Remedy: Please inform the authorized personnel/service department. Select for the identifier to be entered a character string
that is not yet used in the system (max. 32 characters).
Program Teileprogramm neu starten.Clear alarm with the RESET key in all channels of this mode group. Restart part program.
Continuation:
4021

[Channel %1: ] Identifier %2 used several times in machine data %3

Parameters: %1 = Channel number
%2 = String: Name of identifier
%3 = String: MD identifier
Definitions: To determine the name in the channel-specific tables for geometry axes and channel axes an identifier already existing
in the control has been used.
Reaction: NC not ready.
Mode group not ready, also effective for single axes.
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm.
Remedy: Please inform the authorized personnel/service department. Select for the identifier to be entered a character string
that is not yet used in the system (max. 32 characters).
Program Switch control OFF - ON.
Continuation:
4030

[Channel %1: ] Identifier missing in machine date %2[%3]

Parameters: %1 = Channel number
%2 = String: MD identifier
%3 = Index: MD array index
Definitions: An axis identifier is expected for the displayed MD in accordance with the axis configuration in the MD20070
$MC_AXCONF_MACHAX_USED and MD20050 $MC_AXCONF_GEOAX_ASSIGN_TAB.
Reaction: NC not ready.
Mode group not ready, also effective for single axes.
NC Start disable in this channel.
Interface signals are set.
Alarm display.
NC Stop on alarm.
Remedy: Please inform the authorized personnel/service department.
Check axis configuration and enter the missing identifier into the MD or, should the axis not exist, specify for this chan-
nel axis the machine axis 0 in the channel-specific MD20070 $MC_AXCONF_MACHAX_USED. If this concerns a
geometry axis that is not to be used (this applies only for 2-axis machining, e.g. on lathes), then channel axis 0 must
be entered additionally in the channel-specific MD20050 $MC_AXCONF_GEOAX_ASSIGN_TAB.
Program Switch control OFF - ON.
Continuation:
4032

[Channel %1: ] Wrong identifier for facing axis in %2

Parameters: %1 = Channel number
%2 = String: MD identifier
Definitions: According to the axis configuration in MD20150 $MC_GCODE_RESET_VALUES or MD20100
$MC_DIAMETER_AX_DEF, a facing axis identifier is expected at the specified location.
Alarms
