Legend
1. Clock signal of the laser@DIGITAL IN1 pin.
2.
Pulse Synchronization Mode
3.
Pulse Synchronization Mode
4. Change of HalfPeriod, for example, due to a
Pulse Synchronization
Mode. For more information, see text.
RTC6 boards
Doc. Rev. 1.0.21 en-US
7 Basic Functions for Scan Head Control and Laser Control
Delay
set_laser_pulse_sync
from
10
4
disabled: LASER1 pulses@LASER1 pin, not synchronized with 1.
enabled: LASER1 pulses@LASER1 pin, synchronized with 1.
set_laser_pulses
call.
20
t [µs]
61
209
