Serial audio interface (SAI)
Bit 4 Reserved, must be kept at reset value.
Bits 3:2 PRTCFG[1:0]: Protocol configuration
These bits are set and cleared by software. These bits have to be configured when the audio block is
disabled.
00: Free protocol. Free protocol allows to use the powerful config uration of the audio block to
address a specific audio protocol (such as I2S, LSB/MSB justified, TDM, PCM/DSP...) by setting
most of the configuration register bits as well as frame configuration register.
01: SPDIF protocol
10: AC'97 protocol
11: Reserved
Bits 1:0 MODE[1:0]: SAIx audio block mode
These bits are set and cleared by software. They must be configured when SAIx audio block is
disabled.
00: Master transmitter
01: Master receiver
10: Slave transmitter
11: Slave receiver
Note: When the audio block is configured in SPDIF mode, the master transmitter mode is forced
(MODE[1:0] = 00). In Master transmitter mode, the audio block starts generating the FS and the
clocks immediately.
39.5.3 Configuration register 2 (SAI_ACR2)
Address offset: 0x008
Reset value: 0x0000 0000
31 30 29
Res. Res. Res.
15 14 13
COMP[1:0] CPL
rw rw rw
1792/2083
28 27 26 25
Res. Res. Res. Res.
12 11 10 9
MUTECNT[5:0]
rw rw rw rw
24 23 22 21
Res. Res. Res. Res.
8 7 6 5
MUTE
MUTE
VAL
rw rw rw rw
RM0440 Rev 1
20 19 18 17
Res. Res. Res. Res.
4 3 2 1
F
TRIS FTH[2:0]
FLUSH
rw w rw rw
RM0440
16
Res.
0
rw
