NCK alarms
14159 [Channel %1: ] Block %2 more than two angles programmed with ROTS or AROTS
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: Frame rotations are described using space angles with the language commands ROTS or AROTS. A maximum of two
angles can be programmed.
Reaction: Correction block is reorganized.
Interpreter stop
Interface signals are set.
Alarm display.
Remedy: Modify program.
Program Clear alarm with NC START or RESET key and continue the program.
Continuation:
14160 [Channel %1: ] Block %2 tool length selection without geometry axis specification
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: If variant C (tool length acts on the programmed axis) is activated by machine data MD20380
$MC_TOOL_CORR_MODE_G43G44 for tool length compensation with H word and G43/G44 in ISO_2 mode, at least
one geometry axis must be specified.
Reaction: Correction block is reorganized.
Local alarm reaction.
Interface signals are set.
Alarm display.
NC Stop on alarm at block end.
Remedy: Change MD20380 $MC_TOOL_CORR_MODE_G43G44 or the part program.
Program Clear alarm with NC START or RESET key and continue the program.
Continuation:
14162 [Channel %1: ] Block %2 error %3 on activation of the CUTMOD function
Parameters: %1 = Channel number
%2 = Block number, label
%3 = Error code
Definitions: An error occurred during the activation of the CUTMOD function. The type of error is more closely defined by the error
code number:
Error code
1No valid cutting direction is defined for the active tool.
2The edge angles (clearance angle and holder angle) of the active tool are both zero.
3The clearance angle of the active tool has an impermissible value (less than 0 degrees or greater than 180 degrees).
4The holder angle of the active tool has an impermissible value (less than 0 degrees or greater than 90 degrees).
5The cutting tip angle of the active tool has an impermissible value (less than 0 degrees or greater than 90 degrees).
6
positions 1 through 4, the holder angle must be less than or equal to 90 degrees, with cutting edge positions 5 through
8, it must greater than or equal to 90 degrees).
7
1 degree) out of the active machining plane. As a result, the cutting edge position is no longer defined in the machining
plane.
With the aid of MD20125 $MC_CUTMOD_ERR, it can be determined for each of the named errors whether the fault
condition is to lead to the issue of an alarm, and whether the alarm is only to be displayed or also trigger a program
stop.
Reaction: Interpreter stop
Interface signals are set.
Alarm display.
170
The cutting edge position - holder angle combination of the active tool is impermissible (with cutting edge
Impermissible rotation of the active tool (the tool was rotated through +/-90 degrees (with a tolerance of about
