Ctrl Command measurement_status
Function Returns:
• Status of a measurement started by
• Current position of the measurement counter
measurement_status( &Busy, &Pos )
Call
Busy
Returned
parameter
values
Pos
Comments • If a measurement session started by
longer active, then Pos+1 indicates the number of recorded data pairs up to
termination
([0...max. channel size, see set_trigger/set_trigger4/set_trigger8]).
• Pos = 2
load_program_file.
• Stored data can be queried with get_waveform.
• The status of the measurement recording is reset by (see
– set_trigger(
– set_trigger4(
– set_trigger8(
– stop_trigger
– stop_execution
RTC4RTC6 Unchanged functionality.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References set_trigger, set_trigger4,
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
Measurement status.
As a pointer to an unsigned 32-bit value.
> 0: A measurement session is currently in progress.
= 0: No measurement session is currently in progress.
Current position of the measurement counter (within the RTC6
measurement data memory) [0...max. channel size, see
set_trigger/set_trigger4/set_trigger8].
As a pointer to an unsigned 32-bit value.
32
–1 indicates that data recording still has not occurred after
Period
= 0 )
Period = 0 )
Period
= 0 )
set_trigger8
set_trigger/set_trigger4/set_trigger8
set_trigger/set_trigger4/set_trigger8
set_trigger
is no
comments):
