Ctrl Command load_z_table_20b
Function
Loads coefficients A, B and C into the currently assigned 3D correction table.
For a focus length value l in the RTC6 20-bit range [–524,288...+524,287].
Restriction
Like load_z_table_no_20b.
ErrorNo = load_z_table_20b( A, B, C )
Call
A
Parameters
B
C
Result
Like load_z_table_no_20b.
Comments
• load_z_table_20b is not executed
– the
– the
• load_z_table_20b is even executed, if:
– a list has been paused by
• load_z_table_20b should always be used after load_correction_file, since
load_correction_file
correction table.
• The ABC values are lost by select_cor_table.
• See also other comments at load_z_table_no.
RTC4RTC6
New command.
RTC5RTC6
New command.
Version info
Available as of DLL 631, OUT 632.
References
get_z_distance, read_abc_from_file_20b, write_abc_to_file_20b,
load_z_table_no_20b, select_cor_table,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Coefficient A of the parabolic function z
calculating the Z output values
(focus length value l in the RTC6 20-bit range [–524,288...+524,287].
As a 64-bit IEEE floating point value.
Allowed value range: [–1,073,741,824.0...+1,073,741,824.0].
Out-of-range values are clipped to the boundary values.
Like A (analogously).
Allowed value range: [–2,048.0...+2,048.0].
Like A (analogously).
Allowed value range: [–1.0...+1.0].
BUSY list execution status
INTERNAL-BUSY list execution status
set_wait (PAUSED list execution status
sets the three coefficients to the default values of the loaded
= A + Bl +Cl
out
(get_last_error
return code RTC6_BUSY), if:
is set
is set
load_z_table_no_20b
2
which is used for
set)
519
