Scanlab RTC6 PCIe Board Installation And Operation Manual page 730

Ctrl Command set_scanahead_params
• For error return information, see get_scanahead_params.
Comments
(cont'd)
• Mode = 1 results in aborted set_scanahead_params execution (Error = 3) if no
SCANahead system is attached or it is not active. All SCANahead functionalities are
deactivated. Parameters specified for Mode = 2 are not applied!
• set_scanahead_params( Mode = 1) cannot be executed when an automatic laser
control is active that uses read out data from an iDRIVE scan system,
see set_auto_laser_control. You have to deactivate it temporarily.
•
• set_scanahead_params waits until the last session has finished traversing, that is,
HEAD BUSY status (Bit
In any case, set_scanahead_params waits no longer than 255 × [10 µs].
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of version DLL 600, OUT 600.
Last change with version DLL 605: data type of Amax.
References get_scanahead_params, activate_scanahead_autodelays, get_last_error, get_status,
load_correction_file
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
#23) from get_status is no longer set.
730
