With several "delayed short list commands" in a
sequence of short list commands, only the last
"delayed" command can actually be executed
delayed. All others before that are executed
immediately (yet before a scanner delay).
When you sequence the commands, make sure to
place the most important "delayed" command at the
end, especially within a Polyline.
Alternatively, you can also explicitly initiate
processing of the scanner delay (for example, by
list_nop), so that all subsequent short list commands
in fact always execute "delayed".
If a normal list command succeeds more than two
short list commands, then the normal list command
is executed delayed by a 10 µs clock cycle.

Multiple List Commands

A multiple list command has multiple components
that accordingly occupy multiple list storage
positions. The initial components are always
undelayed short list commands. The final component
is always a short, normal or variable list command. All
components immediately execute successively. Any
still-pending delayed short list commands execute
first. The RTC6 command set currently only contains
two-component multiple list commands, for
example, wait_for_encoder_in_range
set_pixel_line_3d.
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands

10.1.2 Compatibility

For RTC6 customers who previously used the RTC4
(RTC5), the command descriptions (in
"RTC6 Command Set", page
command's "RTC4RTC6" ("RTC5RTC6") section:
• to what extent a command differs from that of
the RTC4 (RTC5),
• whether the command is new to the command
set,
• whether and how parameter values are converted
in RTC4 Compatibility Mode
(RTC5 Compatibility
Some RTC3/RTC4 commands and a few RTC2
commands emulated by the RTC3/RTC4 are not
supported by the RTC6, see
"Unsupported RTC4/RTC5 Commands", page
Further information on changing from the
RTC4 board to RTC6 board see
RTC4 Compatibility Mode
for RTC4 Users", page
Further information on changing from the
RTC5 board to RTC6 board see
RTC5 Compatibility Mode
for RTC5 Users", page
or
Chapter 10.2
315) note in each
Mode).
Chapter 10.3
864.
and Chapter 2.10 "Notes
48.
and Chapter 2.11 "Notes
58.
