BN 2301/02 Fig. 1 Two versions of the COSA-4055 modules The COSA-4055 is Viavi’s new generation of CWDM analyzer modules. It scans the full wavelength range between 1260 and 1625 nm for commissioning, upgrade, and trouble shooting of CWDM networks. The COSA-4055 offers the functionality and speed of an optical spectrum analyzer in a handheld form at a fraction of the price of an OSA.
Chapter 1 Optical Spectrum Measurement Safety information The COSA-4055 comes in two versions. The basic version (BN 2301/01) provides CWDM analyzer functionality only. The advanced version (BN 2301/02) additionally offers 2 integrated SFP slots for mounting up to 2 SFP transceiver modules (to be ordered separately). The transceiver modules can be used as a CWDM stimulus to check CWDM networks together with the CWDM analyzer.
Never look directly into the output of a laser source or into an optical fiber connected to it. Always cover unused ports. Heed the normal precautions for working with laser radiation and consider local regulations. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
However, the user is free to use any other SFP transceiver compatible with the SFP Multi Source Agreement (MSA). CAUTION In this case you must observe the laser classification of the inserted SFP transceiver and its safety instructions! MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Please refer to the user manual of the MTS-5800 Base Unit for further information. Battery Please refer to the user manual of the MTS-5800 Base Unit for further information. operation MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Following configuration will automatically be set. Setting Parameter Acquisition settings Sweep Single Measurements settings Channel detection Permanent Signal threshold Auto Splitter compensation Results screen settings Grid default = last value used Alarms Table notes Unit MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
. Alternatively, change the parameters via the touchscreen. The various parameters proposed are defined below. Fig. 3 Configuration for optical spectrum measurements. (The softkeys available depend on the grid settings.) MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
In this mode the channels are always detected without making a reference measurement. 1. Attention: All modification of these parameters has immediate repercussions on the trace and entails the loss of the measurement statistics. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 15
For example, with a 10 dB splitter, the results will be augmented by 10 dB. The trace will be offset upwards by 10 dB. A channel measured at -30 dBm will be displayed -20 dBm. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
The type Conventional and the option None do not give access to the parameters of the Grid sub-menu; the others give access to certain options, as shown in the table of the figure. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 17
If all the results are within the thresholds (no result is in red), the icon becomes To activate the alarm system, go to the Alarms line and select Active. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 18
1. Wavelength drift. Selection of the alarm on the basis of the value of Delta Offset 2. The values are then defined in P Min 3. The values are then defined in P Max 4. Delta of frequency 5. Minimum power 6. Maximum power MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 19
Here the units of the x axis can be selected: Wavelength in nm Frequency in THz Fig. 7 Unit parameters Table Content Here the table content can be selected. Fig. 8 Table Content parameters MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Chapter 1 Optical Spectrum Measurement Configuration Link Define the parameters in the Link Description menu and add a comment. Description Fig. 9 Link Description parameters MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Acquisition To start a measurement press the key. TART The COSA-4055 will scan over the entire wavelength range and the measurement result will be displayed in graphical and tabular format. Trace display By pressing the button the results window is displayed.
A-B: Wavelength and power difference between cursors A and B 6. Alarm result (see “Alarms” on page 15). 7. Trace/Table selection 8. Channel number 9. Trace with markers 10. Table of results (see "Table display" on page 29). MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 24
5 to 8 lines of the table of results. – Table: Display of the table alone. Table Content Gives access to table related functions. Advanced Gives access to further trace related functions. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
1. Select a cursor or both cursors and move them to the desired position. 2. Press the Zoom/Shift softkey and select Zoom. 3. Press the key to reduce or enlarge the x-axis. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
1. Set the cursors at the desired positions. 2. Press the softkeys Advanced, Measure A<->B and Total Power A<->B. The space between the trace and the two cursors is greyed out and the power is displayed. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 27
The first and last maximum are linked by a solid line. The slope in [dB/nm] and the difference power in [dB] are stated below the line. Fig. 13 Example of Delta Power measurement MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 28
"Parameters of display and analysis of the results" on page 14). 1. The “Auto” value is obtained by continuing to reduce the value of the threshold be- low the minimum value of -54.9 dBm MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
2. Trace number (active trace in orange) To remove a trace: 1. Press the Trace softkey and use the arrow keys to select a trace. 2. Press the Remove Current Trace softkey. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 30
2. Press the Advanced softkey, select Overlay and then 2 Curves Diff. The difference curve is displayed as a new trace in the diagramm. Fig. 15 Difference of two curves (1) MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
– Th: Threshold 6. Measurement settings and results: – Detect.: Detection Grid/Permanent – Splitter: Splitter Compensation Yes/No – Nb: Number of channels detected/available – Pcomp: Composite power of all channels MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 32
For the COSA-4055 this parameter indicates the peak channel power level. P/Pcomp The ratio between the power of the channel and the composite power in [%]. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
A or B to be used on the trace. 2. Press the Channel key. 3. Press to move the cursor to the following or preceding channel: MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 34
2. Move the cursor on to the channel that is to serve as the reference. 3. Press the Set Ref Channel softkey. The results are recalculated with respect to this channel of reference. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
15.) Fig. 17 Displaying multiple traces 1. Not all results are in the thresholds. 2. Results within the thresholds are displayed green. 3. Results outside the thresholds are displayed red. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
A Drift measurement can only be done at predefined wavelengths or frequencies, for this reason a reference Grid needs to be defined and the Channel Detection parameter is set to Grid. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 37
Activates the drift display showing the selected parameter over time. Activating the Drift display will show the following screen: Fig. 19 Example of drift measurement, figure shows wavelength drift over time MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 38
NOTE If the channel power drifts to a power level below the channel detection threshold, the measurement will indicate “No Signal” in the bar above the table. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Fast Report generates a report which is stored in file system. Fig. 20 Fast Report (1) To change the Fast Report parameters, select the Results button. Fig. 21 Fast Report parameters MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Chapter 1 Optical Spectrum Measurement Reports File system To view the reports on the file system, select the File button. report Fig. 22 Report from file system MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
4. Click on View Tace(s) Load Trace + Config. The selected file is opened. For further informations on file management, please see the chapter “File Management” in the Base Unit user manual. MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Hazardous materials Viavi avoids or uses with care any hazardous or dangerous material in themanufacturing process or the end product. If the use of a dangerous material cannot be avoided, it is identified in product documentation and clearly labeled on the product itself.
In the European Union, all equipment purchased from Viavi after 2005- 08-13 can be returned for disposal at the end of its useful life. Measuring systems affected by this can be recognized by the symbol on the right of a crossed-out trash can and a black bar.
Page 44
Chapter 1 Optical Spectrum Measurement Recycling information MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 45
Chapter 1 Optical Spectrum Measurement Recycling information MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
Page 46
Chapter 1 Optical Spectrum Measurement Recycling information MTS / T-BERD 5800 • COSA-4055 • User Manual 2016.01...
