Scanlab RTC6 PCIe Board Installation And Operation Manual page 948

Code Code
HIGH LOW
(hex) (hex)
05 12
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Code Code
HIGH LOW
(hex) (hex)
05 13
Notice! Generic information. May be incomplete or even incorrect for your scan system.
Code Code
HIGH LOW
(hex) (hex)
05 14
Notice! Generic information. May be incomplete or even incorrect for your scan system.
RTC6 boards
Doc. Rev. 1.0.21 en-US
20 Appendix E: iDRIVE Scan Systems – Control Commands and Signals Transmitted to RTC Boards
Data type transmitted by the scan system
As of scan system firmware  2001.
Only intelliWELD with varioSCAN
Not: intelliWELD with varioSCAN FC:
Actual z axis position
Can only be read out from the channel of the scan head connector to which the
z axis is connected.
16-bit 20-bit
protocol protocol
Bit #0 Bit #0 Unit with 16-bit protocol: In bits.
Value range with 16-bit protocol: [–32.768...+32.767].
... ...
Unit with 20-bit protocol: In bits.
Bit #15 Bit #19
Value range with 20-bit protocol: –524.288...+524.287.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Data type transmitted by the scan system
Reserved.
16-bit 20-bit –
protocol protocol
Bit #0 Bit #0 –
... ...
Bit #15 Bit #19
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
Data type transmitted by the scan system
As of scan system firmware  2001.
Temperature of galvanometer scanner
16-bit 20-bit
protocol protocol
Bit #0 Bit #0 Unit with 16-bit protocol: In 10
Value range with 16-bit protocol: [–32.768...+32.767].
... ...
Unit with 20-bit protocol: In 160
Bit #15 Bit #19
Value range with 20-bit protocol: –524.288...+524.287.
Always consult the dedicated scan system manual!
Module Rev.1.0.4 en-US
FCi.
de
–1
°C.
–1
°C.
