Normal List timed_jump_abs
Command
Function Moves the output point (of the laser focus) for the specified jump duration along a
2D vector from the current position to the specified position (absolute coordinate values)
within a 2D
Call timed_jump_abs( X, Y, T )
Parameters X
Y
T
Comments • Unlike jump_abs, timed_jump_abs does not execute the jump with the specified (by
set_jump_speed
number of Microsteps) is adjusted so that the vector lasts as long as specified, see
Chapter 8.9 "Timed Commands", page
of the specified (rounded) time and the set delays.
• See also comments on jump_abs.
RTC4RTC6 Unchanged functionality. In addition: increased value range.
In RTC4 Compatibility
The allowed value ranges decrease accordingly.
RTC5RTC6 Unchanged functionality. In addition: increased value range.
Version info Available as of DLL 600, OUT 600, RBF 600.
References jump_abs, timed_jump_rel,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Image Field.
Like jump_abs.
Like jump_abs.
Duration of the complete jump vector. In µs.
As a 64-bit IEEE floating point value.
Allowed value range: [0...167,772,160]. The parameter is rounded to an
integer-multiple of 10. Out-of-range values are clipped.
If T < 5, then timed_jump_abs behaves like jump_abs.
or set_jump_speed_ctrl) jump speed. Instead, the speed (that is, the
Mode, the RTC6 multiplies the specified values for X and Y by 16.
timed_jump_abs_3d
274. The total jump time is (for T  5) the sum
