61420
[Channel %1: ] Block %2: Check calibration of multi/mono probes.
Parameters:
%1 = Channel number
%2 = Block number, label channel number
Definitions:
The alarm can be triggered by the following measuring cycles: CYCLE974, CYCLE994, CYCLE977, CYCLE978,
CYCLE979, CYCLE997, CYCLE998
Remedy:
The workpiece probe must be calibrated according to its type and use.
61421
[Channel %1: ] Block %2: Software release of measuring cycles or NCK inadequate or
set up incorrectly --> error code %4
Parameters:
%1 = Channel number
%2 = Block number, label channel number
Definitions:
The alarm can be triggered by the following measuring cycles: CYCLE996
Remedy:
Causes of error:
1. Error code = A
61422
[Channel %1: ] Block %2: Parameter _MVAR incorrect --> Error code: %4
Parameters:
%1 = Channel number
%2 = Block number, label channel number
Definitions:
The alarm can be triggered by the following measuring cycles: CYCLE996
Remedy:
Causes of error:
1. Error code = A
2. Error code = B
3. Error code = C
61423
[Channel %1: ] Block %2: Parameter _TNUM not agreed or not created
Parameters:
%1 = Channel number
%2 = Block number, label channel number
Definitions:
The alarm can be triggered by the following measuring cycles: CYCLE996
Remedy:
Causes of error:
1. Parameter CYCLE996 _TNUM incorrect or equals zero
2. No swivel data record created -> MD18088 = 0
61424
[Channel %1: ] Block %2: Parameter _SETVAL for diameter of calibration ball incorrect
Parameters:
%1 = Channel number
%2 = Block number, label channel number
Definitions:
The alarm can be triggered by the following measuring cycles: CYCLE996
Remedy:
Check parameter _SETVAL.
Alarms
Diagnostics Manual, 07/2010, 6FC5398-8BP40-0BA0
->
_OVR[] - parameter field too small. Check GUD definition.
DEF CHAN REAL _OVR[72] (up to MZ06.03.xx.xx =32)
->
_MVAR = 9x identifier CYCLE996 measure kinematics
->
Parameter for normalizing (_MVAR) incorrect
->
Measurement variant "compute only" active, but rotary axis 1 or 2 not measured
(see also parameter _OVR[40])
NCK alarms
449
