Ctrl Command load_text_table
Function Assigns the specified index to a text string defined by subsequent list commands and loads
the text string into the protected
load_text_table( Index )
Call
Index
Parameters
Comments • Up to 42 indexed text strings can be stored (for marking times, dates and serial
numbers by other commands). The following ordering applies:
– Index = 0...9: digits for marking the time and date [0...9]
– Index = 10...21: months [January...December]
– Index = 22...28: days-of-the-week [Sunday...Saturday]
– Index = 29: blank character for marking serial numbers
– Index = 30...39: digits for marking serial numbers [0...9]
– Index = 40: text for "a.m."
– Index = 41: text for "p.m."
If Index > 41 then load_text_table is ignored
RTC6_PARAM_ERROR).
• Even if digits are defined by
mark_char, the character set can still be subsequently switched for this purpose (see
select_char_set).
• The addresses in the protected
definitions are stored are automatically determined and internally managed.
Management is independent of that for indexed subroutines (see load_sub) and
character definitions (see load_char).
• Indexed text string definitions must be terminated with a
prerequisite for actual storage of the commands, entry of the start address into the
internal management table, and initiating a flush of the buffered list input, see
Chapter 6.4.1 "Loading Lists", page
without a preceding list_return), the text string with this index is not available.
• An indexed text string definition is not stored if the protected
"List 3" has not been previously configured for a sufficient size beyond "List 1" and
"List 2".
• If list_return
string definition is deleted from the internal management table.
• Also observe all notes in the
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References list_return, load_sub,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
RTC6 List Memory
Index of the indexed text string.
As an unsigned 32-bit value.
Allowed value range: [0...41].
mark_text
RTC6 List Memory
is the next command after load_text_table, then the corresponding text
Chapter 6.5.2 "Character Sets and Text Strings", page
load_char
area "List 3".
(get_last_error
instead of as individual characters with
area "List 3" where the text string
list_return
105. Otherwise (the input pointer is altered
return code
call. This is a
RTC6 List Memory area
118.
