Notes for RTC5 Users
• In contrast to RTC5 boards, jumper numbers are
no longer imprinted on RTC6 PCIe Boards.
Therefore, RTC5 jumper designations cannot
longer be used in this RTC6 Manual. The relation
of the designations establishes
RTC5 Boards
RTC5: JP1
1
RTC5: JP6
RTC5: JP5
RTC5: JP7
RTC5: JP8
2
Legend
1. With RTC6 PCIe Boards referred to as
solder jumper field A in this manual
2. With RTC6 PCIe Boards referred to as
solder jumper field B in this manual
3. With RTC6 PCIe Boards referred to as
solder jumper field C in this manual
Jumper designations with RTC5 boards and
RTC6 PCIe Board
s.
Figure shows RTC5 board.
RTC6 boards
Doc. Rev. 1.0.21 en-US
2 Product Overview
2.7.1 Solder Jumper Field A –
The solder jumper field A is located on the lower side
Figure 1.
of the RTC6 PCIe Board, see
It is used to set the level (5 V or 3.3 V) of all output
signals at the EXTENSION 1 socket connector, see the
following table.
See also
Level", page
Allowed
jumper setting
RTC5: JP3
RTC5: JP2
RTC5: JP4
3
(1)
.
(3)
.
(2)
.
1
*
in this solder jumper field. Other combinations are
not allowed and cause damage to the board!
Configuring Output Signal
Level at EXTENSION 1 Socket
Connector
Section "Configuring the Output Signal
78.
EXTENSION 1
socket connector
Output signal level
5 V.
5V 3.3V
Digital I/O Voltage
Output signal level
3.3 V.
5V 3.3V
Digital I/O Voltage
No signal output.
5V 3.3V
Digital I/O Voltage
Caution: make sure that only one position is closed
Figure 6.
41
