Undelayed

clear_fly_overflow

Short List
Command
Resets the specified error bits (from get_marking_info) for customer-defined monitoring
Function
of Processing-on-the-fly applications.
Call clear_fly_overflow( Mode )
Parameters Mode
Comments • For usage of clear_fly_overflow, see
page
• All 6 error bits are reset for:
– Mode = 0
– Mode = 63
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
get_marking_info,
References
Ctrl Command clear_fly_overflow_ctrl
Function Like clear_fly_overflow, but a control command.
clear_fly_overflow_ctrl( Mode )
Call
Mode
Parameters
Comments • See clear_fly_overflow.
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 628, OUT 629.
References clear_fly_overflow
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
The error bits to be reset.
As an unsigned 32-bit value.
Bit #0 = 1: error bit
Bit #1 = 1: error bit
Bit #2 = 1: error bit
Bit #3 = 1: error bit
Bit #4 = 1: error bit
Bit #5 = 1: error bit
Bit #0...Bit #5 can be combined as desired.
Higher-order bits are ignored.
256.

clear_fly_overflow_ctrl

Like clear_fly_overflow.
Bit #4 (underflow X).
Bit #5 (overflow X).
Bit #6 (underflow Y).
Bit #7 (overflow Y).
Bit #24 (underflow Z).
Bit #25 (overflow Z).
Section "Customer-Defined Monitoring Area",
340
