1

About this Manual

This manual describes the available SCANLAB
RTC6 boards and their usage for synchronous control
of scan systems, lasers and peripheral equipment.
The main chapters of this manual use the
RTC6 PCIe Board (= "RTC6 PCI Express Board") to
exemplify. For a product overview, see
"Product Overview", page
Other RTC6 board variants are described in the
Appendix:
• RTC6 Ethernet Board, see
"Appendix A: The RTC6 Ethernet Board",
page 876
The manual is a part of the product. Read these
instructions carefully before you proceed with
installing and operating.
In particular, observe all safety guidelines in this
manual. If there are any questions regarding the
contents of this manual, contact SCANLAB, see
Chapter 1.1

"Manufacturer".

Keep the manual available for servicing, repairs and
product disposal. This manual should accompany the
product if ownership changes hands.
RTC6 boards
Doc. Rev. 1.0.21 en-US
1 About this Manual
Chapter 2
31.
Chapter 16
This manual refers to:
• RTC6 Software Package V1.16.0
DLL file RTC6DLL.dll
for 32 bit
(a)
user programs
DLL file RTC6DLLx64.dll
for 64 bit
(a)
user programs
RTC6OUT.out
Program file
for the PCIe-DSP
RTC6ETH.out
Program file
for the Eth-DSP
RTC6RBF.rbf
Firmware file
for the FPGA
Auxiliary file RTC6DAT.dat
(a) Software for laser–scan processes, which controls
RTC6 boards based on this
denoted as "user program" in this manual.
(b) Abbreviated version in this manual for the Versions.
The version numbers of the supplied
RTC6 files are indicated in the names of the
corresponding zip files, see
Files", page 33.
To identify the version numbers of your files after
installation, use get_dll_version,
and get_rtc_version.
1.1 Manufacturer
SCANLAB GmbH
Siemensstr. 2a
82178 Puchheim
Germany
Tel. +49 (89) 800 746-0
Fax: +49 (89) 800 746-199
info@scanlab.de
www.scanlab.de
(b)
DLL 640
(b)
OUT 641
(b)
ETH 641
(b)
RBF 637
(b)
DAT 604
RTC6 DLL file is consistently
RTC6 DLL and
Section "Folder RTC6
get_hex_version
