Remedy:
- Check parameter CON
- Check contour call
- Check whether the contours exist in the program storage (workpieces, subroutines or part programs)
Program
Clear alarm with the RESET key. Restart part program
Continuation:
61702
%[[Channel %1: ] Block %2: %]Label %4 not existing in machined part contour
Parameters:
%1 = Channel number
%2 = Block number, label
Definitions:
Alarm triggered by following cycle: CYCLE952
Reaction:
Interpreter stop
NC Start disable in this channel.
Interface signals are set.
Alarm display.
Remedy:
- Check whether the labels exist in the machined part contour
Program
Clear alarm with the RESET key. Restart part program
Continuation:
61703
%[[Channel %1: ] Block %2: %]Label %4 not existing in the blank contour
Parameters:
%1 = Channel number
%2 = Block number, label
Definitions:
Alarm triggered by following cycle: CYCLE952
Reaction:
Interpreter stop
NC Start disable in this channel.
Interface signals are set.
Alarm display.
Remedy:
- Check whether the labels exist in the blank contour
Program
Clear alarm with the RESET key. Restart part program
Continuation:
61704
%[[Channel %1: ] Block %2: %]Machined part contour missing
Parameters:
%1 = Channel number
%2 = Block number, label
Definitions:
Alarm triggered by following cycle: CYCLE952
Reaction:
Interpreter stop
NC Start disable in this channel.
Interface signals are set.
Alarm display.
Remedy:
- Check contour call
Program
Clear alarm with the RESET key. Restart part program
Continuation:
Alarms
Diagnostics Manual, 07/2010, 6FC5398-8BP40-0BA0
NCK alarms
467
