Mcbsp_Init_Spi - Scanlab RTC6 PCIe Board Installation And Operation Manual

Ctrl Command mcbsp_init_spi
Function No function.
mcbsp_init_spi( ClockLevel, ClockDelay )
Call
ClockLevel
Parameters
ClockDelay
Comments • See
RTC4RTC6 New command.
RTC5RTC6 Changed functionality.
• The RTC6 command set contains mcbsp_init_spi, but it has no effect. Execution of it
is refused and the
• Notes on migrating the source code of RTC5 user programs, etc.: For hardware reasons,
RTC6 boards are no longer configurable for
modify any such source code sections.
Version info Available as of DLL 600, OUT 600, RBF 600.
mcbsp_init,
References
RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
= 0: inactive low.
> 0: inactive high.
As an unsigned 32-bit value.
= 0: Clock signal and data bits at the same time.
> 0: Clock signal is delayed a half period.
As an unsigned 32-bit value.
Chapter 4.6.6 "McBSP/ANALOG Socket Connector", page
get_last_error
set_mcbsp_freq
return code is RTC6_REJECTED.
SPI functionality. You need to appropriately
84.
545
