Ctrl Command eth_get_com_timeouts
Function Returns timing information for an RTC6 Ethernet Board that is entered in the
RTC6 board management.
eth_get_com_timeouts( &AcquireTimeout, &AcquireMaxRetries, &SendRecvTimeout,
Call
&SendRecvMaxRetries, &KeepAlive, &KeepInterval )
Result None.
AcquireTimeout
Returned
parameter
AcquireMaxRetries
values
SendRecvTimeout
SendRecvMaxRetries
KeepAlive
KeepInterval
All values are each 0, if the board is not an RTC6 Ethernet Board.
All time specifications in µs.
Comments • See also
• By eth_set_com_timeouts, the settings can be changed
(usually only in the context of a problem clarification and only on request by SCANLAB).
• The parameters AcquireTimeout, AcquireMaxRetries, SendRecvTimeout and
SendRecvMaxRetries refer only to the
without granted access right to an RTC6 Ethernet Board.
• The returned parameters KeepAlive and KeepInterval have the value 0, if for the
addressed RTC6 Ethernet Board
– there is no access right granted
(  DLL
 DLL 619: no error message any more)
– there is a granted access right, but no connection is established
(get_last_error
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 606, OUT 606, RBF 611.
Last change DLL 619: no error message any more, if no access right granted.
References eth_set_com_timeouts,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
As a pointer to an unsigned 32-bit value.
See AcquireTimeout.
See AcquireTimeout.
See AcquireTimeout.
See AcquireTimeout.
See AcquireTimeout.
Chapter 16.5.3 "About the RTC6 Board Management", page
618:get_last_error return code
return code RTC6_ETH_ERROR)
eth_set_com_timeouts_auto
RTC6 DLL. Therefore, they can be read out even
RTC6_ACCESS_DENIED and RTC6_ETH_ERROR;
905.
