Normal List timed_para_jump_abs
Command
Function Moves the output point (of the laser focus) for the specified jump duration along a
2D vector from the current position to the specified position (absolute coordinate values)
within a 2D
parameter selected by
timed_para_jump_abs( X, Y, P, T )
Call
X
Parameters
Y
P
T
• Unlike para_jump_abs, the timed_para_jump_abs command does not execute the
Comments
jump with the specified (by
Instead, the speed (that is, the number of Microsteps) is adjusted so that the vector
lasts as long as specified (see
The total jump time is (for T  5) the sum of the specified (rounded) time and the set
delays.
• timed_para_jump_abs requires two
command's part on the first list entry is executed as a short list command and
afterward the second part is executed as a normal list command. Thereby, both
command parts are executed within the same 10 µs clock, unless further (previous)
short list commands induce a
• See also comments on para_jump_abs.
RTC4RTC6 New command.
See para_jump_abs.
RTC5RTC6 Unchanged functionality. In addition: increased value range.
Version info Available as of DLL 600, OUT 600, RBF 600.
References para_jump_abs, timed_jump_abs, jump_abs, timed_para_jump_rel,
timed_para_jump_abs_3d
RTC6 boards
