Ctrl Command mcbsp_init
Function Defines the data delays for transmitting and receiving data by the
Section "McBSP Interface", page
mcbsp_init( XDelay, RDelay )
Call
XDelay
Parameters
RDelay
Comments • For invalid parameter values, mcbsp_init is not executed
(get_last_error
• The initialized values (after program start) are XDelay = RDelay = 1.
• The signals and operating conditions of the
Chapter 4.6.6 "McBSP/ANALOG Socket Connector", page
• The
provided is not transmitted, see
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References read_mcbsp, set_mcbsp_out, set_mcbsp_out_ptr, set_mcbsp_freq,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Transmission delay.
As an unsigned 32-bit value.
Allowed value range: [0...2].
Receiving delay.
As an unsigned 32-bit value.
Allowed value range: [0...2].
return code RTC6_PARAM_ERROR).
McBSP interface ignores the first FrameSync signal after a mcbsp_init. That is, data
84.
McBSP interface
page 86.
McBSP interface, see also
are presented in
84.
mcbsp_init_spi
