurement Of I-Osnr
I-OSNR mode As the out-of-band OSNR measurements might not provide the 'TRUE' OSNR value for the above listed systems configurations, the in-band OSNR measurement method based on Viavi’s polarization nulling technique must be selected. User Manual 78000010220 Rev. 024...
Page 322 Chapter 8 Optical Spectrum Measurement Measurement of I-OSNR Press S until OSA test setup appears. ETUP Press Test Auto I-OSNR button. The instrument will be set for in-band OSNR measurements. All Parameter settings will be done automatically: The following parameters will be pre-set: Sweep mode single Sweep range...
Page 323 Chapter 8 Optical Spectrum Measurement Measurement of I-OSNR => can be used for a first check when expected OSNR <20dB for 10G systems at channel spacing of 50GHz and higher; and for systems running at 40GBps at channel spacing of 100GHz or higher •...
Page 324: Performing An In-Band Osnr Test In I-Osnr Mode
Chapter 8 Optical Spectrum Measurement Measurement of I-OSNR It might be that the system has a visible channel spacing of 100GHz but the min channel spacing is 50GHz as only every second channel is loaded. This could also be the case when 50GHz optical interleavers are used to multiplex two 100GHz spaced WDM signals (even and odd channels) together into a 50GHz spaced system =>...
Page 325: Wdm-Expert Software Option
• I-OSNR: in-band OSNR measured Gaussian or no Filter approximation WDM-Expert Software option The WDM-Expert option is a software option, available on Viavi OSA-110M//110R and OSA-500/500M/500RS. This option allows to perform Real time analysis (no additional measurement time required) and can be used as a post analysis software on already measured links.
Page 326: Configuring The Display With Wdm-Expert Option
Chapter 8 Optical Spectrum Measurement WDM-Expert Software option Transmitted signals Indication in WDM Table 100G signals higher using pol-mux modulation ≥100G PM 40G signals without pol-mux modulation 10G signals without pol-mux modulation 2.5G signals without pol-mux modulation 2.5G Configuring the display with WDM-Expert option Once the software option is installed, new parameters are available in the Setup page: Press S ETUP...
Page 327: Modifying A User Defined Table
Chapter 8 Optical Spectrum Measurement WDM-Expert Software option Figure 154 Customization of WDM table In the right menu keys, check Value is defined to Available. In Column Categories, select the category into which an item must be added to user-defined table. In Available Columns, select the item to be added to the table (video reversed).
Page 328 Chapter 8 Optical Spectrum Measurement WDM-Expert Software option To rearrange the sequence of the columns in the result table select one of the result column in the Current Table column. Figure 155 Modify / Remove items Once a User defined table is available, it can be modified at any time from the Setup page: •...
Page 329 Chapter 8 Optical Spectrum Measurement WDM-Expert Software option Items available per category Figure 156 Items for each category for user definable WDM table Chan.Numbers & Names Sequence Number channels are consecutively numbered. Channel ID the channel identification, defined by the text in Display > Grid > Channel settings >...
Page 330 Chapter 8 Optical Spectrum Measurement WDM-Expert Software option Spect.Pos. [Disp.Unit] All spectral positions in this columns category are displayed in nm or THz. This depends on the value of the Setup/Display/Unit parameter Center the center frequency / wavelength of the channel signal Spacing the frequency / wavelength difference to the previous channel signal...
Page 331 Chapter 8 Optical Spectrum Measurement WDM-Expert Software option Center Ref.rel the difference between the reference frequency of the channel and the reference channel Spect. Pos [nm] All spectral positions in this columns category are displayed in nm, independent of the value of the Setup/Display/Unit parameter.
Page 332 Chapter 8 Optical Spectrum Measurement WDM-Expert Software option P / Pcomp the percentage of the power of a channel signal to the sum of all powers of the channel signal Power Peak rel the difference between the peak power and the peak power of the reference channel Power Integr.
Page 333 Chapter 8 Optical Spectrum Measurement WDM-Expert Software option WDM / OSNR) given in THz or nm; depends on the value of the Setup/Display/Unit parameter Noise Dist. [GHz] distance between the center of the channel and the point of reference for the noise (only valid for Acquisition Mode WDM / OSNR) given in GHz;...
Page 334: Results Tables With Wdm-Expert Software Option
Chapter 8 Optical Spectrum Measurement WDM-Expert Software option Osnr Avg. the average of the optical signal to noise ratio of a channel signal Osnr Min. the minimum of the optical signal to noise ratio of a channel signal Osnr Max. the maximum of the optical signal to noise ratio of a channel signal Osnr Delta...
Page 335 Chapter 8 Optical Spectrum Measurement WDM-Expert Software option Figure 157 Extended Table Content If a user-defined table content has been configured, the table differs according to the items selected for the results table: Figure 158 Example of user-defined results table User Manual 78000010220 Rev.
Page 336: Saving The Trace And Generating A Report
Chapter 8 Optical Spectrum Measurement Saving the trace and generating a report Saving the trace and generating a report Once the results page is displayed, the trace can be saved and a report can be gener- ated directly from the results screen. Saving results and creating a report from results page To generate a report: Press Fast Report menu key...
Page 337: Opening The Report
Chapter 8 Optical Spectrum Measurement Saving the trace and generating a report In the Direction parameter, select/modify the direction, to define if the measurement has been performed from Origin to Extremity (A -> B) or from Extremity to Origin (B -> A) In the Location A and Location B parameters, enter/modify the name of Origin and Extremity.
Page 338: Recalling Files
Example of OSA Report in pdf CAUTION To modify the Viavi logo, set by default on the header of the pdf report, save your logo in a jpg file called logo.jpg and place it to the root of the disk: disk >...
Page 339 Chapter 8 Optical Spectrum Measurement Saving the trace and generating a report Press F to open the Explorer. Select the directory and then the file to open Click on Load Click on View Tace(s) Load Trace + Config. The selected file is opened For further informations on file management, see Chapter 20 “File management”.
Page 340 Chapter 8 Optical Spectrum Measurement Saving the trace and generating a report User Manual 78000010220 Rev. 024...
Page 341: Osca-710 Optical Spectrum Measurement
OSCA-710 Optical Spectrum Chapter 9 Measurement This chapter describes the different stages in carrying out a spectrum analysis of an optical signal, or analyzing effects from an optical components or network elements like ROADMs, DFB-sources..., by a Platform 8000V2 equipped with an OSCA -710. The OSCA-710 series is only available on MTS / T-BERD 8000 V2 plat- forms.
Page 342 Chapter 9 OSCA-710 Optical Spectrum Measurement • “Trace display functions” on page 318 • “Table of results” on page 325 • “Testing ROADM networks” on page 326 • “Measuring POL-MUX (polarization mulitplexed ) channels” on page 328 • “File Management” on page 331 User Manual 78000010220 Rev.
Page 343: Laser Safety
Chapter 9 OSCA-710 Optical Spectrum Measurement Laser safety Laser safety The OSCA module contains a Class 1 Laser product according to DIN EN 60825-1. Please take notice of following instructions When the system or device is switched on, never look directly into the in- and output or into a connected optical fiber.
Page 344: Transportation
Using the original packing material ensures that the device is properly protected during shipping. Otherwise, VIAVI cannot give warranty on modules good protection. If you need a new packaging, please contact Viavi Technical Assis- tance Center. Configuration of the instrument...
Page 345: Osca Optical Spectrum Analyzer Setup
Chapter 9 OSCA-710 Optical Spectrum Measurement OSCA optical spectrum analyzer Setup Kind of input connector: • if the protection cap is green the optical input interface is a angled physical connector (APC-type) • if it is a black protection cap, the interface type is physical connector (PC-type) OSCA optical spectrum analyzer Setup To configure the 8000 V2 Platform in preparation for an OSCA test on a fiber, press the button.
Page 346 Chapter 9 OSCA-710 Optical Spectrum Measurement OSCA optical spectrum analyzer Setup Unit Show I-OSNR trace Configuration of the file set-up (see Chapter Filenaming [Cable_id][Fiber_Num][Test_Poin][Direction] Auto Store Nb Fiber Increment or define your own configuration Click on one parameter on the screen to display the possible options: make your choice using the direction keys , or using the touchscreen.
Page 347: Loading A Configuration File
Chapter 9 OSCA-710 Optical Spectrum Measurement OSCA optical spectrum analyzer Setup On Setup page, select one of the menu clicking on one of the menu key or press Main Menu to display the menu keys on the right of the screen. The various parameters proposed are defined below.
Page 348: Analysis Parameters
Chapter 9 OSCA-710 Optical Spectrum Measurement OSCA optical spectrum analyzer Setup Analysis parameters In the Setup page, press Analysis softkey (if one parameter is selected in the current screen, press Top Menu soft key to display the right menu keys and click on Analysis). Those parameters are only linked to the current active fiber.
Page 349 Chapter 9 OSCA-710 Optical Spectrum Measurement OSCA optical spectrum analyzer Setup NOTE At the end of an acquisition in permanent mode, it is possible to create a grid on the basis of the channels detected. To do this, press the key Adopt Grid in the S menu.
Page 350: Osnr
Chapter 9 OSCA-710 Optical Spectrum Measurement OSCA optical spectrum analyzer Setup OSNR To modify these parameters, go to the OSNR line. A sub-menu then appears proposing the following options: OSNR method (only available in OSNR mode) Side of the peak where the point of reference for noise measurement is taken (left, right, average left and right, worst case of left and right).
Page 351: Display Parameters
Chapter 9 OSCA-710 Optical Spectrum Measurement OSCA optical spectrum analyzer Setup Unit Choice of compensation in dB or as a percentage of the value measured. For example, with a 10 dB splitter, the results will be augmented by 10 dB. The trace will be offset upwards by 10 dB.
Page 352: Alarms
Chapter 9 OSCA-710 Optical Spectrum Measurement OSCA optical spectrum analyzer Setup Table 7 Grid menu options for each type of grid ITU DWDM Regular Manual Number of Editable, from 1 to 256 Editable, from 1 to 256 Editable from 1 to 256 channels by increments of 1 by increments of 1...
Page 353: Zoom Mode
Chapter 9 OSCA-710 Optical Spectrum Measurement OSCA optical spectrum analyzer Setup Composite power No or threshold modifiable from -59.9 dBm to +20 dBm Channel alarms Max channel offset No/Freq/Wavelen. Min. channel power Yes/No Max. channel power Yes/No Min. OSNR Yes/No Channel Number From «001»...
Page 354: Unit
Chapter 9 OSCA-710 Optical Spectrum Measurement Acquisition Center / Span manually selectable center /span. Unit Here the units of the x axis can be selected: • Frequency in THz • Wavelength in nm Table Content Standard The result table displays the columns Ch-Number, Ch-ID, Wavelength/Frequency, Spacing/Offset, Ch-Power, OSNR, Noise Acquisition...
Page 355: Display Of The Wdm / Osca Results
Chapter 9 OSCA-710 Optical Spectrum Measurement Trace display functions Display of the WDM / OSCA results The results window, obtained by pressing the R button, shows different zones ESULTS displaying, from top to bottom: • the mini-trace in the upper part of the screen, accompanied by the principal char- acteristics of the acquisition and of the file if the result is stored in memory.
Page 356: Display Functions
Chapter 9 OSCA-710 Optical Spectrum Measurement Trace display functions Display functions Zoom function The Zoom function is used to analyze part of the trace in greater detail. In association with Channel (WDM/OSCA) it enables rapid checking of a succession of events or chan- nels.
Page 357: Full Scale
Chapter 9 OSCA-710 Optical Spectrum Measurement Trace display functions Positioning the cursor When a trace is displayed, the key can be used to select one or both cursors. The direction keys move the selected cursor(s) along the trace. When a selected cursor touches the right or left-hand edge of the screen, the trace starts to scroll horizontally to maintain display of this cursor.
Page 358: Shift Function
Chapter 9 OSCA-710 Optical Spectrum Measurement Trace display functions Shift function The Shift function is used to displace the displayed section of the trace by pressing the direction keys. The horizontal shift is performed maintaining the point of intersection between the trace and the selected cursor at the same level, scrolling the trace horizontally while following it vertically, so that it never goes off the screen.
Page 359: Channel Detection Threshold
Chapter 9 OSCA-710 Optical Spectrum Measurement Trace display functions Table: display of the table alone Figure 164 OSCA Results - Table Channel detection threshold On the trace, some peaks corresponding to noise could be mistaken for channels. It is therefore necessary to fix a power threshold level: only peaks that exceed this threshold will be considered as channels and included in the table of results.
Page 360: Display Of Gain Tilt (Delta) And Gain Slope Results
Chapter 9 OSCA-710 Optical Spectrum Measurement Trace display functions Pressing the key Total Power A<-->B a second time removes the result of the total power measurement. Display of gain Tilt (delta) and gain slope results The 8000 V2 Platform can display two additional results: •...
Page 361: Table Of Results
Chapter 9 OSCA-710 Optical Spectrum Measurement Table of results Table of results Lines According to the choice made in the S menu, the table of results may include: ETUP • either a line for each channel detected (if Channel Selection = Permanent) •...
Page 362: Testing Roadm Networks
Chapter 9 OSCA-710 Optical Spectrum Measurement Testing ROADM networks Press the Channel Press to move the cursor to the following or preceding channel: Displaying relative results By default, the table gives the results in absolute values. To obtain these results in rela- tive values with respect to a reference channel: Press the Table Contents...
Page 363 Chapter 9 OSCA-710 Optical Spectrum Measurement Testing ROADM networks Here is a test setup for in-band OSNR testing. Figure 167 Test setup for In-band OSNR testing OSCA-710 OSCA-710 OSCA-710 OSCA-710 OSCA-710 Example: • OSNR measured with OSCA-710 at terminal site (1) provides value of 14dB •...
Page 364: Measuring Pol-Mux (Polarization Mulitplexed ) Channels
As the out-of-band OSNR measurements might not provide the 'TRUE' OSNR value for the above listed systems configurations, the POL-MUX OSNR measurement method based on VIAVI’s coherent spectral correlation technique must be selected. Press S until OSCA test setup appears.
Page 365 Chapter 9 OSCA-710 Optical Spectrum Measurement Measuring POL-MUX (polarization mulitplexed ) channels NOTE The preset min channel spacing is 50GHz, which works for most of the sys- tems. For other systems, the operator needs to enter the effective minimum system channel spacing of the WDM system. This is important for a correct approximation of the noise distribution inside the transmission band of the WDM channels.
Page 366: Performing Osnr Test In Wdm/Osnr Mode
Chapter 9 OSCA-710 Optical Spectrum Measurement Measuring POL-MUX (polarization mulitplexed ) channels Manual Settings: Reference Correlation As each transmitter system is a sophisticated complex optical device, the unit is not perfect. Therefore the characteristics of the transmitting laser will vary over various types, manufacturers, configurations etc.
Page 367: File Management
Chapter 9 OSCA-710 Optical Spectrum Measurement File Management Figure 168 Result trace of an OSNR measurement The table will show the following results: • Wavelen/Freq: will be displayed in nm or in THz • Spacing: channel spacing in THz • Level: total integrated channel power in dBm •...
Page 368: Recalling Osca Files
Chapter 9 OSCA-710 Optical Spectrum Measurement File Management Recalling OSCA files Once an OSCA file has been stored, recall it using the Explorer: Press F to open the Explorer. Select the directory and then the file to open. Press the Load soft key.
Page 369: Polarization Mode Dispersion Measurement
Polarization Mode Dispersion Chapter 10 Measurement This chapter describes the different steps in carrying out a PMD measurement with a Platform 8000 equipped with a 81PMD / 81DISPAP / 81MRDISPAP Module. The topics discussed in this chapter are as follows: •...
Page 370: Recommended Equipment
Chapter 10 Polarization Mode Dispersion Measurement Recommended equipment Recommended equipment To perform a PMD measurement, the following equipment is recommended: • Platform 8000 with a module as mentioned above, and associated optical connectors. • OBS-5XX Optical Broadband Source, or 81BBS1A and 81BBS2A Optical broad- band source modules.
Page 371: Setup Menu
Chapter 10 Polarization Mode Dispersion Measurement PMD Activation and self calibration Press S hard key. ETUP On bottom right of setup page, press Load Config. menu key. In the Explorer, select the desired file configuration Press Load Config. menu keys. A beep is emitted to validate the selection of the configuration file.
Page 372: Acquisition Parameters
Chapter 10 Polarization Mode Dispersion Measurement PMD Activation and self calibration File – Filenaming: Auto : [Cable_Id][Fiber_Num][Direction] – Auto store: Yes Figure 169 PMD Test setup menu See OTDR Setup: “Configuring the Link parameters” on page 43 See OTDR Setup: “Configuring the File parameters”...
Page 373 Chapter 10 Polarization Mode Dispersion Measurement PMD Activation and self calibration Sweep (Not available when used with the Polarisation scrambler Module in High Resolution PMD mode) Continue Continuous measurement with a trace refresh and a real-time display of the results. Single Single measurement with associated results displayed.
Page 374: Alarms Parameters
Chapter 10 Polarization Mode Dispersion Measurement PMD Activation and self calibration Last zero (Only when used with the Polarization scrambler module in High Resolution PMD mode) This parameter displays the date and time of the last reference. Number of sweeps (not available when used with the Polarization scrambler module in High Resolution PMD mode) Number of acquisitions from 2 to 1000.
Page 375: Analysis Parameters
Chapter 10 Polarization Mode Dispersion Measurement PMD Activation and self calibration Alarms Status None No Pass/Fail thresholds selected. Active Pass/Fail analysis will be made upon defined thresholds: auto values or delay. Auto Values Threshold values entered manually. Threshold values automatically calculated according to the bit rate info selection.
Page 376 Chapter 10 Polarization Mode Dispersion Measurement PMD Activation and self calibration Fiber length Unknown If you do not know the fiber length Distance Press Edit Number to enter fiber distance: Min=0.100 km / Max=20000 km The fiber length must be set to calculate the PMD coefficient. Distance Unit When the fiber length is manually entered, choose the distance unit Distance unit defined in kilometers.
Page 377: Saving Configuration In A File
Chapter 10 Polarization Mode Dispersion Measurement Performing a PMD measurement with a PMD test module Saving configuration in a file Once parameters have been configured, they can be kept in memory and saved in a configuration file. This configuration file can then be recalled in order to be recalled for future PMD acqui- sitions.
Page 378: Remote Operator
Chapter 10 Polarization Mode Dispersion Measurement Performing a PMD measurement with a PMD test module • 81BBS1A • 81BBS2A The following procedure considers the use of an OBS-5xx type source. Remote operator Inspect and clean connectors with appropriate methods as described in IEC 61300-3-35 Connect the fiber under test to the optical connector of the broadband source using required mating solution such as a fiber patchcord.
Page 379: Performing A High Resolution Pmd Measurement
Chapter 10 Polarization Mode Dispersion Measurement Performing a High Resolution PMD measurement Figure 170 PMD measurement with an ODM plug-in Fiber under test fiber patchcords OBS-5XX Optical connector of the 81DISPAP/ 81MRDISPAP module Performing a High Resolution PMD measurement The HR PMD measurement requires a polarization scrambler module (PSM) to be connected to the PMD module, and the use of the 81BBS1A broadband source module at the other end of the fiber under test.
Page 380 Chapter 10 Polarization Mode Dispersion Measurement Performing a High Resolution PMD measurement To perform a reference, connect your Broadband source 81BBS1A to the PSM module as shown below: Figure 171 Interconnection of 81BBS1A and PSM modules Coupler Jumper Signal input connector on the PSM module...
Page 381: Performing The Measurement
Chapter 10 Polarization Mode Dispersion Measurement Performing a High Resolution PMD measurement NOTE When performing a PMD reference, acquisition parameters are not taken in account, except for averaging. Press the button S to start referencing of the broadband source. TART NOTE Performing a reference measurement can take several minutes (minimum 2 min 30).
Page 382: Display Of Results
Chapter 10 Polarization Mode Dispersion Measurement Display of results Select the appropriate PMD test parameters according to your application as earlier defined in this chapter. Press the S button to start measuring. TART Figure 173 HR PMD measurement Fiber under test Jumper fiber patchcords Signal input connector on the...
Page 383 Chapter 10 Polarization Mode Dispersion Measurement Display of results • The information bar with: – module reference – number of acquisitions used for the statistics (Acq) – wavelength range (1525-1610 nm), – fiber number (N:) – fiber length in defined unit –...
Page 384: Cursors, In Spectrum Display
Chapter 10 Polarization Mode Dispersion Measurement Display of results NOTE When several acquisitions are performed, the trace resulting from the last acquisition is displayed. Cursors, in spectrum display To move the cursor(s) on the trace: Press Cursor A / Cursor B menu key to select one or both cursor(s). Use the direction arrow keys With touchscreen, directly press on trace to position the cursor(s) The coordinates of each cursor intersection with the trace are indicated under-...
Page 385: Statistics Results
Chapter 10 Polarization Mode Dispersion Measurement Statistics results Statistics results Statistics can be performed on a series of samples defined by the number of samples and the time between two consecutive samples (Wait period). Refer to “Acquisition parameters” on page 336 for parameter setup.
Page 386: Information Messages
Chapter 10 Polarization Mode Dispersion Measurement Statistics results In Drift mode, the cursor can be moved on each measurement by clicking on the key Previous Acq. or Next Acq. • The histogram providing the delay value for each acquisition. Figure 176 Example of histogram Information messages Under the trace, at the right-hand corner a message indicates the current status of the...
Page 387: Saving The Trace And Generating A Report
Chapter 10 Polarization Mode Dispersion Measurement Saving the trace and generating a report Ready to start Measurement The message is displayed after the completion of an acquisition sample or a Reference measurement. Waiting bar graph When Statistic mode is used and Long term is set to Period, a bargraph displays, the remaining time before the next acquisition.
Page 388 Chapter 10 Polarization Mode Dispersion Measurement Saving the trace and generating a report Figure 177 Fast report configuration In the Save Mode parameter, select: txt file select Yes to save the results in a blts file and to generate a txt file of the results.
Page 389: Opening The Report
Chapter 10 Polarization Mode Dispersion Measurement Saving the trace and generating a report Once saving is completed, a sound is emitted onto the Platform. NOTE The trace and the report are saved in the last storage media and directory selected. Opening the report To open the report: Press F...
Page 390: Recalling Pmd Files
Example of PMD Report in pdf CAUTION To modify the Viavi logo, set by default on the header of the pdf report, save your logo in a jpg file called logo.jpg and place it to the root of the disk: disk >...
Page 391: Pmd Standards And Limits
Chapter 10 Polarization Mode Dispersion Measurement PMD standards and limits Press F to open the Explorer. Select the directory and then the file to open Press the Load soft key. Press View Trace(s) Load Trace + Config. The selected file is opened For further informations on file management, see Chapter 20 “File management”.
Page 392 Chapter 10 Polarization Mode Dispersion Measurement PMD standards and limits User Manual 78000010220 Rev. 024...
Page 393: I-Pmd Measurement
This chapter describes the different steps in carrying out an In-Service and In-Band PMD-OSNR with a T-BERD/MTS 8000 V2 equipped with 81IPMD and 81PSM Modules. Viavi's non-intrusive technique used in I-PMD enables to measure PMD in a link that is in-service by using the transmission DWDM channels.
Page 394: Recommended Equipment
Chapter 11 I-PMD Measurement Recommended equipment Recommended equipment To perform an In-Band PMD measurement, the following equipment is recommended: • T-BERD/MTS 8000V2 mainframe with a 81IPMD module, and associated optical connectors. • one PSM Module and associated optical connectors. • Fiber inspection scope with associated optical connector tips.
Page 395: Loading A Configuration File
Chapter 11 I-PMD Measurement I-PMD Activation and Configuration Figure 179 I-PMD Test Setup menu See OTDR Setup: “Configuring the Link parameters” on page 43 See OTDR Setup: “Configuring the File parameters” on page 48 Loading a configuration file To load the configuration file to be used for IPMD test: Press S hard key.
Page 396: Acquisition Parameters
Chapter 11 I-PMD Measurement I-PMD Activation and Configuration Acquisition parameters In the Setup screen, First, select PMD/I-OSNR on the parameter Mode, Then select the following parameters for acquisition: PMD Mode Select the acquisition mode in the parameter: Channel Acquisition will be performed on one G.694.1 Channel Grid Acquisition will be performed on multiple channels defined in a grid Acquisition will be performed with BBS inserted, instead of Transmis-...
Page 397: Analysis Parameters
Chapter 11 I-PMD Measurement I-PMD Activation and Configuration Number of Scans Define the number of scans to perform (from 1 to 1000). This mode also gives access to the following parameters: Long Term and Time Interval between scan if more than 1 scan is selected.
Page 398: Splitter Compensation
Chapter 11 I-PMD Measurement I-PMD Activation and Configuration Noise Shape Filtered evaluation for mixed filter shaped ROADM networks Unfiltered evaluation for networks without optical filters Noise Acq. Bandwidth Reference bandwidth used for the acquisition of noise Standard 0.1 nm Values lie between 0.05 nm and 1.0 nm. OSNR meas.type Selection of OSNR calculation: S / N or (S+N)/N Splitter Compensation...
Page 399: Display
Chapter 11 I-PMD Measurement I-PMD Activation and Configuration Display Alarms To define alarm thresholds for IPMD measurement , select Alarm parameter, and in the sub-menu displayed, configure the alarm values: None No, Pass/Fail thresholds selected. Active Pass/Fail analysis will be made upon defined thresholds: auto values or delay.
Page 400: Performing A Zero Reference
Chapter 11 I-PMD Measurement Performing a Zero Reference If necessary, press S to return to Setup page. ETUP Select one parameter in one of the setup page (acquisition, link..) Press Save Config. menu key Enter a name for the configuration file using the edition keypad (max 20 charac- ters).
Page 401: Performing An In-Band Pmd-Osnr Measurement With An I-Pmd
Chapter 11 I-PMD Measurement Performing an In-Band PMD-OSNR measurement with an I-PMD Module Figure 180 Zero reference screen Performing an In-Band PMD-OSNR measurement with an I-PMD Module Installation Once I-PMD setup has been correctly configured: Connect a jumper between the I-PMD module and the PSM output port. Connect the fiber to be tested to the PSM input port.
Page 402: Detection Of Channels
Chapter 11 I-PMD Measurement Performing an In-Band PMD-OSNR measurement with an I-PMD Module Figure 181 Modules interconnections To test Access/ Short patchcord to Monitor port interconnect I-PMD and PSM modules Module I-PMD Module Detection of Channels If the list of DWDM channels to be tested is unknown, it is possible to run a quick scan in order to detect all available frequencies: Press Detect Channels menu key in order to start the detection of channels.
Page 403: In Band Pmd-Osnr Measurement
Chapter 11 I-PMD Measurement Performing an In-Band PMD-OSNR measurement with an I-PMD Module Figure 182 Channel detection step 3 step 4 Check all channels have been detected. If not, add or remove channels: Press Table Contents menu key Press Add Channel or Remove Channel menu key. Press Adopt Detected Channels menu key to adopt detected channels to the acquisition grid.
Page 404: Display Of Results
Chapter 11 I-PMD Measurement Display of results Figure 183 View Setup Grid If necessary, channels can be added/removed from this screen. Press Exit to return to the Setup menu Enter the number of scans to be performed (see Figure 179 on page 359) using the parameter Number of Scans,.
Page 405: Osa Results
Chapter 11 I-PMD Measurement Display of results OSA Results OSA menu key Check Osa function is selected on the menu key The spectrum results page is displayed as below: Figure 184 Example of OSA Results Instantaneous Effective DGD In-Band noise measurement measured for each for each channel...
Page 406 Chapter 11 I-PMD Measurement Display of results The table of results (without statistics): If only one scan is performed, no statistics are available, and the results table contains the following results: – the channel number – the frequency or the wavelength of the channel, according to the unit selected in the Setup menu –...
Page 407: Moving The Cursors
Chapter 11 I-PMD Measurement Display of results Figure 185 Example of OSA Results with statistics NOTE When several scans are performed, only the trace resulting from the last scan is displayed. Moving the cursors To move the cursor(s) on the trace: Press soft key Cursor A / Cursor B menu key,...
Page 408: Trace Shift
Chapter 11 I-PMD Measurement Display of results Use the direction keys to zoom in either horizontally or verti- cally. Use the touchscreen to position upper left and bottom right location of the zoom area The zoom is made around the selected cursor(s). NOTE To reset the zoom and see the full trace, press Full...
Page 409 Chapter 11 I-PMD Measurement Display of results Figure 186 Results table - one single line • on half of the screen (see Figure 184 on page 369) • on the whole screen Figure 187 Results table in full screen User Manual 78000010220 Rev.
Page 410: Pmd Results
Chapter 11 I-PMD Measurement Display of results Cursor X / Cursor Y menu key: Two types of cursors can be defined: – Cursor on X: only a vertical bar is present. – Cursor on X and Y: there is a vertical bar and a horizontal bar. The inter- section between these two bars is placed on the trace.
Page 411: Performing A Pmd Measurement With Bbs And Ipmd Module
Chapter 11 I-PMD Measurement Performing a PMD Measurement with BBS and IPMD Module Performing a PMD Measurement with BBS and IPMD Module The following modules apply: • E81PMD with E81PSM Handheld or module broadband sources can be used to perform PMD measurements: •...
Page 412: Display Of Results
Chapter 11 I-PMD Measurement Performing a PMD Measurement with BBS and IPMD Module Select the I-PMD function in the Home page and wait for the module self calibra- tion (tuning). Press the S button to access the IPMD Test Setup menu (see Figure 179 on ETUP page...
Page 413 Chapter 11 I-PMD Measurement Performing a PMD Measurement with BBS and IPMD Module Figure 190 Example of OSA BBS Results Instantaneous Effective DGD measurement for each channel Optical Spectrum Analysis with Frequency The OSA results screen is split in 3 main areas. from top to bottom: The information bar with: –...
Page 414: Functions On Trace Display
Chapter 11 I-PMD Measurement Performing a PMD Measurement with BBS and IPMD Module Figure 191 Example of OSA - BBS Results with statistics NOTE When several scans are performed, only the trace resulting from the last scan is displayed. Functions on trace display Several functions are available in results page, in OSA or PMD view, using the menu keys: •...
Page 415: File Management
Chapter 11 I-PMD Measurement File Management File Management Saving results If Auto store is selected, results are saved automatically. If not, or if you want to store the results under another name/directory etc.: Click on the F Click on Save >...
Page 416 Chapter 11 I-PMD Measurement PMD standards and limits Bit Rate Per Equivalent PMD Delay SONET Channel Time-slot Limit 10 Gbit/s STM-64 OC-192 100 ps 10 ps 40 Gbit/s STM-256 OC-768 25.12 ps 2.5 ps 10G Ethernet Ethernet 5 ps User Manual 78000010220 Rev.
Page 417: High Resolution Osa Measurement
High Resolution OSA Chapter 12 Measurement This chapter describes the different stages in carrying out a spectrum analysis of an optical signal, or analyzing effects from an optical components or network elements like DFB-sources by a Base Unit equipped with a High Resolution OSA. NOTE The HROSA-C and OSA610 series are available on T-BERD/MTS 8000 V2 and T-BERD/MTS 6000A V2platforms.
Page 418: Cleaning Of Connectors
Chapter 12 High Resolution OSA Measurement Cleaning of Connectors Cleaning of Connectors Cleaning of the patchcord connector is extremely important to avoid damage to the input of the OSA. A dirty connection can irreversibly damage both surfaces, especially when working with high powers. We highly recommend inspection of the patchcord before connecting it to the OSA.
Page 419: Osa Optical Spectrum Analyzer Setup
Chapter 12 High Resolution OSA Measurement Configuration of the instrument A beep is emitted to validate the selection of the configuration file. The software automatically brings you back to setup page. NOTE Most of the configuration files are available into the Platform in disk/con- fig/IPMD.
Page 420: Acquisition Parameters
Chapter 12 High Resolution OSA Measurement Configuration of the instrument Figure 192 Setup for optical spectrum measurements See OTDR Setup: “Configuring the Link parameters” on page 43 See OTDR Setup: “Configuring the File parameters” on page 48 Acquisition Parameters Sweep Continue The OSA sweeps continuously and displays the results Single...
Page 421 Chapter 12 High Resolution OSA Measurement Configuration of the instrument Averaging acquisition Select between "No" and 64 times averaging. Resolution Select the resolution bandwidth used for HR OSA acquisition (depends of the module used). Coarse Scan The coarse mode provides a faster scan over multiple channels at the cost of a degraded frequency accuracy.
Page 422: Analysis Parameters
Chapter 12 High Resolution OSA Measurement Configuration of the instrument Time Interval between Scans This parameter allows to enter a wait period before the measurement start (only active if Long Term is positioned on Yes, in Continue or Statistics mode) •...
Page 423 Chapter 12 High Resolution OSA Measurement Configuration of the instrument Min. Channel elevation Defines the minimum elevation of two adjacent peaks from the valley between them which is required to recognize independent channels. Peaks which are not separated by a valley deeper than the min.channel elevation are considered as part of the same optical channel.
Page 424 Chapter 12 High Resolution OSA Measurement Configuration of the instrument - Pre-defined: select 25 GHz (0.2 nm), 50 GHz (0.4 nm),100 GHz (0.8 nm) from the peak. - Left & Right: manually define different left and right distances from the peak Noise Acq.
Page 425: Saving Configuration In A File
Chapter 12 High Resolution OSA Measurement Acquisition • Wavelength in nm Those parameters are valid for all traces present on the screen. Saving configuration in a file Once parameters have been configured, they can be kept in memory and saved in a configuration file.
Page 426: Trace Display Functions
Chapter 12 High Resolution OSA Measurement Trace display functions Trace display functions The trace acquired or recalled from a memory is displayed on the Results page: see example Figure 193 on page 391. A range of functions enable modifications to the display of the trace (Cursors, Zoom/ Shift, Event/Trace, Trace/Table, Full scale, etc.).
Page 427: Display Functions
Chapter 12 High Resolution OSA Measurement Trace display functions Figure 193 Example of OSA test result (with grid) Fiber number Filename Mini-trace display Wavelengths and power at point of trace referenced by cursors A and B Channel Wavelength and power difference between cursors A and B Number of the channel...
Page 428: Cursors Function
Chapter 12 High Resolution OSA Measurement Trace display functions Use touchscreen and click on trace to position the upper left and bottom right corners of the zoomed area. Zooming on the different channels in succession Zoom on one of the channels as shown above. On the Trace/Channel key, select the...
Page 429: Full Scale
Chapter 12 High Resolution OSA Measurement Trace display functions • Cursor X: only a vertical bar is present. • Cursor X and Cursor Y: there is a vertical bar and a horizontal bar. The intersec- tion between these two bars is placed on the trace. To display the type of cursor selected: Click on Advanced.
Page 430 Chapter 12 High Resolution OSA Measurement Trace display functions Trace alone: main display of the trace with a single line of the table at the foot of the page (see“Example of OSA test result (with grid)” on page 391). Trace + Table: display of trace, reduced in size but followed by 5 to 8 lines of the table of results.
Page 431: Channel Detection Threshold
Chapter 12 High Resolution OSA Measurement Trace display functions Channel detection threshold On the trace, some peaks corresponding to noise could be mistaken for channels. It is therefore necessary to fix a power threshold level: only peaks that exceed this threshold will be considered as channels and included in the table of results.
Page 432: Overlay Trace Function
Chapter 12 High Resolution OSA Measurement Overlay trace function Overlay trace function This very useful function enables up to eight traces to be displayed on the screen at once: • either to compare traces acquired on a number of different fibers in the same cable, •...
Page 433: Display Of Traces In Overlay
Chapter 12 High Resolution OSA Measurement Overlay trace function NOTE In the case of Multi-trace display with multiple wavelength acquisition: when the S key is pressed, all the traces displayed are deleted to leave room TART for the new acquisitions. Display of traces in overlay •...
Page 434: Changing The Traces Position
Chapter 12 High Resolution OSA Measurement Overlay trace function Changing the traces position Once a trace is displayed in overlay, the traces can be adjusted according to the Y axis: Press Advanced > Overlay menu keys. Select the adjustment according to Y axis: Reset: all traces are on the the same level at the intersection with the active cursor.
Page 435: Quitting The Overlay Menu
Chapter 12 High Resolution OSA Measurement Table of results Removing all the traces To remove all the traces except the current trace, press the key Remove Other Traces. Quitting the overlay menu To quit the overlay menu, press the Exit key.
Page 436: On/Off-Osnr Method
Chapter 12 High Resolution OSA Measurement On/Off-OSNR Method Indicates the noise level measured left and right of the peak of the optical channel (out-of-band noise measurement), in the defined resolution. The optical signal to noise ratio for the channel in dB. In WDM mode this parameter indicates the out of band SNR result based on the out-of-band noise measurement.
Page 437: Setup
Chapter 12 High Resolution OSA Measurement On/Off-OSNR Method Switch-off the channel carrying PDM signals and perform a second measure- ment The channel power measured at the deactivated channel wavelength will indicate the in-band noise Poff = noise power In-band OSNR is calculated based on Pon and Poff Setup In the Acquisition setup screen, set the parameter Mode to OO-OSNR and configure the measurement as wished (see...
Page 438: Limitations
Chapter 12 High Resolution OSA Measurement DFB results analysis Noise power is measured at the center frequency of the switched-off channels. Noise power is normalized to Noise Acq BW (i.g. 0.1nm) according to the setup param- eter. OSNR will be calculated and displayed in the table based on stored P_ch (step 1). Limitations The On/Off-OSNR method requires an intervention into the optical system as the optical channel to be measured needs to be switched-off.
Page 439: Dfb Measurements
Chapter 12 High Resolution OSA Measurement DFB results analysis In the Acquisition setup screen, set Mode on DFB. A new DFB sub-menu is offered while other Setup parameters are the same for DFB as for WDM measurements. Refer to “OSA optical spectrum analyzer Setup” on page 383 for a complete description.
Page 440: Dfb Results
Chapter 12 High Resolution OSA Measurement DFB results analysis Cursors A and B are automatically positioned on the first DFB laser, respectively on the max SMSR and the pick of the main component. DFB results A table is displayed (see “DFB measurements”...
Page 441: File Management
Chapter 12 High Resolution OSA Measurement File Management File Management Storing HR-OSA measurements If Auto store has been selected, then results will be saved automatically. If not, or if you want to save the results under another name, directory etc.: Click on F Click on Save...
Page 442 Chapter 12 High Resolution OSA Measurement File Management User Manual 78000010220 Rev. 024...
Page 443: Attenuation Profile
Attenuation profile Chapter 13 This chapter describes the different steps in carrying out a Attenuation Profile (AP) measurement with a Platform 8000 V2 equipped with a 81DISPAP or 81 MRDISPAP Module. The topics discussed in this chapter are as follows: •...
Page 444: Recommended Equipment
Chapter 13 Attenuation profile Recommended equipment Recommended equipment To perform a AP measurement, the following equipment is recommended: • Platform 8000 V2 with a module as referenced above, and required optical connector. • OBS-5XX,the BBS1A or BBS2A with required optical connectors. •...
Page 445: Setup Menu
Chapter 13 Attenuation profile AP Activation and self calibration Setup Menu The different test and display parameters are described below: Figure 200 Configuration menu for AP test See: “Configuring the File See: “Configuring the Link parameters” on page 48 parameters” on page 43 Test Auto configuration The Test Auto soft key sets all parameters to auto or default values and let the unit to choose the appropriate setup, as listed below.
Page 446: Acquisition Parameters
Chapter 13 Attenuation profile AP Activation and self calibration Acquisition parameters Acquisition band (with 81DISPAP modules) OESCL measurement performed over the full wavelength range (OESCL bands). measurement performed over a wavelength range limited to S,C and L bands NOTE In case of OBS5xx handheld sources, the measurement will be performed exclusively on SCL band.
Page 447: Last Reference / Bbs Type / Bbs Serial Number
Chapter 13 Attenuation profile AP Activation and self calibration Last Reference / BBS Type / BBS Serial Number These parameters provide the relevant information related to the Broadband source (BBS) referencing. These parameters cannot be modified as they are automatically generated after a refer- ence measurement (see “Performing the reference”...
Page 448: Display
Chapter 13 Attenuation profile AP Activation and self calibration Display Wavelength It enables to configure the range of wavelengths to be displayed on the graph and in the table of results. Full Displays results along the full available wavelength range S+C+L Band Displays results along S, C + L bands.
Page 449: Ap Reference Measurement
Chapter 13 Attenuation profile AP Reference Measurement Select one parameter in one of the setup page (acquisition, link..) Press Save Config. menu key Enter a name for the configuration file using the edition keypad (max 20 charac- ters). NOTE Configuration file is saved in the directory disk/config/AP. Press Enter to validate A sound is emitted to indicate the file is saved.
Page 450 Chapter 13 Attenuation profile AP Reference Measurement Figure 201 Reference measurement setup Mating adapter OBS-5XX Fiber patchcord Signal input connector of the 81DISPAP or 81 MRDISPAP module Activate the source on the distant Unit, and select AP function. In the AP Setup page, press the Acq.
Page 451 Chapter 13 Attenuation profile AP Reference Measurement Press Yes in the dialog box to start reference and wait for the end of reference measurement. Once the reference is correct, the message "ready to start Measurement" appears in the blue bar. Figure 203 Example of a reference for a broadband source A bargraph indicates the source power level...
Page 452: Saving A Reference Measurement
Chapter 13 Attenuation profile Performing a AP measurement Saving a reference measurement When the reference measurement of the broadband source has been completed, you can save the result on the hard disk or disk of the Base Unit (8000V2 or 6000/6000A Platform).
Page 453: Display Of Ap Results
Chapter 13 Attenuation profile Display of AP results Press the S button to see the results within a few seconds. TART Repeat step 1 to 4 for every fiber to be tested. NOTE When the composite power of the input signal is higher than +20 dBm, a warning is displayed and the signal is cut off.
Page 454: Trace Display
Chapter 13 Attenuation profile Display of AP results Trace display Figure 204 Example of a AP result Fiber Length File name Wavelength range Attenuation profile Curve Results table (see “Results table” on page 420) Spectrum/Profile For a reference measurement, only the spectrum is available. For a AP measurement, two different graphs may be displayed.
Page 455: Zoom
Chapter 13 Attenuation profile Display of AP results Figure 205 Example of a spectrum view after a measurement • Profile: it provides the difference between the final spectrum and the reference spectrum of the broadband source- that’s the resulting attenuation profile (see figure “Example of a AP result”...
Page 456: Trace Shift
Chapter 13 Attenuation profile Display of AP results NOTE To reset the zoom and see the full trace, press Full scale. Trace shift To shift the trace horizontally or vertically: Press the Zoom/Shift menu key to select Shift Use the arrow keys to make the required shift.
Page 457 Chapter 13 Attenuation profile Display of AP results The menu key Trace/Table/Summary enables to display either: the trace and 1 line of the table (see Figure 204 on page 418). the trace and 8 lines of the table Figure 206 AP Profile - Trace and Results table the trace and a summary of the results Figure 207...
Page 458: Saving The Trace And Generating A Report
Chapter 13 Attenuation profile Saving the trace and generating a report : the table only Figure 208 AP Profile -Results table The results table provides, for each wavelength (calculated using the wavelength range and the incrementation parameter as seen in “Wavelength”...
Page 459 Chapter 13 Attenuation profile Saving the trace and generating a report A menu displays under the trace. In the menu, configure the file saving (and the report) Figure 209 Fast report configuration In the Save Mode parameter, select: File Only to save exclusively the trace in a ats file File + txt to save the trace in a ats file and to generate a txt file of the results File + pdf to save the trace in a ats file and to generate a report of the trace and results in a pdf file...
Page 460: Opening A Report
Chapter 13 Attenuation profile Saving the trace and generating a report Once saving is completed, a sound is emitted onto the Platform.. NOTE The file and the report are saved in the last storage media and directory selected. Opening a report To open the report, press F hardkey In the Explorer page, in the directory selected, select the pdf file of the report.
Page 461: Recalling Ap Files
Saving the trace and generating a report CAUTION To modify the Viavi logo, set by default on the header of the pdf report, save your logo in a jpg file called logo.jpg and place it to the root of the disk: disk >...
Page 462 Chapter 13 Attenuation profile Saving the trace and generating a report User Manual 78000010220 Rev. 024...
Page 463: Cd Measurements Using Phase Shift Method
CD measurements using Chapter 14 phase shift method The Chromatic Dispersion analyzer function using phase shift method is available through the 81DISPAP, 81MRDISPAP and 81CD modules and is described in this chapter. Topics discussed in this chapter are as follows: •...
Page 464: Cd Activation And Self Calibration
Chapter 14 CD measurements using phase shift method CD activation and self calibration CD activation and self calibration Press the H button Select the function Press the button R to display the auto-calibration status. ESULTS A bargraph tuning in progress informs of the progression status of the calibra- tion at the bottom of the screen.
Page 465 Chapter 14 CD measurements using phase shift method Configuring the CD test Amplified Link: No (refer to “Performing a CD measurement through amplifiers” on page 439) RESULTS SCREEN Normalized to km Show Measured pointsNo Show Fit Formula Storage parameters (see Chapter 20 “File management”): –...
Page 466: Loading A Configuration File
Chapter 14 CD measurements using phase shift method Configuring the CD test The configuration parameters of the CD test are described below. Loading a configuration file To load the configuration file to be used for CD test: Press S hard key. ETUP On bottom right of setup page, press Load Config.
Page 467: Reference
Chapter 14 CD measurements using phase shift method Configuring the CD test Power Level This parameter enables to get a power level indication at the start of an acquisition (only with 81DISPAP or 81MRDISPAP modules). the received power is not indicated before starting the measurement acquisition.
Page 468: Analysis Parameters
Chapter 14 CD measurements using phase shift method Configuring the CD test Auto values: No Dispersion Threshold value is entered manually: select the maximum dispersion threshold (ps/nm) : from >1 to > 10000 ps/nm. NOTE Max. dispersion threshold is always considered for non normalized disper- sion values.
Page 469 Chapter 14 CD measurements using phase shift method Configuring the CD test Approx. formula Select the approximation formula to be used for generation of the delay, dispersion and slope curves: Please refer to ITU-T G.650.1 or IEC 60793 1-42 for further information. Quadratic A+Bλ+Cλ...
Page 470: Saving Configuration In A File
Chapter 14 CD measurements using phase shift method Configuring the CD test Manual Displays results between 2 user defined wavelengths. The user must then select the inf. wavelength to "start” with and the sup. wave- length to "end" with. NOTE This parameter cannot be configured if, in Measurements box, the parame- ter Fiber Length is defined to Unknown.
Page 471: Cd Reference Measurement
Chapter 14 CD measurements using phase shift method CD Reference measurement Select one parameter in one of the setup page (acquisition, link..) Press Save Config. menu key Enter a name for the configuration file using the edition keypad (max 20 charac- ters).
Page 472 Chapter 14 CD measurements using phase shift method CD Reference measurement Figure 212 Reference measurement setup Mating adapter Fiber patchcord OBS-55 Signal input connector of the 81DISPAP or 81 MRDISPAP module Activate the source on the distant Unit., and select CD function. In the CD Setup page, press the Acq.
Page 473: Saving A Reference Measurement
Chapter 14 CD measurements using phase shift method CD Reference measurement Enter a serial number for the broadband source used. Press the button S to start the reference of the broadband source. TART A bargraph as this one is displayed until the end of the acquisition.
Page 474: Loading Existing Reference
Chapter 14 CD measurements using phase shift method Performing a CD Measurement The file has the extension ".OCD", but differs from the CD measurement result files as it only contains the reference points (the information on the upper part of the screen are different).
Page 475: Performing A Cd Measurement Through Amplifiers
Connect the source and the 81DISPAP/81MRDISPAP module at each end of the fiber under test. Optical attenuators (OLA55 1 and OLA55 2) have to be posi- tioned before and after the amplified link. Viavi recommends to: • setup the front attenuator (OLA55 #1) so that the power level received by the amplifier is 10 dB lower than the in-service power level (in normal operation).
Page 476: Display Of Cd Results
Chapter 14 CD measurements using phase shift method Display of CD results Amplified Network 81BBSXX or 81DISPAP or OLA 55 #1 OLA 55 #2 OBS-5XX 81MRDISPAP Psource=Pi - 10dB Ptester=- 10dBm max Press the S button to access the CD configuration menu. ETUP Select the appropriate CD test setup according to your application as earlier defined in...
Page 477: Functions Available
Chapter 14 CD measurements using phase shift method Display of CD results Figure 215 Delay Curve Fit Formula Measured points Normalized to km The information provided with the delay curve may be different depending on to the parameters settings. In the Figure 215, the following parameters have been configured: •...
Page 478: Trace/Table
Chapter 14 CD measurements using phase shift method Display of CD results Figure 216 Example of the Slope display Trace/Table The menu key Trace/Table/Summary enables to display either: : the trace and 7 lines of the table (see Figure 216 on page 442) the trace and a summary of the results User Manual...
Page 479 Chapter 14 CD measurements using phase shift method Display of CD results Figure 217 CD Delay - Trace and Summary : the table only Figure 218 Results Table Move from 7 lines table to full table using menu key Trace/Table. The results table displays the following values for each wavelength (depending on the range and increment defined in the Setup menu): User Manual...
Page 480: Cursor, Zoom And Shift Functions
Chapter 14 CD measurements using phase shift method Display of CD results • Delay • Total dispersion • Dispersion Coefficient (if Normalized to km is set to in the Setup menu. If not, this column is empty). • Slope The blue line at the top of the table displays the following information: •...
Page 481: Wavelength
Chapter 14 CD measurements using phase shift method Saving the trace and generating a report Shifting the trace To shift the trace horizontally or vertically: Press the Zoom/Shift soft key to select Shift function. Use the direction arrow keys With touchscreen, touch and hold the screen to make the required shift. Wavelength To move the cursor from one wavelength to the next one, Press the Wavelength key...
Page 482 Chapter 14 CD measurements using phase shift method Saving the trace and generating a report Figure 219 Fast report configuration In the Save Mode parameter, select: File Only to save exclusively the trace in a ocd file File + txt to save the trace in a ocd file and to generate a txt file of the results File + pdf to save the trace in a ocd file and to generate a report of the trace and results in a pdf file...
Page 483: Opening A Report
Chapter 14 CD measurements using phase shift method Saving the trace and generating a report The icon displays during saving process. Once saving is completed, a sound is emitted onto the Platform. NOTE The file and the report are saved in the last storage media and directory selected.
Page 484: File Signature
Example of CD ODM Report CAUTION To modify the Viavi logo, set by default on the header of the pdf report, save your logo in a jpg file called logo.jpg and place it to the root of the disk: disk > logo.jpg.
Page 485: Recalling Reference Or Cd Measurement Files
Chapter 14 CD measurements using phase shift method Saving the trace and generating a report The Reference measurement and the CD measurement files have both the extension ".ocd" but can be differentiated by the information displayed in the File signature, on upper part of the screen: Figure 221 File Signature for Reference and CD measurement...
Page 486 Chapter 14 CD measurements using phase shift method Saving the trace and generating a report User Manual 78000010220 Rev. 024...
Page 487: Chapter 15 Broadband Source Bbs
Broadband source BBS Chapter 15 This chapter describes the function of the BBS (Broadband Source) module and its use. The topics discussed in this chapter are as follows: • “Function of the BBS module” on page 452 • “Activation process” on page 452 •...
Page 488: Function Of The Bbs Module
Chapter 15 Broadband source BBS Function of the BBS module Function of the BBS module The broadband source (BBS) module, covers two different wavelengths: • from 1260 to 1640 nm with the 81BBS2A • from 1460 to 1640 nm with the 81BBS1A. They are used to measure the attenuation profile, chromatic dispersion and PMD of optical fibers.
Page 489: Remote Interlock Connector
Chapter 15 Broadband source BBS Remote interlock connector If a CD mode is selected, the key Full Band/SCL Band is displayed and allow to select transmitted wavelength range. Configuration with the 81BB1A module Figure 223 Configuration of the BBS1A Select CD, AP/PMD or ALL transmission mode to perform the corresponding test using the 81DISPAP or 81MRDISPAP module.
Page 490 Chapter 15 Broadband source BBS Remote interlock connector Figure 224 Remote interlock connector Remote interlock connector User Manual 78000010220 Rev. 024...
Page 491: Chapter 16 Multi Test Access Unit
Multi Test Access Unit Chapter 16 This chapter describes the function of the MTAU (Multi Test Access Unit) module and its use. The topics discussed in this chapter are as follows: • “Function of the MTAU module” on page 456 •...
Page 492: Function Of The Mtau Module
Chapter 16 Multi Test Access Unit Function of the MTAU module Function of the MTAU module The MTAU is a passive module (switch) used to route the signals from the different measurement plug-ins to one and the same fiber. The advantage is to be able, for example, to make all the characterization measure- ments (insertion loss, reflectometry, chromatic dispersion, spectrum and polarization measurements) with a single Platform 8000 without ever disconnecting the fiber.
Page 493: Configuration
Chapter 16 Multi Test Access Unit Configuration Configuration To use the MTAU function, go into the page and select the icon Then go into the menu (the same page is displayed for this plug- ETUP ESULTS in) to access the screen from which the the input channels can be switched. The screen displays a diagram of the input and outputs to the switching device.
Page 494: Auto Mode
Chapter 16 Multi Test Access Unit Auto mode Auto mode The auto mode offers the best way to test a full cable. The purpose is to set a sequence of operations, which will be performed for each fiber, one after the other with no need to modify the configuration or to go to each measurement tab.
Page 495: Fiber Characterization
Fiber Characterization Chapter 17 Used with the MTAU module, the Fiber characterization function allows to automate a test sequence with the different modules and associated test functions available in the T-BERD/MTS. If a touchscreen is not available, to use the Fiber Characterization Script function, external keyboard and mouse or screen deported on PC are mandatory.
Page 496: Inspect And Clean Connectors
Chapter 17 Fiber Characterization Inspect and clean connectors Inspect and clean connectors Before connecting a fiber into a test module, inspect and clean the module bulkhead and the fiber jumper connectors. Connect the P5000i video inspection scope to both units USB port (any) Press H hard key on the T-BERD/MTS 8000 V2.
Page 497 Chapter 17 Fiber Characterization Connect the test modules to the MTAU • in Unidirectional configuration Figure 228 Interconnection - Unidirectional configuration DISPAP (CD/PMD/AP) MTAU 2: Multi-Test Access unit allowing a single connection/disconnection of Fiber under test OTDR module 1310/1550/1625 nm + FiberComplete (IL/ORL) •...
Page 498: Referencing The Test Functions
Chapter 17 Fiber Characterization Referencing the test functions The test modules (OTDR, DISPAP) have to be located in the slots clos- est to the mainframe. Keep the MTAU module at the back slots. Referencing the test functions The following test functions require REFERENCING before performing tests: •...
Page 499: Il/Orl Referencing
Chapter 17 Fiber Characterization Referencing the test functions IL/ORL referencing IL/ORL referencing with the integrated FiberComplete® solution Connect a fiber jumper to the MTAU COM port of T-BERD/MTS 8000 V2 and one to the test port of the module of the T-BERD/MTS 6000A. Refer to Figure 229 on page 461 for proper module interconnections.
Page 500 Chapter 17 Fiber Characterization Referencing the test functions Figure 230 IL Side by side measurement Press OK to measure emitted power level. When prompt, disconnect the test jumpers from the mainframe power meters and connect the non-reflective terminator to the end of each test jumper, as shown below (terminators located in the black plastic box) Figure 231 Zero ORL Referencing...
Page 501: Perform Orl And Loopback Il Referencing
Chapter 17 Fiber Characterization Referencing the test functions Press OK to perform zero ORL referencing. Connect both jumpers together using the appropriate mating adapter. See below the interconnection schematic. Figure 232 IL Side by Side Referencing schematic Press Ok to perform IL Referencing. Perform ORL and Loopback IL Referencing Touch the FCOMP tab.
Page 502: Activate The Cd Or Ap Function On T-Berd/Mts 8000 V2
Chapter 17 Fiber Characterization Referencing the test functions Connect a fiber jumper to the MTAU COM port of T-BERD/MTS 8000 V2 and to the test module of the T-BERD/MTS 6000A V2. Connect both jumpers together using the appropriate mating adapter. See below the interconnection schematic.
Page 503: Perform The Cd/Ap Referencing On T-Berd/Mts 8000 V2
Chapter 17 Fiber Characterization Referencing the test functions On the Home page, select BBS icon Press R hard key. ESULTS Click on BBS tab. Click on menu key to select CD or AP. Press S hard key to activate the BBS. TART Perform the CD/AP referencing on T-BERD/MTS 8000 V2...
Page 504: Activate The Ap/Cd Function On The T-Berd/Mts 8000 V2
Chapter 17 Fiber Characterization Referencing the test functions Figure 234 Interconnection for Referencing in Unidirectionnal mode Press the hard key O on both the T-BERD/MTS 8000 V2 and the OBS5x0 unit Activate the AP/CD function on the T-BERD/MTS 8000 V2 Press the hard key H and light the icon with your...
Page 505: Perform The Ap / Cd Referencing On The T-Berd/Mts 8000 V2
Chapter 17 Fiber Characterization Fiber Characterization Test Sequence in Manual mode Perform the AP / CD referencing on the T-BERD/MTS 8000 V2 Touch the AP / CD tab and press the hard key. Press the soft key Acq. Ref. to enter the reference menu. Select Make Reference to Yes.
Page 506: Getting Started With The "Link Characterization" Script
Chapter 17 Fiber Characterization Fiber Characterization Test Sequence in Manual mode The Insertion Loss (IL), the Optical return Loss (ORL), the Chromatic Dispersion (CD) and the Attenuation Profile (AP) measurements have to be referenced before starting testing. Please refer to chapter “AP and CD referencing with FC1 Test Kit”...
Page 507: Define The Link Description
Chapter 17 Fiber Characterization Fiber Characterization Test Sequence in Manual mode • Cable commissioning: is used for testing an entire cable. The script will save all the test results and the summary report into one directory, and for all the fibers. The directory will be created using the Cable ID as the name.
Page 508: Start The Test Sequence
Chapter 17 Fiber Characterization Fiber Characterization Test Sequence in Manual mode Repeat steps 1 to 3 until you have selected all the parameters. Maximum 7. Press the soft key Validate in order to acknowledge the selection. Figure 235 Summary table contents Press Exit to return to Fiber Characterization screen.
Page 509: Obs-500/550 Lightsource Operation For Fiber Characterization Testing
Chapter 17 Fiber Characterization Fiber Characterization Test Sequence in Manual mode Press Yes to continue CD test. After completion of CD test, Result screen appears. Figure 236 Results screen with FC1 Test Kit If more fibers are to be tested press Yes and fiber number automatically increments. If no more fiber is to be tested press No and a summary of the results is visible.
Page 510: Fiber Characterization With Fc2 Test Kit (Bi-Dir.)
Chapter 17 Fiber Characterization Fiber Characterization Test Sequence in Manual mode When directed by the testing technician, using the Application button ensure AP light is green, then CD. NOTE OBS-550 has HD mode which is High dynamic mode. By selecting HD mode, the EDFA amplifier built into the light source is engaged and the out- put power increases substantially.
Page 511: Setting The Test Parameters
Chapter 17 Fiber Characterization Fiber Characterization Test Sequence in Manual mode If a new folder is needed, go to step 3, else go to next section. Highlight desired main folder. Press the soft key Create Directory to create a sub-directory. A virtual keyboard will appear to allow you to input a new folder name.
Page 512 Chapter 17 Fiber Characterization Fiber Characterization Test Sequence in Manual mode Setting the OTDR test parameters on both units Go to the SM-OTDR tab. Press the soft key Alarms. Select Alarm level to Fail Set the thresholds to Default or define your own criteria (see Figure 243 on page 484).
Page 513: Defining The Filenaming And Fiber Description
Chapter 17 Fiber Characterization Fiber Characterization Test Sequence in Manual mode Figure 239 Alarms and Wavelength range configuration Defining the filenaming and fiber description Go to the FCOMP tab Press the F hard key If needed, press soft key Explorer/Setup to toggle to Setup Configure your File storage mechanism For ‘Filenaming’, define your desired string, example: [Orig- in_Id]_[End_Id]_[Fiber_Id]_[Fiber_Num]...
Page 514 Chapter 17 Fiber Characterization Fiber Characterization Test Sequence in Manual mode Wait for the completion of FCOMPand OTDR testRed Testing light turns off. Go to MTAU tab and select Out B On the T-BERD/MTS 6000A Press the S hard key to go to the Home page and activate the BBS function YSTEM Press the R hard key...
Page 515: Testing Next Fiber
Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script All measurements are completed FOR THIS FIBER Testing next fiber Before testing next fiber, make sure the fiber description (fiber num- ber, location…) has been correctly setup in the FiberComplete FILE setup page and copied to all.
Page 516 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script Launching the Link Characterization script Press the S hard key on the 8000 V2 CRIPT Select the function Scripts > Link Characterization using touchscreen or stylus Press the soft key Launch to enter the script configuration menu..
Page 517 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script Figure 241 Link Description parameters Enter Cable/Link Id Enter Fiber Enter Fiber information number Enter both end Select bit locations rate in drop Add job/work# info. & down list comments if required NOTE...
Page 518 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script When asked to “CHECK PMD SOURCE”, contact far end user to connect OBS-550/500 light source. Turn light source on, ensure BB mode of opera- tion, and set for PMD mode and press Activate. Red light will turn on indi- cating source is active.
Page 519 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script NOTE The far end 6000A Datalink icon will turn yellow when connection is estab- lished. Both units will beep to confirm. NOTE You can use the optical talkset simultaneously to talk through the spare fiber. Figure 242 Talkset and Datalink connection Optical...
Page 520 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script Press the S hard key on both units ETUP Go to the FCOMP tab on both units Configure the FCOMP Thresholds parameters as Default or enter your own criteria Go to the SM-OTDR tab on both units Press the soft key Alarms...
Page 521 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script Configuring the test sequence Check the test functions to include in the characterization sequence as follow Configuring the test sequence on the T-BERD/MTS 8000 V2 Figure 244 Test sequence configuration on 8000 V2 Configuring the test sequence on the T-BERD/MTS 6000A Figure 245...
Page 522 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script Configuring the Job Type & Link Description Check Fiber Span testing is defined in Job Type parameter. Enter Link Description on both units Figure 246 Link Description parameters Enter Cable/Link Id Enter Fiber Enter Fiber information...
Page 523 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script Starting a test sequence Press the soft key Start on both units A message Waiting for Datalink initialisation... is displayed while both units are communicating to each others in order to synchronize the test sequence.
Page 524 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script Measurement will start automatically,, when the far end BBS is on. Press No when message prompt appears to stop testing. Notify the far end user to do the same. Testing next fiber Before testing next fiber, make sure the fiber description (fiber num- ber, location…) has been correctly setup in the Link Characterization...
Page 525 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script Go to the SM-OTDR tab on both units Press the soft key Alarms Select Alarm level to “Fail” Set the thresholds to Default or define your own criteria Figure 247 OTDR Alarms - Default and User Selecting data storage directory...
Page 526 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script Configuring the test sequence Check the test functions to include in the characterization sequence as follow Configuring the test sequence on the T-BERD/MTS 8000 V2 Figure 248 Test sequence configuration on 8000 V2 Configuring the test sequence on the T-BERD/MTS 6000A Figure 249...
Page 527 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script Configuring the Job Type & Link Description Check Fiber Span testing is defined in Job Type parameter. Enter Link Description on both units Figure 250 Link Description parameters Enter Cable/Link Id Enter Fiber Enter Fiber information...
Page 528 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script Starting a test sequence Press the soft key Start on both units When message Do you want to start measurement from your site? appears, click Yes on the 8000 and No on the 6000A Inspect and clean connectors of the fiber to test using the P5000i inspection scope on both ends when the inspection page appears Connect the fiber under test to each patchcord (one connected to the TB8000...
Page 529 Chapter 17 Fiber Characterization Fiber Characterization Automated Test Sequence using the Link Characterization Script On the T-BERD/MTS 6000A V2 When notified by the 8000 V2 user, touch the softkey to position the test mode as AP Notify the far end user On the T-BERD/MTS 8000 V2 Press Yes to the message to start AP measurement...
Page 530 Chapter 17 Fiber Characterization Results display and saving Results display and saving Once all the measurements are performed, the result table is displayed Figure 251 Fiber Characterization Results Table The results summary is filled in with the last 5 fiber measurements and the user can scroll up and down to view the other fibers tested.
Page 531 Chapter 17 Fiber Characterization Results display and saving Figure 253 Example of txt file opened via Excel Job Information OTDR Results CD Results PMD Results AP Results User Manual 78000010220 Rev. 024...
Page 532 Chapter 17 Fiber Characterization Results display and saving User Manual 78000010220 Rev. 024...
Page 533 OFI Module Chapter 18 This chapter describes the functions of the OFI module (Optical Fiber Installation) and its use. The topics discussed in this chapter are as follows: • “OFI module” on page 498 • “Selection of the OFI module” on page 498 •...
Page 534 Chapter 18 OFI Module OFI module OFI module The OFI module is used to make insertion loss measurements, ORL measurements and distance measurements. The following functions are available with the OFI Module: • Loss Test Set • FOX (Fiber Optic eXpert) •...
Page 535 Chapter 18 OFI Module LTS function Configuring the LTS To activate the function: Press the S button. YSTEM Validate the Powermeter icon and the Source icon The effect of this action will be to bring the power meter and source into use. Figure 255 Configuration of power measurement See OTDR Setup:...
Page 536 Chapter 18 OFI Module LTS function NOTE A continuous push on the direction keys, increments the value by 10 dBm. Configuring the Measurement parameters In the Setup page, press Measur’t soft key (if one parameter is selected in the current screen, press Top Menu soft key to display the right menu keys and click Wavelength Selecting wavelength:...
Page 537 Chapter 18 OFI Module LTS function NOTE To copy a Reference Level or a Attenuator Compensator on all wavelengths, select the reference wavelength and click on Update for All Wavel.. Configuring and displaying the parameters of the source Figure 256 Source configuration Source When the laser is on, the icon...
Page 538 Auto (the sources emit on determined frequencies to enable the power meter to detect the wavelength used automatically) Twintest (cyclical emission on all available wavelengths for a few seconds on each wavelength), compatible with the Viavi OLP 5/6/15/16/18. CW (continuous emission) The mode used is displayed, above the icon PowerIn CW mode: You can choose the emitted power: - either the nominal value: -3.5 dB...
Page 539 Chapter 18 OFI Module LTS function A measurement result is displayed in the table when the Keep Result softkey is pressed. Clear Table softkey orders deletion of all the results displayed in the table. If the Alarm function has been activated, any result that exceeds the selected thresholds appears in red in the table.
Page 540 Chapter 18 OFI Module LTS function Power Ref – Set as reference Selects the current result as reference value to measure the attenuation of a link. This reference is displayed under the measurement result until a new reference value is chosen. Keep Result Saves the result on the corresponding line of the table.
Page 541 Chapter 18 OFI Module LTS function Optical link loss Setting the zero value of the power meter It is important to set the zero of the power meter before making any mea- surements where accuracy is required, as the noise from the photodiode fluctuates over time and with variations in temperature.
Page 542 Chapter 18 OFI Module FOX Function Function The FOX function is used to make automatic, bidirectional optical power measurements and / or ORL measurements at one or several wavelengths. This function is also used to make a distance measurement of the link under test. Two MTS 8000 are required, each one equipped with an OFI module at each end of the fiber.
Page 543 Chapter 18 OFI Module FOX Function Results screen parameters Index Of Refraction Preset Index 1550 SM User from 1.30000 to 1.70000 Corning SMF-28 1.46810 Lucent Truewave 1.47320 SpecTran SM 1.46810 Litespec 1.46700 ATT SM 1.46700 Fitel Furukawa 1.47000 Corning SMF-DS 1.47110 Corning SMF-LS 1.47000...
Page 544 Chapter 18 OFI Module FOX Function • the fiber number is automatically incremented. To display the fiber to be tested, push the S button in the results page of the TART FOX function (see “Choosing the fiber to be tested” on page 513).
Page 545 Chapter 18 OFI Module FOX Function On the R page, push the References key. ESULTS Push the Loss Side/Side key. Link the FOX connectors of the two MTS 8000s by using two jumpers. Push on key. Figure 259 Taking a side by side reference (8000 V2 series example) Reference date.
Page 546 Chapter 18 OFI Module FOX Function Taking the reference in a loop-back mode NOTE This reference can be made wether the MTS 8000s are on the same site or not. Connect the optical output of the source (FOX port) to the optical input of the power meter by means of a jumper.
Page 547 Chapter 18 OFI Module FOX Function Establishing a reference for an ORL measurement Two steps must be carried out to take a reference for a ORL measurement: Power emitted reference Zero ORL adjustment Follow the order given above to take the reference. They are not two differ- ent processes but two steps necessary to establish a reference for an ORL measurement NOTE...
Page 548 Chapter 18 OFI Module FOX Function Figure 261 Adjustment of the ORL Zero Once the reference has been taken, the reference screen is updated for the wavelengths available on the local instrument. It indicates the type of reference used. Once the two references are complete, the date as well as the type and serial number of the local instrument are displayed on the first line of the table.
Page 549 Chapter 18 OFI Module FOX Function • Results table with the last measurement made. • The tested fiber parameters Choosing the fiber to be tested Once the results page is displayed, push the S button. TART The details of the next fiber to be tested are displayed. Figure 262 Details of the following fiber to be tested To test a different fiber to the one displayed, select the new fiber according to its number...
Page 550 Chapter 18 OFI Module FOX Function Once the measurement has finished, the MTS 8000 beeps to signal the end of the sequence. The beep differs, depending on wether the measurement has completed correctly or according to the measurement/alarm status. Identifying the distant module Before making a measurement, you can check presence of the distant module.
Page 551 Chapter 18 OFI Module FOX Function During the measurement, the following icon is displayed and the keys on the right of the screen are inactive. Once the measurement has finished: • the icon turns grey • keys are active. • the MTS 8000 beeps to signal the end of the measurement.
Page 552 Chapter 18 OFI Module FOX Function Two types of messages are available: – predefined messages (10) – User-definable messages(4) The message sent by one MTS 8000 will be displayed on the screen of the other MTS 8000. To send a message to the distant MTS 8000: In the Results page, push the Send Message key.
Page 553 Chapter 18 OFI Module Manual ORL NOTE If the link is not established between the two MTS 8000, the following error message is displayed: «No acknowledge received for the SMS sent». Manual ORL The OFI module can be equipped with the ORL function (option), which allows to make an ORL manual measurement .
Page 554 Chapter 18 OFI Module Manual ORL NOTE As ORL manual is an option, establishing a reference for this measurement is not automatically available with the OFI module. Measurement acquisition The page displays: • The results screen with the wavelength and the ORL references established. •...
Page 555 Chapter 18 OFI Module Generating a pdf report Figure 266 Results for an ORL manual measurement Once all the results are displayed, click on the F button to save the file in a directory. Generating a pdf report Once the FOX results page is displayed, a report can be generated directly from the results screen.
Page 556 Chapter 18 OFI Module Generating a pdf report NOTE The pdf report is saved in the last storage media and directory selected. Opening a report To open the report Press F hardkey In the Explorer page, in the directory selected, select the pdf file of the report. The pdf file name by default is: trace file name_year_month_day__hour_min_sec.pdf.
Page 557 Chapter 18 OFI Module Generating a pdf report Figure 267 Example of FOX Report Adding a logo to a pdf report To display a logo (or any other image) on the upper left part of the pdf report: Go to the System Settings screen (H >...
Page 558 Chapter 18 OFI Module File Management File Management Storing results Although each measurement is automatically stored (for FOX results only), it is possible to save the results under a different file name, directory etc. Once the results are displayed: Push the F button Select Setup...
Page 559 Macros Chapter 19 The macro function allows to store series of user actions, in order to play them back automatically. The macro function is operational only while the Platform is used under the context of «fiber optic applications», meaning used with one of the following application selected: OTDR, OSA, CD, PMD, AP, LTS...
Page 560 Chapter 19 Macros Calling the Macro function Calling the Macro function This function is accessible via the button S , in the front of the 8000 V2 or clicking CRIPT on the upper banner and pressing Script button on the 6000/6000A V2. 10 various macros may be created and used.
Page 561 Chapter 19 Macros Macro recording Standard macro This macro type shall be used to automate functions or operation mode. To create a new standard macro: Select a free position. A sub-menu automatically appears. Change the Macro type if necessary to set it on Standard. Click on the soft key Learn.
Page 562 Chapter 19 Macros Macro recording Select the file you want to work with to perform all actions. Load and view the corresponding trace. You can now see the icon at the top of the screen indicating the macro can be recording. Perform all actions you wish to record in your macro.
Page 563 Chapter 19 Macros Macro recording Inserting a pause Click on the soft key Insert Pause. This action will automatically make the macro wait for a user action. Renaming a macro Whether you just created a new macro or you wish to modify the name of an existing macro, you may edit the name and change it as much as you want.
Page 564 Chapter 19 Macros Default macro Removing a macro Select an existing macro and click on the soft key Remove. A message will be displayed, asking you if you really wish to delete the selected macro. Click if you wish to continue. Default macro Using the default macro It is possible to set one macro as default.
Page 565 Chapter 19 Macros Macro playback Macro playback To play the default macro, you may directly double click on S CRIPT To play another macro, go to the macro screen (press S once), and select CRIPT the macro you wish to play. Then press the soft key Play. During all the play back of the macro, you can see the icon at the top of the screen.
Page 566 Chapter 19 Macros Macro playback Playing a macro in Real Time In the Script page, the soft key Play Real Time allows to play the macro selected, taking into account the speed of the actions during the macro recording. Script (specific option) According the configuration of the MTS/T-BERD 6000/8000V2, this one can be equipped with a Script function, available on the same page as the macro page.
Page 567 File management Chapter 20 The topics discussed in this chapter are as follows: • “Description of the explorer” on page 532 • “Saving and loading files” on page 535 • “Exporting files” on page 537 In Home > App’s > File Explorer, the files can be loaded and traces can be displayed or saved even when no module is set into the Base Unit.
Page 568 Chapter 20 File management Description of the explorer Description of the explorer Opening the file explorer To access the Explorer Press the F button The explorer is used to select the storage medium, and to create or rename directories and files: –...
Page 569 Chapter 20 File management Description of the explorer Managing tabs Tabs give access to the File menu of each application (OTDR, OSA, Power Meter, etc.) present in the instrument. It is possible to open a file even if the corresponding module is not present in the instru- ment (e.g.
Page 570 Chapter 20 File management Description of the explorer Figure 272 Example of signature of a FCOMP file Measurement parameters Origin / End Fiber Identification Module used Fiber Number Comment Cable Identification Acquisition Date & Time Buttons on the right of the screen Saving traces These buttons are used to save one or more traces/ •...
Page 571 Chapter 20 File management Saving and loading files NOTE Remote T-BERD/MTS and data transfer During a data transfer (with the option Data/Talkset), the distant MTS / T- BERD hard drive connected by the fiber is displayed as a storage media. File and directory edition features may all be used in the same manner with this storage media as with the other ones.
Page 572 Chapter 20 File management Saving and loading files Figure 273 Saving active trace from the explorer Displayed when two active overlaid traces are open. The trace described in the file signature will be saved in the directory selected (in this example: demo) This will open automatically the edition keypad, in order to give a filename for the active trace.
Page 573 Chapter 20 File management Exporting files • If the MTS / T-BERD was equipped with a different module from the current one when the trace was acquired, certain configuration parameters cannot be updated. A message warns the user of this. •...
Page 574 Chapter 20 File management Exporting files For example, if the Link Mgr. function is selected in the tab OTDR, only the link informa- tion from the OTDR files will be displayed (wether in multimode or singlemode). Select Link Mgr with the menu key Explorer/Link Mgr. to display the corresponding files for the active tab.
Page 575 Chapter 20 File management Exporting files Table 8 Fiber Information displayed Column. OTDR & OEO CD ODM Lambda Length Nb Channel Length Length Power (dBm) Total Loss Power Max. Delay 1 AP @ 1310 nm Loss (dB) Fiber Length Power Min. Coeff.
Page 576 Chapter 20 File management Exporting files NOTE The txt file can be renamed once it is saved. This file is made of two parts: • The Header, with general information: the equipment used and its serial number, the date and time of export, the location of the file, and the number of files exported.
Page 577 Chapter 20 File management Exporting files Generating pdf report(s) Several files of a same type (example: all OTDR files) can be generated in one/several pdf report(s). Select the file(s) to be generated in a pdf report Press Export > Report menu keys. Using the menu key select: –...
Page 578 Chapter 20 File management Exporting files CAUTION To modify the Viavi logo, set by default on the header of the pdf report, save your logo in a jpg file called logo.jpg and place it to the root of the disk: disk > logo.jpg.
Page 579 Chapter 20 File management Exporting files Check in the Setup page that the File Export parameters are correctly configured (see 8000 V2 or 6000(A V2) Platform User Manual). In the Explorer, select the file(s) to be sent by e-mail Press Export menu key. Click on Send by mail menu key If necessary, in the edition menus displayed, modify the e-mail address and/or the subject of the e-mail.
Page 580 Chapter 20 File management Exporting files User Manual 78000010220 Rev. 024...
Page 581 Technical specifications Chapter 21 This chapter shows the technical specifications of the modules, of the T-BERD/MTS, and options and accessories available. The topics discussed in this chapter are as follows: • “Mains adapters” on page 546 • “Environment” on page 546 •...
Page 582 Chapter 21 Technical specifications Mains adapters Mains adapters Standard Mains Adapter High power Mains Adapter Input 100-250 V, 50-60 Hz 100-250 V, 50-60 Hz 24 V continuous, 21V continuous, Output 6,25 A max 10.5 A max Compliance EN 60950 EN 60950 Environment Indoor/outdoor •...
Page 583 Pollution degree • Pollution degree: 2 Viavi recommends that customers dispose of their instruments and peripherals in an environnmentally sound manner. Potential methods include reuse of parts or whole products and recycling of products components, and/or materials. Waste Electrical and electronic Equipment (WEEE) Directive In the European Union, this label indicates that this product should not be disposed of with household waste.
Page 584 The Attribute/Descriptor housing (in ABS, type V0) does not propagate fire. IP Protection Index Index of the IP protection for the Platform 8000: IP32 NOTE For a higher classification, contact Viavi. OTDR Modules Typical values at 25°C, otherwise specified. User Manual...
Page 585 Chapter 21 Technical specifications OTDR Modules Warning labels for the laser classes Dangerous voltage (> 70VDC) is present inside of the product. Do not attempt to remove cover when product is in use. Due to the reduced dimensions of the optical modules, it is not possible to attach the required warning labels to them.
Page 586 Chapter 21 Technical specifications OTDR Modules • Resolution of cursor: 1 cm max. • Sampling resolution (distance between measurement points): from 2 cm, with up to 256 000 acquisition points. • Absolute Accuracy: – For OTDR Modules A: –5 MM part: ±0.33m ± sampling resolution + 1.10 x distance –5 SM part: ±0.5m ±...
Page 587 Chapter 21 Technical specifications OTDR Modules Automatic measurement • Automatic measurement of all the elements of the signal: Event Distance / Event Loss / Event Reflectance / Section Loss and Attenuation / Optical Return Loss • Slope measurement by least square averages or 2-point method. •...
Page 588 Chapter 21 Technical specifications OTDR Modules B, C & D Modules Singlemode Modules 8100B OTDR 8100C OTDR Series 8100D OTDR Series Series 1310 ± 20 nm 1310 ± 20 nm 1310 ± 20 nm 1490 ± 20 nm 1550 ± 20 nm 1550 ±...
Page 589 Chapter 21 Technical specifications OTDR Modules 8100B OTDR 8100C OTDR Series 8100D OTDR Series Series Output Power Level -3.5 dBm 0 dBm Stability < ± 0.1 dB @ 25°C over 1 hour Operating modes , 270Hz, 330Hz, 1kHz, 2kHz, Twintest, Auto 1.
Page 590 Chapter 21 Technical specifications OTDR Modules 8100B OTDR Series 8100C OTDR Series Power Meter Calibrated wavelengths 1310, 1490, 1550, 1625 nm Power range -3 to -55 dBm Uncertainty ± 0.5 dB @ -30 dBm Optical Source Wavelengths 1310, 1550, 1625 nm 1310, 1490, 1550, 1625 nm Output Power Level -3.5 dBm...
Page 591 Chapter 21 Technical specifications OTDR Modules E8146A E8156 A Event Dead Zone 0.20/0.25 m 0. 60 m Attenuation Dead Zone 1.5 / 2.1 m 2 m (@ 1310 nm) Continuous Wave Light Source Output Power Level 0 dBm Stability < ± 0.2 dB @ 25° over 1 hour <...
Page 592 Chapter 21 Technical specifications OTDR Modules CWDM Modules 8100 8100 8100 8100 8100 CWDM modules CWDM1E CWDM2E CWDM3E CWDM4E CWDM5E Central Wave- 1551 ± 5 nm 1471 ± 5 nm 1351 ± 5 nm 1271 ± 5 nm length 1571 ± 5 nm 1491 ±...
Page 593 Chapter 21 Technical specifications OTDR Modules 1 ns 3 ns 10 ns 30 ns 50 ns 200 m 500 m 1 km 2 km 5 km 10 km Singlemode Module 3 ns 10 ns 30 ns 100 ns 300 ns 1 µs 3 µs 10 µs...
Page 594 Chapter 21 Technical specifications OTDR Modules 1 μs 3 μs 10 μs 20 μs 5 ns 10 ns 30 ns 100 ns 300 ns 2 km 5 km 10 km 20 km 40 km 80 km 160 km 320 km Ranges for OTDR Module C 2 ns 10 ns...
Page 595 Chapter 21 Technical specifications OTDR Modules 5 km 10 km 20 km 40 km 80 km 160 km 320 km Ranges for CWDM modules 1 μs 3 μs 10 μs 20 μs 3 ns 30 ns 100 ns 300 ns 5 km 10 km 20 km...
Page 596 Chapter 21 Technical specifications HR OSA Module HR OSA Module Typical values, at 25°C, unless specified otherwise. Module EOSA610B Wavelength Acquisition Range 190.7-196.65 THz (1524.498 - 1572.063 nm) Absolute uncertainty of frequency ±370 MHz (±3pm) (wavelength) Frequency (wavelength) resolu- 300 MHz (2.4pm) tion Minimum signal separation 2 GHz (16 pm)
Page 597 Chapter 21 Technical specifications ODM Modules ODM Modules Typical values, at 25°C, unless otherwise specified. Chromatic Dispersion (E81CD/E81DISPAP) 80km G652 10km G655 Wavelength Acquisition Range 1260 - 1640 nm Wavelength Uncertainty +/- 0.1 nm Minimum length 1 km Dynamic Range 45 dB 55 dB Zero dispersion wavelength uncertainty...
Page 598 Chapter 21 Technical specifications ODM MR Modules Attenuation Profile (E81DISPAP) Dynamic Range 55 dB 60 dB Measurement Uncertainty +/-0.006dB/km @1310nm (80 km fiber G652) +/-0.003dB/km @1550nm +/-0.004dB/km @1625nm Measurement Time 6 seconds 1. With Broadband Source module E81BBS2A unless specified 2.
Page 599 Chapter 21 Technical specifications High Resolution Dispersion test solution Polarization Mode Dispersion (E81MRDISPAP) Dynamic Range 45 dB PMD Measurement range 0.08 to 130 ps 4, 5 PMD Type B uncertainty +/- 0.02 ps +/- 2% PMD 4, 5 PMD Repeatability 0.025 ps Measurement Time 8 seconds, independent of PMD value...
Page 600 Chapter 21 Technical specifications High Resolution Dispersion test solution Polarization Mode Dispersion Measurement time From 30 s. 1. With Broadband Source module E81BBS1A in Corresponding mode 2. With Kit 1 (PMD only). Subtract 6 dB for Kit 2 (PMD / CD / AP) 3.
Page 601 Chapter 21 Technical specifications BBS Modules 5. Excluding reference fiber uncertainties Dimensions and weight • Weight: 600 g (1.32Ibs) • Dimensions (w x h x d): 213 x 124 x 32 mm (8.36 x 4.88 x 1.26 in) BBS Modules Specifications, at 25°C, unless otherwise mentioned.
Page 602 Chapter 21 Technical specifications MTAU modules Ref. standard EN 60825-1, Edition 1.2, 2001-08 FDA21CFR§1040.10 Class 2 Measurements on optical fibers are difficult to execute and the precision of the results obtained depends largely on the precautions taken by the user. MTAU modules Typical values, at 25°C, unless otherwise specified.
Page 603 Options and accessories Chapter 22 This chapter describes all the accessories and options available with the MTS / T-BERD series. NOTE Product marking is based on the commercial reference excluding the first let- ter. Example: Commercial reference E4146QUAD is identified 4146QUAD on the product.
Page 604 Chapter 22 Options and accessories References of measurement modules References of measurement modules OTDR Modules OTDR Module A Singlemode/Multimode References Multimode / Singlemode 850/1300 nm & 1310/1550 nm OTDR module A E8146A Multimode / Singlemode PENTA 850/1300 nm & 1310/1550/1625 nm E8156A OTDR module A OTDR Module A Multimode...
Page 605 Chapter 22 Options and accessories References of measurement modules OTDR Module C Reference OTDR Module C 1310/1550 nm wavelengths with continuous wave light E8126C source and built-in power meter OTDR Module C 1625 nm wavelength filtered and Raman compensated, E81162C optical connector must be specified OTDR Module C 1650 nm wavelength filtered and Raman compensated, E81165C...
Page 606 Chapter 22 Options and accessories References of measurement modules OTDR Module C Reference OTDR Module C 1310/1550/1625 nm wavelengths combining FiberCom- plete function for bi-directional Insertion Loss and ORL testing and SCL Broadband Source for CD/PMD/AP measurements. also includes contin- E8136C-FCHAR uous wave light source and built-in power meter.
Page 607 Chapter 22 Options and accessories References of measurement modules CWDM modules References 2-Wavelengths CWDM OTDR 1431/1451 nm module with continu- E8140OTDRCWDM3E ous wave light source 4-Wavelengths CWDM OTDR 1351/1371/1391/1411 nm module E8140OTDRCWDM4E with continuous wave light source 4-Wavelengths CWDM OTDR 1271/1291/1311/1331 nm module E8140OTDRCWDM5E with continuous wave light source PMD / I-PMD / HR OSA Modules...
Page 608 Chapter 22 Options and accessories User manual references 1. To be used with a broadband source. ODM MR Modules ODM modules Reference ODM MR Medium Range module E81MRDISPAP 1. To be used with a Broadband Source: EOBS500 / E81BBS1A/E81BBS2A BBS Modules BBS modules References BroadBand Source module for PMD, Long Range CD and ATT Pro-...
Page 609 Chapter 22 Options and accessories References of optical connectors and adapters User manuals for MTS/T-BERD modules References User manual for modules, 8100 series (German) E8100M03 References of optical connectors and adapters Front Panel interchangeable Optical connectors for References Multi-mode SRL OTDR Universal PC Connector with FC adapter EUNIPCFCMM Universal PC Connector with SC adapter...
Page 610 Chapter 22 Options and accessories References of result processing software Additional Adapters for Universal Connectors References Universal FC Adapter EUFCAD Universal SC Adapter EUSCAD Universal ST Adapter EUSTAD Universal DIN Adapter EUDINAD Universal LC adapter EULCAD 1. Interchangeable in the field References of result processing software References Optical Fiber Trace software...
Page 611 RoHS Information Appendix A This appendix describes the RoHS (Restriction of Hazardous Substances) information, which are mandatory requirements from China. The RoHS directive consists in the restriction on the use of certain hazardous substances in electrical or electronic equipment sold or used in the European Union, after July 1, 2006.
Page 612 Appendix A RoHS Information Concerned products: 8100 V2 modules series Concerned products: 8100 V2 modules series Nb 8000 V2 series User Manual 78000010220 Rev. 024...
Page 613 Appendix A RoHS Information Concerned products: OTDR 8100 V2 Modules Series Concerned products: OTDR 8100 V2 Modules Series 8115UHD, 8123MM, 8126UHD, 8129UHD, 8136UHD User Manual 78000010220 Rev. 024...
Page 614 Appendix A RoHS Information Concerned products: OTDR VLR 8100 V2 Modules Series Concerned products: OTDR VLR 8100 V2 Modules Series 8118 VLR(38/49), 8138 VLR49, 8148 VLR38 User Manual 78000010220 Rev. 024...
Page 615 Appendix A RoHS Information Concerned products: PMD 8100 V2 Modules Series Concerned products: PMD 8100 V2 Modules Series 81PMD User Manual 78000010220 Rev. 024...
Page 616 Appendix A RoHS Information Concerned products: PMD 8100 V2 Modules Series User Manual 78000010220 Rev. 024...
Page 617 Index Accessories Cable SLM Setup Adapter reference switch acquisition parameters types Configuration results sreen parameters Attenuation CD ODM Attenuation profile Acquisition acquisition parameters Configuration measurement Reference Measurement measurement procedure Results results display results table CD-ROM burning Channel filtering (OSA) Cleaning optical connectors Backscatter coefficient Coefficient of reflection...
Page 618 Index loopback cable configuration mode measurements FTTH results laser Distance splitters specif. OTDR measurement Ghost EDFA configuration measurement results Index of refraction Environment specifications Event Index Of Refraction (IOR) macro Event memorization Event OTDR Icons Laser Launch cable Loopback Lower & upper thresholds (OFI) Fiber end FiberComplete Store...
Page 619 Index Measurement connection attenuation (specif.) Unit distance (specif.) of power principle Optical connectors Memory precautions see File Options Modules CD (specif.) manual measurement (OFI) MTAU (specif.) Saturated trace OTDR range OTDR MTAU Attenuation unit auto mode Configuration configuration Manual measurement manual mode 2 points 5 points...
Page 620 Index Display Resolution display Remove removing Overlaying traces Scatter coefficient Script Shift Attenuation Profile Shift function Short acquisition acquisition parameters Display of results Side by side graphic display Signal threshold WDM) information messages Slope Measurement procedure method used Smart Link Cable principle of measurement Cable project reference measurement...
Page 621 Index results display SNR parameters table results WDM/OSA acquisition parameters Configuration difference between 2 traces (OSA) Zero value display param. and analysis Zoom alarms Attenuation Profile grid WDM/OSA measurement parameters User Manual 78000010220 Rev. 024...
Page 622 Index User Manual 78000010220 Rev. 024...
Page 624 8100M02/UM/08-21/EN Rev. 024 English VIAVI Solutions North America: 1.844.GO VIAVI / 1.844.468.4284 Latin America +52 55 5543 6644 EMEA +49 7121 862273 APAC +1 512 201 6534 All Other Regions: viavisolutions.com/contacts email TAC@viavisolutions.com VIAVI France 34 rue Necker 42000 Saint-Etienne FRANCE...
