Ctrl Command set_delay_mode
Function Turns the
and sets some special scanner delay-related parameters as well as the 3D Z-Move mode.
set_delay_mode( VarPoly, DirectMove3D, EdgeLevel, MinJumpDelay, JumpLengthLimit )
Call
Parameters Name
VarPoly
DirectMove3D
EdgeLevel
MinJumpDelay
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
"Variable Polygon Delays" mode
Allowed Values
> 0
= 0
> 0
= 0
32
0...(2 –1).
1 bit equals 10
µs.
32
0...(2 –1).
1 bit equals 10
µs.
and the "Variable Jump Delays" mode
Description
Enables "Variable Polygon Delays"
Disables "Variable Polygon Delays"
Default setting.
As an unsigned 32-bit value.
This parameter effects only 3D-applications.
The z output is changed directly (linearly) to its end
value during a jump.
The z output is changed to its end-value in such a way
that the focus is kept in one plane during the entire
jump.
As an unsigned 32-bit value.
This parameter defines a maximum "laser on" time for
the corners of a Polyline. If the
than or equal to this value (because the angle  is
close to 180°, for instance), the laser is switched off
(after a LaserOff Delay) and a new
This can be useful for preventing burn-in effects. The
EdgeLevel value must be smaller than twice the set
value for the Mark Delay, otherwise it has no effect.
See also Figure 40.
Note: To disable this feature, the EdgeLevel value must
32
be set to (2 –1) (default value).
As an unsigned 32-bit value.
Minimum Jump Delay that cannot be undercut for
jumps shorter than JumpLengthLimit (even for
jump vectors of zero length, see
longer than JumpLengthLimit, the MinJumpDelay has no
relevance. To avoid anomalies in the range of
MinJumpDelay, define a value for MinJumpDelay that is
not larger than the Jump
As an unsigned 32-bit value.
on or off
mode.
mode.
Mark Delay is longer
Polyline is started.
Figure 36). For jumps
Delay.
