40.7.3 I2C own address 1 register (I2C_OAR1)
Address offset: 0x08
Reset value: 0x0000 0000
Access: No wait states, except if a write access occurs while a write access to this register is
ongoing. In this case, wait states are inserted in the second write access until the previous
one is completed. The latency of the second write access can be up to 2 x PCLK1 + 6 x
I2CCLK.
31 30 29
Res. Res. Res. Res.
15 14 13
OA1EN Res. Res. Res.
rw
Bits 31:16 Reserved, must be kept at reset value.
Bit 15 OA1EN: Own Address 1 enable
Bits 14:11 Reserved, must be kept at reset value.
Bit 10 OA1MODE: Own Address 1 10-bit mode
Note: This bit can be written only when OA1EN=0.
Bits 9:0 OA1[9:0]: Interface own slave address
Note: These bits can be written only when OA1EN=0.
28 27 26 25
Res. Res. Res.
12 11 10 9
OA1
Res.
MODE
rw rw
0: Own address 1 disabled. The received slave address OA1 is NACKed.
1: Own address 1 enabled. The received slave address OA1 is ACKed.
0: Own address 1 is a 7-bit address.
1: Own address 1 is a 10-bit address.
7-bit addressing mode: OA1[7:1] contains the 7-bit own slave address. The bits OA1[9],
OA1[8] and OA1[0] are don't care.
10-bit addressing mode: OA1[9:0] contains the 10-bit own slave address.
Inter-integrated circuit (I2C) interface
24 23 22
Res. Res. Res.
8 7 6
rw rw rw
RM0440 Rev 1
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
OA1[9:0]
rw rw rw rw
17 16
Res. Res.
1 0
rw rw
