Remedy: Please inform the authorized personnel/service department. Check the transferred parameter (axis name) of the func-
tion AXNAME to determine whether a geometry, channel or machine axis of this name has been configured by means
of the machine data:
MD10000 $MN_AXCONF_MACHAX_NAME_TAB
MD20060 $MC_AXCONF_GEOAX_NAME_TAB
MD20080 $MC_AXCONF_CHANAX_NAME_TAB
Select the transfer string in accordance with the axis name, and change the axis name in the machine data if neces-
sary. (If a change of name is to take place via the NC part program, this change must first be validated by means of a
"POWER-ON").
Program Clear alarm with NC START or RESET key and continue the program.
Continuation:
14098 [Channel %1: ] Block %2 conversion error: no valid number found
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: The string is not a valid INT or REAL number.
Reaction: Interpreter stop
NC Start disable in this channel.
Interface signals are set.
Alarm display.
Remedy: Modify part program. If it is an entry, then you can check whether the string is a number via the preset function ISNUM-
BER (with the same parameter).
Program Clear alarm with the RESET key. Restart part program
Continuation:
14099 [Channel %1: ] Block %2 result in string concatenation too long
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: The result of string chaining returns a string which is greater than the maximum string length laid down by the system.
Reaction: Interpreter stop
NC Start disable in this channel.
Interface signals are set.
Alarm display.
Remedy: Adapt part program. With the function STRLEN, it is also possible to query the size of the sum string before executing
the chaining operation.
Program Clear alarm with the RESET key. Restart part program
Continuation:
14100 [Channel %1: ] Block %2 orientation transformation not available
Parameters: %1 = Channel number
%2 = Block number, label
Definitions: Up to 4 transformation groupings (transformation types) can be set for each channel via machine data. If the keyword
TRAORI(n) (n ... number of the transformation grouping) is used to address a transformation grouping for which the
machine data is not defaulted, the alarm message will be triggered.
Reaction: Correction block is reorganized.
Interface signals are set.
Alarm display.
