Ctrl Command eth_get_port_numbers
Function Returns the UDP ports for board searches (UDPsearch) and exclusive connections (UDPexcl)
as well as the TCP port of an RTC6 Ethernet Board.
Result = eth_get_port_numbers( &UDPsearch, &UDPexcl, &TCP )
Call
Result Error code.
As an unsigned 32-bit value.
0:
1:
UDPsearch
Returned
parameter
values
UDPexcl
TCP
All values are each 0, if the board is not an RTC6 Ethernet Board.
Comments • The values can also be queried by eth_get_card_info.
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 606, OUT 606, RBF 611.
References eth_get_card_info,
Ctrl Command eth_get_serial_search
Function Returns the pertaining serial number for a specified RTC6 Ethernet Board in the search
result list.
Serialnumber = eth_get_serial_search( SearchNo )
Call
SearchNo
Parameters
Result Serial number.
As an unsigned 32-bit value.
• eth_get_serial_search is not available as a multi-board command.
Comments
• To create the search result list, use either
eth_search_cards_range. Their result value is the same as the one of
eth_found_cards. See also
page
• The result value is 0 for SearchNo = 0 and SearchNo > eth_found_cards.
At the same time the
• If an search has not yet been carried-out then automatically the following applies:
SearchNo > eth_found_cards.
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 608, OUT 608, RBF 611.
References get_serial_number,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Success: OK.
Error: Not an RTC6 Ethernet Board.
UDP port for board searches.
As a pointer to an unsigned 32-bit value.
UDP port for exclusive connections.
As a pointer to an unsigned 32-bit value.
TCP port for exclusive connections.
As a pointer to an unsigned 32-bit value.
eth_set_port_numbers
Index in the search result list.
As an unsigned 32-bit value.
Chapter 16.5.2 "About Searching RTC6 Ethernet Boards",
904.
get_last_error
eth_get_card_info_search
eth_search_cards
or
RTC6_PARAM_ERROR
return code is generated.
