NCK alarms
14860 [Channel %1: ] Block %2 Selection of the tool cutting rate not allowed. Cause %3
Parameters: %1 = Channel number
%2 = Block number, label
%3 = Cause of the error
Definitions: Selection of the cutting rate SVC is not permissible in the current state
Causes of the problem: the following function is active.
1: Constant cutting rate G96, G961 or G962 active
2: SPOS/SPOSA/M19 (spindle positioning mode) active
3: M70/axis mode active
4: SUG active
Reaction: Correction block is reorganized.
Local alarm reaction.
Interface signals are set.
Alarm display.
Remedy: Activate the speed control mode for the spindle prior to programming SVC, for example with M3, M4 or M5.
Program Clear alarm with NC START or RESET key and continue the program.
Continuation:
14861 [Channel %1 ] Block %2 SVC programmed, but no tool offset active
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: Cutting velocity SVC programmed in the block, but no tool offset active.
Reaction: Correction block is reorganized.
Local alarm reaction.
Interface signals are set.
Alarm display.
Remedy: Select an appropriate tool prior to the SVC instruction.
Program Clear alarm with NC START or RESET key and continue the program.
Continuation:
14862 [Channel %1 ] Block %2 SVC has been programmed, but the radius of the active tool
correction is zero
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: A cutting velocity SVC has been programmed in the block, but the radius of the active tool offset is zero.
The radius of the active tool offset consists of the offset parameters $TC_DP6, $TC_DP12, $TC_SCPx6 and
$TC_ECPx6.
Reaction: Correction block is reorganized.
Local alarm reaction.
Interface signals are set.
Alarm display.
Remedy: Select an appropriate tool offset with a positive tool radius prior to the SVC instruction.
Program Clear alarm with NC START or RESET key and continue the program.
Continuation:
